OEX Alternator 12V 160A Denso Style DXA562

The OEX Alternator DXA562 is a 12V, 160A unit built in a Denso style format, with ECU voltage control and a clutch style pulley fitted. It is a new alternator, supplied as each, and uses a pad mount arrangement with 6 groove pulley layout.

This alternator is listed with internal regulator type, 55mm pulley outside diameter, 30mm mount leg thickness, 11mm adjusting hole diameter, and 12mm pivot hole diameter. The mounting dimensions also include 119mm inside mounting legs and 117mm mount centre to centre, which are important checks before ordering.

OEX identifies this unit as part number DXA562 and notes the unit suits Denso applications. It carries a 3 year passenger / 1 year commercial warranty, and the stated weight is 5.86kg. These details help confirm you are comparing the correct rotating electrical unit, not just a similar-looking alternator.

Key Features

• 12V alternator with 160A output
• Denso style unit
• ECU voltage control
• Clutch style pulley fitted
• Internal regulator
• New unit, not remanufactured

Specifications

• Brand: OEX
• Part No.: DXA562
• Product type: Alternator
• Voltage: 12V
• Power rating: 160A
• Pulley type: Clutch
• Pulley section: 6 groove
• Alternator mount: Pad

Verified fitment applications

• Chrysler Grand Voyager
• Chrysler Voyager
• Chrysler Voyager / Grand Voyager
• Fitment data includes model-year references for Chrysler Grand Voyager from 2007 through 2011
• Fitment data also includes Chrysler Voyager / Grand Voyager references from 1995 through 1998

Application and Buying Notes

The key identifier here is part number DXA562, along with the Denso style, 12V system, 160A output, and clutch style pulley. If the alternator already on the vehicle is a Denso pattern unit, comparing these details first will save time and reduce the risk of ordering the wrong rotating electrical part.

The mounting dimensions are just as important as the electrical rating. Check the pad mount setup, 117mm mount centre to centre, 119mm inside mounting legs, 30mm mount leg thickness, 11mm adjusting hole diameter, and 12mm pivot hole diameter against the vehicle’s existing alternator before purchasing.

Pulley configuration must also match. This unit uses a 6 groove clutch pulley with a 55mm outside diameter, so belt type and pulley design should be checked against the current vehicle arrangement. A mismatch here can create installation issues even when the electrical rating appears suitable.

The alternator is fitted with ECU voltage control and an internal regulator, so it should only be selected where that control arrangement is appropriate for the application. If the vehicle has been modified, or if the original unit has been replaced previously, it is worth confirming both the physical fit and the charging control setup before fitting.

For Chrysler applications, use the listed model references as a guide only and confirm the exact vehicle application against the part number and the mounting details. Matching the year range alone is not enough when alternators share similar housings but differ in pulley type, regulator arrangement, or mounting dimensions.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXA562 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type ALTERNATOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Adjusting Hole Diameter 11, Mount Leg Thickness 30mm, Pivot Hole Diameter 12, Pulley Outside Diameter 55mm, Regulator Type Internal, Voltage 12, Alternator Mount Pad.

Additional published details for cross-checking include New / Reman. New, Product Group 2 ALTERNATORS, Part No. DXA562, Brand OEX, Description OEX Alternator 12V 160A Denso Style, Pulley Type Clutch, Inside Mounting Legs 119mm, Pin Code ER46, Power Rating (Amp) 160.

OEX Alternator 12V 160A Denso Style. Part number DXA562 should be checked first. Listed voltage is 12. Listed output rating is 160. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Mount style is Pad. Regulator type is Internal. Pulley configuration is 6 Groove. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number DXA562, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a alternator in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 and output 160 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include CHRYSLER GRAND VOYAGER, CHRYSLER GRAND VOYAGER 2007, CHRYSLER GRAND VOYAGER 2008, CHRYSLER GRAND VOYAGER 2009. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Please confirm fitment using part number DXA562, the Denso style specification, the 12V 160A rating, the 6 groove clutch pulley, and the listed mounting dimensions before ordering. Vehicle listings are a guide only and should be checked against the existing unit.

FAQ

What is the part number for this alternator?

The listed OEX part number is DXA562.

What voltage and output does this alternator have?

It is a 12V alternator with a 160A power rating.

What type of pulley is fitted?

This unit is fitted with a clutch style pulley and uses a 6 groove pulley section.

Is this alternator new or remanufactured?

It is listed as a new unit.

What regulator type does it use?

The alternator has an internal regulator and ECU voltage control.

Which vehicles are listed in the fitment data?

The supplied fitment data references Chrysler Grand Voyager, Chrysler Voyager, and Chrysler Voyager / Grand Voyager applications, including Chrysler Grand Voyager model-year references from 2007 through 2011 and Chrysler Voyager / Grand Voyager references from 1995 through 1998.
