OEX Alternator 12V 120A Valeo Style VXA932

The OEX Alternator VXA932 is a new 12V, 120A unit with a Valeo style application and an internal regulator. It is listed with a 6 groove pulley, 60mm pulley outside diameter, and a twin leg alternator mount, so the key mounting and drive details are already defined before you compare it with the vehicle.

This alternator suits Valeo unit make applications and uses an M10x1.5 / 10 pivot hole, 8.5mm adjusting hole, 178mm mount centre to centre, and 67mm inside mounting legs. Those measurements matter when you are checking physical interchange, especially where the alternator bracket, pulley alignment, and leg spacing need to match closely.

OEX identifies this as part number VXA932, with PIN code IR189, and it carries a 3yr passenger / 1yr commercial warranty. It is sold as each, weighs 6.26kg, and sits within the rotating electrical / alternators product group.

The OEX alternator range is positioned as an aftermarket option with a focus on quality and reliability. For buyers comparing replacement units, the most useful checkpoints here are the 12V charging system, 120A output, internal regulator, Valeo style fitment, and the listed mounting dimensions.

Key Features

• New OEX alternator
• 12V, 120A output
• Internal regulator type
• Valeo style / suits Valeo unit make
• Twin leg alternator mount
• 6 groove pulley

Specifications

• Voltage: 12V
• Power rating: 120 amp
• Pulley outside diameter: 60mm
• Pulley section: 6 groove
• Inside mounting legs: 67mm
• Mount centre to centre: 178mm
• Pivot hole diameter: M10x1.5 / 10
• Adjusting hole diameter: 8.5mm

Fitment guidance

• Suits Valeo unit make applications
• Listed fitment data includes Audi A3, A4 and A6 applications
• Listed fitment data includes Fiat 124 and Ducato applications
• Listed fitment data includes Iveco Daily and Turbodiesel applications
• Listed fitment data includes Lancia Beta applications
• Listed fitment data includes Mercedes-Benz C-Class, E-Class and Sprinter 3-T applications
• Listed fitment data includes Porsche 911 applications
• Listed fitment data includes Volkswagen Beetle, Bora, Golf and Passat applications

Application and Buying Notes

Before ordering, compare the part number VXA932 and the Valeo style application details against the alternator you are replacing. The critical physical checks on this unit are the 12V system, 120A output, twin leg mount, 178mm centre-to-centre measurement, and 67mm inside mounting legs, because those are the dimensions that determine whether the unit will sit correctly in the bracket and align properly with the belt drive.

The pulley setup is also important. This alternator has a 6 groove pulley with a 60mm outside diameter, so it needs to match the belt and drive arrangement already fitted to the vehicle. The pivot hole diameter is M10x1.5 / 10 and the adjusting hole is 8.5mm, which are both worth checking if you are comparing to an existing alternator or a bracket that has already been modified.

If you are purchasing for a commercial application, note the warranty is 1 year for commercial use and 3 years for passenger use. The unit is new, weighs 6.26kg, and uses an internal regulator, so replacement should be assessed as a complete alternator swap rather than assuming the regulator is separate or externally controlled.

Fitment information is broad across several European makes and models, but it should still be confirmed against the exact vehicle application and the existing unit. Matching the mounting style, pulley section, voltage, amperage, and part number is the safest way to avoid ordering the wrong alternator when the vehicle family or year range overlaps with similar units.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number VXA932 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type ALTERNATOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Inside Mounting Legs 67mm, Pivot Hole Diameter M10x1.5 / 10, Pulley Outside Diameter 60mm, Regulator Type Internal, Voltage 12, Mount Cnt to Cnt 178mm, Weight 6.26kg.

Additional published details for cross-checking include Product Group 1 ROTATING ELECTRICAL, Part No. VXA932, Brand OEX, Description OEX Alternator 12V 120A Valeo Style, Adjusting Hole Diameter 8.5, Pin Code IR189, Power Rating (Amp) 120, Pulley Section 6 Groove, Suits Unit Make Valeo, Alternator Mount Twin Leg.

OEX Alternator 12V 120A Valeo Style. Part number VXA932 should be checked first. Listed voltage is 12. Listed output rating is 120. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Mount style is Twin Leg. Regulator type is Internal. Pulley configuration is 6 Groove. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number VXA932, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a alternator in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 and output 120 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Confirm fitment by checking part number VXA932, Valeo style application details, mount type, pulley configuration, and the vehicle’s existing alternator dimensions before ordering.

FAQ

What is the voltage and output of this alternator?

It is a 12V alternator with a 120A power rating.

Is this alternator new or remanufactured?

It is listed as new.

What type of regulator does it use?

It uses an internal regulator.

What pulley does it have?

It has a 6 groove pulley with a 60mm outside diameter.

What are the key mounting measurements?

The listed mounting details are 67mm inside mounting legs, 178mm mount centre to centre, an M10x1.5 / 10 pivot hole, and an 8.5mm adjusting hole.

What warranty is supplied?

The warranty is 3 years for passenger use and 1 year for commercial use.
