BMPRO MINIBOOSTPRO 30A lithium DC–DC charger with solar input
$395.00
KEY FEATURES
30A multi-stage lithium DC-DC charger
Dual input solar/aux up to 30A
Multi battery chemistry selector
Suitable for modern smart alternators
BMPRO BP35 and J35 compatible
BMPRO signature durability and ease of use
2 year warranty
RAPIDLY CHARGE YOUR DEEP CYCLE BATTERY WHILE YOU DRIVE
BMPRO’s MiniBoostPRO is a compact Lithium DC-DC charger with solar input, specially designed for the RV market. The MiniBoostPRO battery charger offers effective charging of your caravan, 4WD or camper trailer’s house battery from the towing vehicle’s electrical system. Blending both solar and auxiliary inputs, the MiniBoostPRO provides a combined charging current of up to a maximum of 30A, with a preference to solar. It features proprietary technology designed to charge from modern car alternators. Moreover, it can be used with LiFePO4 batteries as well as with traditional lead-acid batteries.
The MiniBoostPRO provides a multi-stage charging profile. It functions when wired directly to 12V batteries and enhances BMPRO’s BatteryPlus35 and J35 battery management systems. A range of protective features built into the MiniBoostPRO will guard your caravan or camper trailer’s charging capacity.
PRODUCT SPECIFICATIONS
Auxiliary Input Voltage 9-15V DCSolar Input Voltage 9-25V DCOutput Voltage Gel: 14.2V, AGM/Wet: 14.4.V, LiFePO4: 14.6VFloat Voltage 13.6VOutput Current Auxiliary Bypass: max. 30A; Auxiliary Boost: max. 22A; Solar Charging: max. 30A; Blending Charging: max. 30AQuiescent Current Draw Auxiliary/Primary Battery: < 25mA; Secondary Battery: < 18mAOperating Temperature -20°C to 80°CDimensions 160mm x 131mm x 41mmIP Rating IP20Standards RCM Approval, EMC CISPR 11: 2015 Class BBattery Chemistry Gel, AGM/Wet, LiFePO4
BMPRO MINIBOOST DC–DC Battery Charger
$295.00
KEY FEATURES
DC-DC charger specifically for RV applications
Input over-current and reverse voltage protection
Output over-current & short circuit protection
Output reverse connection protection
BMPRO signature durability and ease of use
IN-VEHICLE DC-DC CHARGER FOR YOUR RV
MiniBoost is a compact DC-DC charger /booster for RVs. It is specially designed to work with BMPRO’s BatteryPlus35 and J35 systems. Charge your caravan or camper trailer's house battery from the towing vehicle’s electrical system, even if the voltage delivered from the tow vehicle is lower than required for a recharge.
The MiniBoost DC to DC charger provides a 2-stage charging profile. It delivers an efficient and controlled current until the auxiliary battery is charged. Mini boost functions when wired directly to most 12V Lead Acid batteries.
The MiniBoost is not a power supply and must be connected to a battery.
To get more out of your solar panels while driving, or to use the DC-DC charger with a lithium battery, refer to
PRODUCT SPECIFICATIONS
Output 14.4V (constant voltage)// 8-18A (constant current), depending on input voltageInput 10-16 VBattery Type 12V Lead AcidBattery Chemistry AGM, Gel, Calcium or WetOperating Temp 0-50 C AmbientUnit size 157x131x39 mm
BMPRO BATTERYCHARGE25 25 Amp | 12V Battery Charger
$425.00
KEY FEATURES
Made in Australia
7 STAGE – Micro Digital Processor
Suitable for charging Lead Acid, AGM, Gel, Calcium
Includes LITHIUM (LiFeP04) charging profile
Adjustable AMP output
Suits batteries 80-800Ah
Rugged casing
Power Supply Mode
FAST 25 AMP BATTERY CHARGER WITH POWER SUPPLY MODE
25 Amp 12V battery charger, BatteryCharge25 is an automatic battery charger with seven charge states. Depending on the size of the battery, the output current is adjustable to 5, 15 or 25 Amps. It delivers high-performance, intelligent charging.
Use it with all types of 12 Volt Lead Acid batteries, such as AGM, Gel, Calcium, or Wet, as well as with LiFePO4 Lithium batteries. You can also use the charger to recondition sulfated lead-acid batteries or revive drained LiFePO4 batteries. Moreover, it is ok to leave the battery permanently connected to the charger without damage or adverse effect on its performance.
Use BatteryCharge25 to service your car, caravan, bike, truck, boat, jet ski, as well as farm equipment or communications. The portable battery charger has protective circuits to prevent it from sparking and overheating. It also features an informative LED interface, which indicates the stage of the charge cycle, selected battery chemistry, and battery charge rate.
25 Amp battery charger will increase your battery’s life and performance. It is multistage with seven stages, which are: desulphation, soft charge, bulk charge, absorption, analysis, recondition, and float.
Use the charger in power supply mode with a constant voltage of 13.6VDC or up to 20A. This is to power appliances or tools that are otherwise 12V battery-powered.
PRODUCT SPECIFICATIONS
Output 5/15/25 AmpsInput 240V, 50HzBattery Size 80 – 800 AhBattery Type Lead Acid, LiFePO4Battery Chemistry AGM, Gel, Calcium or Wet, LiFePO4Charger Type Multi-stagePower Supply Mode 13.6V (20 Amp max)
BMPRO BATTERYCHARGE15 15 Amp | 12V Battery Charger
$295.00
KEY FEATURES
Designed and made in Australia
7 STAGE – Micro Digital Processor
Suitable for charging Lead Acid, AGM, Gel, Calcium
Includes LITHIUM (LiFePO4) charging profile
Adjustable Amp output
Suits batteries 50-500Ah
Rugged casing
Power Supply Mode
PROTECT YOUR 12V BATTERY FROM OVERCHARGING
15 Amp battery charger BatteryCharge15 is an automatic multistage charger delivering high-performance intelligent charging. Depending on the size of the battery, you can adjust the output current to 5, 10 or 15 Amps.
Use it with all types of 12 Volt Lead Acid batteries, such as AGM, Gel, Calcium, or Wet, as well as with LiFePO4 Lithium batteries. You can also use the charger to recondition sulfated lead-acid batteries or revive drained LiFePO4 batteries. Moreover, it is ok to leave the battery permanently connected to the charger without damage or adverse effect on its performance.
Use BatteryCharge15 to service your car, caravan, bike, truck, boat, jet ski, tractor, or as a spare charger. The smart battery charger has protective circuits to prevent it from sparking and overheating. It also features an informative LED interface, which indicates the stage of the charge cycle, selected battery chemistry, and battery charge rate.
A heavy-duty steel body protects all components inside, making the unit extremely durable.
15 Amp battery charger will increase your battery’s life and performance. It is multistage with seven stages, which are: desulphation, soft charge, bulk charge, absorption, analysis, recondition, and float.
Use the charger in power supply mode with a constant voltage of 13.6VDC or up to 10A to power appliances or tools that are otherwise 12V battery powered.
PRODUCT SPECIFICATIONS
Output 5/10/15 AmpsInput 240V, 50HzBattery Size 50-500 AhBattery Type Lead Acid, LiFePO4Battery Chemistry AGM, Gel, Calcium or Wet, LiFePO4Charger Type Multi-stagePower Supply Mode 13.6 V (10 Amp max)
BMPRO BATTERYCHARGE7.5 7.5 Amp | 12V and 24V Battery Charger
$189.00
KEY FEATURES
Multi-stage charger
Ability to charge multiple battery chemistries
LCD display shows charge progress
Overload and reverse connection protection
Capable of charging battery sizes 10-240Ah
Durable, dust- and water-proof casing
Large clamps for easy battery connection
Ring terminals to mount the charger on the battery
RECHARGE YOUR BATTERY TO ORIGINAL CAPACITY
7 Amp battery charger BatteryCharge7.5 has ten charge states, including pulse and trickle charge modes. It delivers high-performance intelligent charging with automatically variable charging amperage up to 7.5 Amps. Use it with all types of 12 and 24 Volt Lead Acid batteries, such as AGM, Gel, Calcium, or Wet, as well as with LiFePO4 Lithium batteries:
12 V: with a capacity of 18 – 240 Ah
24 V: with a capacity of 10 – 120 Ah
Lithium (12.8V LiFePO4): with a capacity of 10 – 80 Ah
The ten-phase-charging strategy enables the recharging of the battery to almost 100 % of its original capacity. The ten phases are: check, recovery, soft start, bulk (stages 4 to 7), absorption, maintenance 1 and maintenance 2. You can leave the battery permanently connected to the charger without damage or adverse effect on its performance.
Use BatteryCharge7.5 to service your car, caravan, bike, truck, boat or as a spare charger. The smart battery charger has protective circuits to prevent it from sparking and overheating. It also features a large LCD display with indicators to let you know the charge progress of your battery. In cold weather, use a cold start to protect your battery from damage.
This 7 Amp battery charger comes supplied both with large clamps and ring terminals to connect to your battery. You can even use it to regenerate completely discharged batteries.
PRODUCT SPECIFICATIONS
Output variable up to 7.5 AmpsInput 240V, 50HzBattery Size 10-240 AhBattery Type Lead Acid, LiFePO4Battery Chemistry AGM, Gel, Calcium or Wet, LiFePO4Charger Type Ten-stage – micro digital processorPower Supply Mode 12V
BMPRO BATTERYCHARGE4 4 Amp | 6V and 12V Battery Charger
$95.00
KEY FEATURES
Multi-stage charger
Ability to charge multiple battery chemistries
LCD display shows charge progress
Overload and reverse connection protection
Capable of charging battery sizes 12-120Ah
Durable dust- and water-proof casing
Large clamps for easy battery connection
Ring terminals to mount the charger on the battery
BMPRO’s 12V 4 Amp battery charger BatteryCharge4 is an automatic battery charger with eight charge states (including pulse and trickle charge modes). It is designed to increase your battery’s life and performance.
BatteryCharger4 is adjustable to 0.9, 3 or 4 Amps and compatible with all 6 and 12 Volt Lead Acid (AGM, Gel, Calcium, Wet) and LiFePO4 Lithium batteries.
Use it to service your car, caravan, bike, boat or spare battery charging needs. Equipped with short-circuit, over-temperature and overload protection, the BatteryCharge4 has a large LCD display with indicators to let you know the charge progress of your battery.
PRODUCT SPECIFICATIONS
Output variable up to 4.0 AmpsInput 240V, 50HzBattery Size 12-120 AhBattery Type Lead Acid, LiFePO4Battery Chemistry AGM, Gel, Calcium or Wet, LiFePO4Charger Type Multi-stagePower Supply Mode 12V
BATTERIES
Revolution Power 12v 100Ah Low Draw Deep Cycle Lithium Battery
$1,398.00
Revolution Power Australia’s lithium batteries are the ultimate in deep-cycle battery technology delivering unrivaled performance and product life span. Australia’s most advanced state of the art Battery Management System (BMS) inbuilt ensures peace of mind when it comes to battery protection and safety. one of the best Lithium Batteries in Australia. 50 AMP Continuous Power Draw Ideal For A 500 WATT Inverter (max)
Lighter Weight: Up to 1/3 the weight of traditional AGM batteries
Faster Recharge: 5x faster recharge times than AGM’s
Longer Life Cycle: Up to 5000 cycles at 50% depth of discharge
Extremely Low Self-Discharge Rate: can sit unused for long periods of time
Purposely Built: for Caravans, Camper trailers, Motor homes, 4WD, Marine Vessels, Trucks
Built-in Battery Management System: Controls cell balancing, over and under-voltage protection, short circuit protection, thermal protection
Proven Parallel Ability: Use in parallel to increase your capacity for longer storage
Flat Discharge Curve: longer run time and more efficient
Safety: LiFePO4 is the safest and most stable of all lithium chemistries reducing associated risks
Proudly Australian Owned and Operated
SPECIFICATIONS
Electrical Specifications
Total Capacity 125Ah Usable Capacity (C20, 25ºC) 100Ah C20 Rating (usable amps to 10.5v) 100 Nominal Voltage 12.8v Self-Discharge Rate ≤ 3% Short Circuit Protection 200-500us Discharge Specifications Maximum Continuous Discharge (BMS) 50A Peak Discharge Current (BMS) 100A Pulse 2-4 sec Cell Discharge rating .5C Discharge Cut-Off Voltage 10.0v Life Cycles 80% DOD 2000 Life Cycles 50% DOD 5000 Operating Temperatures Optimum Temperature Range 0 ~45 ºC Operational Temperature Range -20 ~ 60 ºC Storage Temperature Range -40 ~ 120 ºC
Mechanical SpecificationsDimension (L x W x H) 305x168x215mmWeight 12.8KgCell Type Prismatic Pouch CellsCell Chemistry LiFePO4Case Material Polycarbonate IP54Terminal Type M8
Charge Specifications Recommended Charge Current 5A – 30AMaximum Charge Current 30ARecommended Charge Voltage 14.6V ± 0.2VBMS Charge Cut Off Voltage 15.6vApproved For Use In Internal/Enclosed Area
Compliance Certifications and Testing ISO9001 Certified CE Certified RoHS Certified UN38.3 Certified SGS Audited Intertek Audited IEC Certified Weight 1398.00 kgDimensions 305 × 165 × 215 cm
VIDEOS
Enerdrive ePOWER B-TEC 100Ah Slim Lithium Battery
$1,520.00
$1,624.00
Enerdrive ePOWER B-TEC 100Ah Slim Lithium Battery, 5 Year Warranty. Enerdrive B-Tec 100AH Slim Battery is an ideal solution for those who are limited for space. It can be well positioned behind the back seat of most dual cab utes or narrow spaces in other locations. The limited edition B-Tec 100Ah Slim Lithium has the same DNA boasts as all other Enerdrive B-Tec batteries. With high quality prismatic cells and suitable for up to 1000 Watt inverter with the best aftersales support program in Australia.
The ePOWER B-TEC is designed and intended for use in deep cycle applications where a single battery is required that meets the amp hour capacity.
Smart Phone Monitoring System
The Enerdrive ePOWER B-TEC battery incorporates wireless Battery Monitoring Technology. By downloading the Android™ or Apple® app to your smartphone or tablet device, you can monitor the following information;
Battery Capacity
Battery Voltage
Battery Current (Amps)
Battery State of Charge (SOC)
Battery State of Health (SOH)
Battery Status
Individual Cell Voltage
Battery Temperature
Battery Cycles
Battery Alarms
Battery Event Information
Battery Management System
The battery is also equipped with an internal LiFePO4 Battery Management System (BMS) that can monitor and optimize each Prismatic cell within the battery during normal operation. It will protect the battery pack from over charge, over discharge, over temperature & short circuit. The BMS helps to ensure safe and accurate operation of the battery.
Size & Weight Savings Lithium v AGM Capacities;
100Ah Lithium = 160Ah AGM
(Based on standard depth of discharge for both Lithium (80%) and AGM (50%).
The ePOWER B-TEC battery provides 60% more usable power than its equivalent lead acid cousin and being nearly 50% lighter and 30% smaller makes for a superior alternative.
The ePOWER B-TEC battery is perfect for camper trailers, 4WD’s (AUX battery), caravans, small water craft, low power communication sites or any other application that requires the use of a single deep cycle battery that meets the amp hour capacity.
With over 7 years of researching, designing and testing lithium batteries and the associated charging systems, Enerdrive are at the forefront of lithium battery systems in Australia. Enerdrive are the only Australian company that can supply a fully integrated self-branded energy system to suit your setup.
With over 3000 complete systems in operation Australia wide, Enerdrive is regarded as the leader in the field of lithium batteries and energy systems for Mobile, Marine and Remote applications.
Please Note: This ePOWER B-TEC lithium battery is capable to be paralleled to a second ePOWER B-TEC lithium battery. For maximum performance and lifespan of your lithium battery, no more than 2 batteries should be connected together to increase your overall capacity. Overall loads when paralleled should not exceed the current limits of a single batteries BMS.
*Note: As stipulated by the manufacturer Enerdrive, failure to charge the Enerdrive Lithium Battery range with an Enerdrive or Redarc Lithium Profile battery charger will void Enerdrive manufacturer warranty.
Specifications
Amp Hours (Ah)
100.0 Ah
Battery Voltage
12V
Cell Type
LiFePO4 Prismatic Cell, 4P x 4S (3.2V per Cell)
Nominal Voltage
12.8V
Nominal Capacity
100Ah
Cycle Life (DOD – 80% under controlled conditions)
≥ 2000 Cycles
Battery Charge Temperature
0 ̴ 45°C
Normal Charge Voltage CV/CC*
14.40 ̴ 14.60V
Standby (Float) Voltage
13.50 ̴ 13.80V
Maximum Charge Current
80A @ 25°C for 30mins
Battery Discharge Temperature
-20 ̴ 60°C
Dimensions
551 x 101 x 239 mm (L x W x H)
Net Weight (kg)
12.4 Kg
Manufacturers Warranty
5 Years
Invicta 12V 75Ah Lithium Battery with 4 Series Functionality
$1,199.00
Invicta 12V 75Ah Lithium Battery with 4 Series Functionality, 7 year warranty. The Invicta Lithium 12V range has been specifically designed for replacement of similar size Lead acid batteries. The family is comprised of the popular sizes found in the lead acid range but with the added benefits of Lithium Iron Phosphate (LiFePO4) technology and is ideally suited to deep cycle longer run time applications.
Invicta batteries are available in 12V, 24V and 36V single battery systems. They are used in a range of applications including 4×4, caravans, marine and commercial/industrial. Invicta uses aluminium encased LiFePO4 prismatic cells that are bolted together using a solid busbar for strength. A strengthening frame is also utilised to reduce movement and vibration often associated in off-road vehicles and marine applications.
Invicta batteries also have an integrated BMS that protects the battery from over charge/discharge, temperature, and short circuit. Invicta 12V200Ah and 12V300Ah also include inverter friendly capabilities.
Features:
Large number of cycles >2000 (100% DoD) Up to 8 times cycle life of SLA lowering your total cost of ownership.
Safe and stable chemistry & Integrated BMS The use of LiFePO4 along with the integrated BMS ensures protection against over charge / discharge, temperature and short circuit providing the highest degree of safety.
Greater capacity utilisation – 60% more than SLA Gives longer runtime than equivalent SLA.
High energy density (less than half of the weight of SLA) Lowering total weight of application.
Fast recharge Battery is charged and ready to be used sooner.
Flat Discharge Curve Longer run time & more efficient use of capacity.
Extremely low self-discharge rate Can sit unused for longer periods of time.
UL1642 at cell level.
Tested Independently:
The Invicta batteries are independently tested by BMRPO to ensure the highest standard of quality. The real-life testing shows that Invicta easily surpassed over 2000 cycles over 1000 days of continuous use under Australian conditions.
Commercial and Industrial Applications:
Invicta is used in both commercial and industrial applications. The Invicta batteries are IEC 62619 (selected models) and IEC 62133 certified. These certifications are independent and rigorous tests that ensures the battery and BMS can withstand short circuit, propagation, high impact, thermal abuse (extreme heat and cold), and over-charge and discharge situations.
Series and Parallel Configurations:
The Invicta batteries are capable of being paralleled.
Safety Notes:
Invicta batteries can be installed on either of its sides however not upside down
Invicta batteries are not for under bonnet use
Invicta batteries are not for starting applications
Invicta batteries must use a charger with a lithium profile setting
When using an inverter with an Invicta battery ensure that the in-rush current of the inverter does not exceed the pulse discharge of the battery
Specifications
Amp Hours (Ah)
75.0 Ah
Battery Voltage
12V
Standby Current
13.8V
Operating Range (temp)
Charge (0-50), Discharge (-20 – 55)
Nominal Voltage
12.8v
Nominal Capacity
75Ah
Total Charge Current
50A
Cycle Life (DOD – 80% under controlled conditions)
>2000
Maximum Charge Current
50V
Recommended Charge Current for Maximum Life
<30A
Maximum Discharge Current
50A
Pulse Discharge Current
150A
Charge Cut-off Voltage
10V
Dimensions
260 x 169 x 215 mm (L x W x H)
Certification
IEC 62619 & IEC 62133
Net Weight (kg)
9.8 Kg
Manufacturers Warranty
7 Years – Please see Warranty Tab for full Terms & Conditions
Invicta 12V 300Ah Lithium Battery with Bluetooth
$3,949.00
Invicta 12V 300Ah Lithium Battery with Bluetooth, 7 year warranty. The Invicta Lithium 12V range has been specifically designed for replacement of similar size Lead acid batteries. The family is comprised of the popular sizes found in the lead acid range but with the added benefits of Lithium Iron Phosphate (LiFePO4) technology and is ideally suited to deep cycle longer run time applications.
Invicta batteries are available in 12V, 24V and 36V single battery systems. They are used in a range of applications including 4×4, caravans, marine and commercial/industrial. Invicta uses aluminium encased LiFePO4 prismatic cells that are bolted together using a solid busbar for strength. A strengthening frame is also utilised to reduce movement and vibration often associated in off-road vehicles and marine applications.
Invicta batteries also have an integrated BMS that protects the battery from over charge/discharge, temperature, and short circuit. Invicta 12V200Ah and 12V300Ah also include inverter friendly capabilities.
Features:
Large number of cycles >2000 (100% DoD) Up to 8 times cycle life of SLA lowering your total cost of ownership.
Safe and stable chemistry & Integrated BMS The use of LiFePO4 along with the integrated BMS ensures protection against over charge / discharge, temperature and short circuit providing the highest degree of safety.
Greater capacity utilisation – 60% more than SLA Gives longer runtime than equivalent SLA.
High energy density (less than half of the weight of SLA) Lowering total weight of application.
Fast recharge Battery is charged and ready to be used sooner.
Flat Discharge Curve Longer run time & more efficient use of capacity.
Extremely low self-discharge rate Can sit unused for longer periods of time.
UL1642 at cell level.
Bluetooth Capabilities:
Bluetooth monitoring is available on selected models via a free mobile application. The app allows you to monitor the status of the battery’s volts, remaining capacity, current draw, and status of the Battery Management System (BMS). The Bluetooth capabilities can also be used to help troubleshoot system issues.
Tested Independently:
The Invicta batteries are independently tested by BMRPO to ensure the highest standard of quality. The real-life testing shows that Invicta easily surpassed over 2000 cycles over 1000 days of continuous use under Australian conditions.
Commercial and Industrial Applications:
Invicta is used in both commercial and industrial applications. The Invicta batteries are IEC 62619 (selected models) and IEC 62133 certified. These certifications are independent and rigorous tests that ensures the battery and BMS can withstand short circuit, propagation, high impact, thermal abuse (extreme heat and cold), and over-charge and discharge situations.
Series and Parallel Configurations:
The Invicta batteries are capable of being paralleled.
Safety Notes:
Invicta batteries can be installed on either of its sides however not upside down
Invicta batteries are not for under bonnet use
Invicta batteries are not for starting applications
Invicta batteries must use a charger with a lithium profile setting
When using an inverter with an Invicta battery ensure that the in-rush current of the inverter does not exceed the pulse discharge of the battery
Specifications
Amp Hours (Ah)
300.0 Ah
Battery Voltage
12V
Standby Current
13.8V
Operating Range (temp)
Charge (0-50), Discharge (-20 – 55)
Nominal Voltage
12.8v
Nominal Capacity
300Ah
Total Charge Current
80A
Cycle Life (DOD – 80% under controlled conditions)
>2000
Maximum Charge Current
14.6V
Recommended Charge Current for Maximum Life
<80A
Maximum Discharge Current
200A
Pulse Discharge Current
350A
Charge Cut-off Voltage
10V
Dimensions
518 x 271 x 222 mm (L x W x H)
Certification
IEC 62619 & IEC 62133
Net Weight (kg)
35.0 Kg
Manufacturers Warranty
7 Years – Please see Warranty Tab for full Terms & Conditions
Invicta 12V 200Ah Lithium Battery with Bluetooth
$2,749.00
Invicta 12V 200Ah Lithium Battery with Bluetooth, 7 year warranty. The Invicta Lithium 12V range has been specifically designed for replacement of similar size Lead acid batteries. The family is comprised of the popular sizes found in the lead acid range but with the added benefits of Lithium Iron Phosphate (LiFePO4) technology and is ideally suited to deep cycle longer run time applications.
Invicta batteries are available in 12V, 24V and 36V single battery systems. They are used in a range of applications including 4×4, caravans, marine and commercial/industrial. Invicta uses aluminium encased LiFePO4 prismatic cells that are bolted together using a solid busbar for strength. A strengthening frame is also utilised to reduce movement and vibration often associated in off-road vehicles and marine applications.
Invicta batteries also have an integrated BMS that protects the battery from over charge/discharge, temperature, and short circuit. Invicta 12V200Ah and 12V300Ah also include inverter friendly capabilities.
Features:
Large number of cycles >2000 (100% DoD) Up to 8 times cycle life of SLA lowering your total cost of ownership.
Safe and stable chemistry & Integrated BMS The use of LiFePO4 along with the integrated BMS ensures protection against over charge / discharge, temperature and short circuit providing the highest degree of safety.
Greater capacity utilisation – 60% more than SLA Gives longer runtime than equivalent SLA.
High energy density (less than half of the weight of SLA) Lowering total weight of application.
Fast recharge Battery is charged and ready to be used sooner.
Flat Discharge Curve Longer run time & more efficient use of capacity.
Extremely low self-discharge rate Can sit unused for longer periods of time.
UL1642 at cell level.
Bluetooth Capabilities:
Bluetooth monitoring is available on selected models via a free mobile application. The app allows you to monitor the status of the battery’s volts, remaining capacity, current draw, and status of the Battery Management System (BMS). The Bluetooth capabilities can also be used to help troubleshoot system issues.
Tested Independently:
The Invicta batteries are independently tested by BMRPO to ensure the highest standard of quality. The real-life testing shows that Invicta easily surpassed over 2000 cycles over 1000 days of continuous use under Australian conditions.
Commercial and Industrial Applications:
Invicta is used in both commercial and industrial applications. The Invicta batteries are IEC 62619 (selected models) and IEC 62133 certified. These certifications are independent and rigorous tests that ensures the battery and BMS can withstand short circuit, propagation, high impact, thermal abuse (extreme heat and cold), and over-charge and discharge situations.
Series and Parallel Configurations:
The Invicta batteries are capable of being paralleled.
Safety Notes:
Invicta batteries can be installed on either of its sides however not upside down
Invicta batteries are not for under bonnet use
Invicta batteries are not for starting applications
Invicta batteries must use a charger with a lithium profile setting
When using an inverter with an Invicta battery ensure that the in-rush current of the inverter does not exceed the pulse discharge of the battery
Specifications
Amp Hours (Ah)
200.0 Ah
Battery Voltage
12V
Operating Range (temp)
Charge (0-50), Discharge (-20 – 55)
Nominal Voltage
12.8V
Nominal Capacity
200Ah
Cycle Life (DOD – 80% under controlled conditions)
>2000
Dimensions
483 x 170 x 241 mm (L x W x H)
Certification
IEC 62619 & IEC 62133
Net Weight (kg)
24.2 Kg
Manufacturers Warranty
7 Years – Please see Warranty Tab for full Terms & Conditions
Invicta Lithium LiFePO4 Battery SLIMLINE 12v 50Ah with Bluetooth
$890.00
Features & Benefits with Lithium • Large number of cycles >2000 (100% DoD) Up to 8 times cycle life of SLA lowering your total cost of ownership • Safe and stable chemistry & Integrated BMS The use of LiFePO4 along with the integrated BMS ensures protection against over charge / discharge, temperature and short circuit providing the highest degree of safety • Greater capacity utilization – 60% more than SLA Gives longer run-time than equivalent SLA • High energy density (less than half of the weight of SLA) • Fast recharge
Invicta Lithium is a premium range of the highest quality Lithium Iron Phosphate (LiFePO4) composition. Lithium Iron Phosphate (LiFePO4) was selected for our Invicta range due to its inherent safety features. When comparing LiFePO4 to other Lithium technologies there are some distinct safety advantages. These advantages include greater tolerance to both high temperatures and abuse such as overcharging, short circuit and penetration. As a result of these features the risk of fire is extremely low even under harsh circumstances.
As well as utilizing LiFePO4 technology, the Invicta lithium range of batteries also includes a built in Battery Monitoring System (BMS) to further protect against over charge or discharge, over temperature and short circuit all critical for the safety of the battery. As an added benefit, Phosphate is not a hazardous material and so is friendly both to the environment and health.
The Invicta Lithium range now comes with IEC Certification on both the BMS and Cells*. This certification has been obtained through thorough testing of the product and a complete audit of the factory. The IEC Certification is a huge tick of approval for safety and quality, and peace of mind.
The Invicta Lithium range comes with all the benefits of LiFePO4 composition in either the standard 12V SLA case sizes or 24V versions for larger applications
With 3.2V per cell the Invicta Lithium range is ideally suited for replacement of equivalent size SLA with the extra benefits of up to 8 times the cycle life, greater utilization of available capacity through increased Depth of Discharge (DOD) and fast charging. All of this at close to half the weight makes them ideal for deep cycle and mobility applications.
With the all new SNL range you can even monitor the health and status of your batteries on your phone via Bluetooth wireless communication.
Feature & Benefits
IEC Certification on the combination of BMS and individual cell for complete safety peace of mind
High energy density (less than half the weight of SLA) lowering total weight of application
Fast recharge, battery is charged and ready to be used sooner
Flat discharge curve, longer run time and more efficient use of capacity
Extremely low self-discharge rate, can sit unused for longer periods of time
Large numbers of cycles >2000 (100% DoD), up to 8 times cycle life of SLA lowering your total cost of ownership
Safe and stable chemistry and integrated BMS, the use of LiFePO4 along with integrated BMS ensures protection against over charge/discharge, temperature and short circuit providing the highest degree of safety.
Bluetooth versions available, monitor the health and state of your battery from your phone
Greater capacity utilization 60% more than SLA, gives longer runtime than equivalent SLA
Applications
Mobility Devices
Caravan , 4WD and camping
Solar energy Storage
UPS and Critical power
Personal power packs
Medical Equipment
Invicta 12V 125Ah Lithium Battery with Bluetooth
$1,799.00
Invicta 12V 125Ah Lithium Battery with Bluetooth, 7 year warranty. The Invicta Lithium 12V range has been specifically designed for replacement of similar size Lead acid batteries. The family is comprised of the popular sizes found in the lead acid range but with the added benefits of Lithium Iron Phosphate (LiFePO4) technology and is ideally suited to deep cycle longer run time applications.
Invicta batteries are available in 12V, 24V and 36V single battery systems. They are used in a range of applications including 4×4, caravans, marine and commercial/industrial. Invicta uses aluminium encased LiFePO4 prismatic cells that are bolted together using a solid busbar for strength. A strengthening frame is also utilised to reduce movement and vibration often associated in off-road vehicles and marine applications.
Invicta batteries also have an integrated BMS that protects the battery from over charge/discharge, temperature, and short circuit. Invicta 12V200Ah and 12V300Ah also include inverter friendly capabilities.
Features:
Large number of cycles >2000 (100% DoD) Up to 8 times cycle life of SLA lowering your total cost of ownership.
Safe and stable chemistry & Integrated BMS The use of LiFePO4 along with the integrated BMS ensures protection against over charge / discharge, temperature and short circuit providing the highest degree of safety.
Greater capacity utilisation – 60% more than SLA Gives longer runtime than equivalent SLA.
High energy density (less than half of the weight of SLA) Lowering total weight of application.
Fast recharge Battery is charged and ready to be used sooner.
Flat Discharge Curve Longer run time & more efficient use of capacity.
Extremely low self-discharge rate Can sit unused for longer periods of time.
UL1642 at cell level.
Bluetooth Capabilities:
Bluetooth monitoring is available on selected models via a free mobile application. The app allows you to monitor the status of the battery’s volts, remaining capacity, current draw, and status of the Battery Management System (BMS). The Bluetooth capabilities can also be used to help troubleshoot system issues.
Tested Independently:
The Invicta batteries are independently tested by BMRPO to ensure the highest standard of quality. The real-life testing shows that Invicta easily surpassed over 2000 cycles over 1000 days of continuous use under Australian conditions.
Commercial and Industrial Applications:
Invicta is used in both commercial and industrial applications. The Invicta batteries are IEC 62619 (selected models) and IEC 62133 certified. These certifications are independent and rigorous tests that ensures the battery and BMS can withstand short circuit, propagation, high impact, thermal abuse (extreme heat and cold), and over-charge and discharge situations.
Series and Parallel Configurations:
The Invicta batteries are capable of being paralleled. Please see the Installation Guide for conditions.
Safety Notes:
Invicta batteries can be installed on either of its sides however not upside down
Invicta batteries are not for under bonnet use
Invicta batteries are not for starting applications
Invicta batteries must use a charger with a lithium profile setting
When using an inverter with an Invicta battery ensure that the in-rush current of the inverter does not exceed the pulse discharge of the battery
Specifications
Amp Hours (Ah)
125.0 Ah
Battery Voltage
12V
Standby Current
13.8V
Operating Range (temp)
Charge (0-50), Discharge (-20 – 55)
Nominal Voltage
12.8v
Nominal Capacity
125Ah
Total Charge Current
80A
Cycle Life (DOD – 80% under controlled conditions)
>2000
Maximum Charge Current
14.6V
Recommended Charge Current for Maximum Life
<60A
Maximum Discharge Current
100A
Pulse Discharge Current
350A
Charge Cut-off Voltage
10V
Dimensions
318 x 165 x 215 mm (L x W x H)
Certification
IEC 62619 & IEC 62133
Net Weight (kg)
14.8 Kg
Manufacturers Warranty
7 Years – Please see Warranty Tab for full Terms & Conditions
THIS IS A SUBHEADING
Check out this section's heading
REDARC The Manager30 S2
$1,786.00
$2,005.00
The Manager30 is a complete battery management system for charging auxiliary batteries used in recreational automotive and marine applications. The dual battery system incorporates AC, DC, and solar inputs to achieve the best charge for an auxiliary battery.Developed with ease of installation in mind, The Manager30 is compatible with all vehicles and alternator systems including variable voltage alternators.Whether you’re charging Lead Acid, Gel, Calcium, AGM, or Lithium Iron Phosphate batteries, The Manager30 represents a complete DC to DC charging and maintenance solution. If you’re charging one auxiliary battery or more, The Manager30 will ensure they’re always fully charged, providing peace of mind when battery charge provides the power source for the comforts of home whilst traveling around Australia.The Manager30 operates like 6 separate products, it charges an auxiliary battery from the vehicle while on the move, it’s a 240-volt charger, a solar regulator, a battery isolator, a load disconnect controller, all with a remote battery monitor, making it market-leading.
Charging lithium batteries
Lithium batteries have improved storage capacity relative to size and weight. They do however require specific charging conditions in order to operate correctly and the battery itself must have an in-built cell management system. REDARC has designed a charging profile within The Manager30 to complement these in-built systems.
Green power priority
The Manager30 is designed to charge an auxiliary battery from multiple sources simultaneously. If 12 volt solar power is available, solar power will be used before topping up the output charging current from another source mains (if available) or DC vehicle power when on the move.
MPPT solar regulator
The built-in Maximum Power Point Tracking (MPPT) solar regulator allows The Manager30 to deliver the maximum amount of power from portable solar panels, even during low light conditions.
Remote monitor
Designed to show you auxiliary battery information and charge status. You can customize how your battery is charged and monitor where the charge is coming from. A user-friendly, graphical display monitor lets you know what’s going on, keeping you in control at all times.
Features
Multi-Stage AC-DC Battery Charger
Multi-Stage DC to DC Charger
Maximum Power Point Tracking Solar Regulator
Battery Monitor
Dual Battery Isolator
Load Disconnect Controller
Super quiet operation
Charges AGM, Gel, Calcium content, VRLA, Standard Lead Acid, and LiFePO4 batteries
Tested to mains power safety standards in Australia
Specifications
Output System Voltage
12VDC
Maximum Charging Voltage
16.0V* (*Calcium setting in storage mode)
Output Current Rating (Cont.)
30A
Output Power
520W
Input Fuse Rating
40A
Output Fuse Rating
40A
Warranty
2 Years
Protection
Short Circuit, Surge, Reverse Polarity, Overload
Input (Operating) Voltage
240VAC / 9 - 32VDC
Length (mm)
445
Width (mm)
185
Height (mm)
79
Weight (kg)
5.5
AC Mains Plug Type
AU, NZ, EU
Type Approval
CE
Videos
REDARC The Manager30 with RedVision display
$2,298.00
$2,350.00
BMS1230S3R Manual
The Manager30 BMS1230S3R features both the RedVision display screen and mobile phone connectivity for complete battery management for charging auxiliary batteries used in recreational automotive and marine applications. The dual battery system incorporates AC, DC and solar inputs to achieve the best charge for an auxiliary battery.
This 30amp charger is the complete battery management system that gives you the best of both worlds. Whether you’re free camping or on a powered site, it knows how to take charge and keep auxiliary batteries fully charged.
The Manager30 operates like 6 separate products, it charges an auxiliary battery from the vehicle while on the move, it’s a 240-volt charger, a solar regulator, a battery isolator, a load disconnect controller, all with a remote coloured RedVision battery monitor, making it market-leading.
The RedVision remote battery monitor is designed to show auxiliary battery information and charge status through its coloured display. You can customise how your battery is charged and monitor where it is coming from. It also provides full connectivity to the Manager30 via the RedVision Smartphone App on both Apple and Android devices.
Whether you’re charging Lead Acid, Gel, Calcium, AGM or Lithium Iron Phosphate batteries, The Manager30 represents a complete DC to DC charging and maintenance solution. If you’re charging one auxiliary battery or more, The Manager30 will ensure they’re always fully charged, providing peace of mind when battery charge provides the power source for the comforts of home whilst travelling around Australia.
Developed with ease of installation in mind, The Manager30 is compatible with all vehicles and alternator systems including variable voltage alternators.
RedVision monitor
The Manager30 comes with a display designed to give you house battery information and charge status along with critical system information while charging is in progress. With the display, you can customise how your house battery is charged and monitor where the charge is coming from, keeping you in control at all times.
The display can be surface mounted on a wall or recessed (into the dashboard of an RV for example). The display also allows a Bluetooth connection to your Smartphone, via the RedVision App, which provides the same data and control available on the display all in the palm of your hand.
Charging lithium batteries
Lithium batteries (LiFeP04) have improved storage capacity relative to size and weight. They do however require specific charging conditions in order to operate correctly and the battery itself must have an in-built cell management system. REDARC have designed a charging profile within The Manager30 to complement these in-built systems.
Green power priority
The Manager30 is designed to charge an auxiliary battery from multiple sources simultaneously. If 12-volt solar power is available, solar power will be used before topping up the output charging current from another source mains (if available) or DC vehicle power when on the move.
MPPT solar regulator
The built-in Maximum Power Point Tracking (MPPT) solar regulator allows The Manager30 to deliver the maximum amount of power from portable solar panels, even during low light conditions.
Features
Multi-Stage AC-DC Battery Charger
Multi-Stage DC to DC Charger
Maximum Power Point Tracking Solar Regulator
Improved, 4.3” coloured RedVision display battery monitor
RedVision display allows connection to Smartphone via App
Dual Battery Isolator
Load Disconnect Controller
Super quiet operation
Charges AGM, Gel, Calcium content, VRLA, Standard Lead Acid and LiFePO4 batteries
Tested to mains power safety standards in Australia
Specifications
Output System Voltage
12VDC
Maximum Charging Voltage
16.0V* (*Calcium setting in storage mode)
Output Current Rating (Cont.)
30A
Output Power
520W
Input Fuse Rating
50A
Output Fuse Rating
40A
Protection
Short Circuit, Surge, Reverse Polarity, Overload
Input (Operating) Voltage
220-240VAC / 9 - 32VDC
Length (mm)
445
Width (mm)
185
Weight (kg)
5.5
AC Mains Plug Type
AU, NZ, EU
Type Approval
CE
Warranty
2 Years
REDARC Manager30 S3
$1,930.00
$1,999.00
The next-generation Manager30 S3 model is the complete battery management system for charging auxiliary batteries used in 4wd, camper recreational automotive, and marine applications. The dual battery system incorporates AC, DC, and solar inputs to achieve the best charge for an auxiliary battery.
Has been developed with ease of installation in mind, The Manager30 is compatible with all vehicles and alternator systems including variable voltage alternators.
Whether you’re charging Lead Acid, Gel, Calcium, AGM, or Lithium Iron Phosphate batteries, The Manager30 represents a complete DC to DC charging and maintenance solution. If you’re charging one auxiliary battery or more, The Manager30 will ensure they’re always fully charged, providing peace of mind when battery charge provides the power source for the comforts of home whilst travelling around Australia.
The Manager30 operates like 6 separate products, it charges an auxiliary battery from the vehicle while on the move, it’s a 240-volt charger, a solar regulator, a battery isolator, a load disconnect controller, all with a remote battery monitor, making it market-leading.
Charging lithium batteries
Lithium batteries have improved storage capacity relative to size and weight. They do however require specific charging conditions in order to operate correctly and the battery itself must have an in-built cell management system. REDARC has designed a charging profile within The Manager30 to complement these in-built systems.
Green power priority
The Manager30 is designed to charge an auxiliary battery from multiple sources simultaneously. If 12-volt solar power is available, solar power will be used before topping up the output charging current from another source mains (if available) or DC vehicle power when on the move.
MPPT solar regulator
The built-in Maximum Power Point Tracking (MPPT) solar regulator allows The Manager30 to deliver the maximum amount of power from portable solar panels, even during low light conditions.
Remote monitor
Designed to show you auxiliary battery information and charge status. You can customize how your battery is charged and monitor where the charge is coming from. A user-friendly, graphical display monitor lets you know what’s going on, keeping you in control at all times.
Features
Multi-Stage AC-DC Battery Charger
Multi-Stage DC to DC Charger
Maximum Power Point Tracking Solar Regulator
Battery Monitor
Dual Battery Isolator
Load Disconnect Controller
Super quiet operation
Charges AGM, Gel, Calcium content, VRLA, Standard Lead Acid, and LiFePO4 batteries
Tested to mains power safety standards in Australia
Charging lithium batteries
Lithium batteries have improved storage capacity relative to size and weight. They do however require specific charging conditions in order to operate correctly and the battery itself must have an in-built cell management system. REDARC has designed a charging profile within The Manager30 to complement these in-built systems.
Green power priority
The Manager30 is designed to charge an auxiliary battery from multiple sources simultaneously. If 12-volt solar power is available, solar power will be used before topping up the output charging current from another source mains (if available) or DC vehicle power when on the move.
MPPT solar regulator
The built-in Maximum Power Point Tracking (MPPT) solar regulator allows The Manager30 to deliver the maximum amount of power from portable solar panels, even during low light conditions.
Remote monitor
Designed to show you auxiliary battery information and charge status. You can customize how your battery is charged and monitor where the charge is coming from. A user-friendly, graphical display monitor lets you know what’s going on, keeping you in control at all times.
Multi-Stage AC-DC Battery Charger
Multi-Stage DC to DC Charger
Maximum Power Point Tracking Solar Regulator
Battery Monitor
Dual Battery Isolator
Load Disconnect Controller
Super quiet operation
Charges AGM, Gel, Calcium content, VRLA, Standard Lead Acid and LiFePO4 batteries
Tested to mains power safety standards in Australia
SPECIFICATIONS
Output System Voltage
12VDC
Maximum Charging Voltage
16.0V* (*Calcium setting in storage mode)
Output Current Rating (Cont.)
30A
Output Power
520W
Input Fuse Rating
40A
Output Fuse Rating
40A
Warranty
2 Years
Protection
Short Circuit, Surge, Reverse Polarity, Overload
Input (Operating) Voltage
240VAC / 9 - 32VDC
Length (mm)
445
Width (mm)
185
Height (mm)
79
Weight (kg)
5.5
AC Mains Plug Type
AU, NZ, EU
Type Approval
CE
VIDEOS
Enerdrive 4WD Canopy Systems
Designed for the end user requiring maximum power requirements along with AC charging ability and 230v Inverter power. In addition to the Explorer & Traveller, The Adventurer consists of the following extra items;
