OEX Alternator 12V 50A Denso Style DXA423

The OEX Alternator DXA423 is a 12V, 50A unit built in a Denso style configuration and supplied as a new alternator. It is listed with an internal regulator, twin leg alternator mount, and a B section pulley with a 76mm outside diameter.

Key mounting dimensions include 67mm inside mounting legs, 156mm mount centre to centre, an 8mm pivot hole diameter, and an M8x1.25 adjusting hole diameter. The shaft dimension is 15, which is useful when matching the alternator to the original application.

This unit is supplied under the OEX brand, with sourcing from market leading original equipment manufacturers and aftermarket suppliers. OEX states its products come from ISO9001 certified factories and are backed by a comprehensive nationwide warranty, with the listed warranty for this alternator being 3 years for passenger use and 1 year for commercial use.

Key Features

• 12V alternator with 50A power rating
• New alternator, not remanufactured
• Denso style unit
• Internal regulator
• Twin leg alternator mount
• B section pulley, 76mm outside diameter

Specifications

• Brand: OEX
• Product type: Alternator
• Part No.: DXA423
• Voltage: 12V
• Power rating: 50A
• Unit of measure: Each
• New / Reman.: New
• Suits unit make: Denso

Verified fitment applications

• TOYOTA INDUSTRIAL 02-7FD35
• TOYOTA INDUSTRIAL 3FG25
• TOYOTA INDUSTRIAL 4SDK10
• TOYOTA INDUSTRIAL 5SDK10
• TOYOTA INDUSTRIAL 5SDK11
• TOYOTA INDUSTRIAL 5SDK9
• TOYOTA INDUSTRIAL FG25
• TOYOTA INDUSTRIAL FORKLIFT

Application and Buying Notes

When checking this alternator against an existing unit, the main identifiers to compare are part number DXA423, the 12V system voltage, and the 50A output rating. The physical fit also matters, so confirm the twin leg mount, 67mm inside mounting legs, 156mm mount centre to centre, 8mm pivot hole diameter, and M8x1.25 adjusting hole diameter before ordering.

This alternator is listed as a Denso style unit with an internal regulator and a B section pulley measuring 76mm outside diameter. Those details are important because a unit can look similar yet still differ in pulley section, regulator arrangement, or mounting geometry. Matching those items to the existing alternator is the safest way to avoid avoidable downtime.

The fitment information supplied points to Toyota Industrial applications including 02-7FD35, 3FG25, 4SDK10, 5SDK10, 5SDK11, 5SDK9, FG25, and Toyota Industrial Forklift listings. Even where the application name looks familiar, confirm the machine details and the original alternator markings, as industrial equipment can change across production runs and service histories.

If you are replacing a failed alternator, it is also worth checking the shaft dimension of 15 and the pulley section before finalising the order. The unit weight is 4.4kg, which may help when comparing with the removed alternator during inspection or parts matching. Where there is any uncertainty, use the original part number and physical measurements together rather than relying on appearance alone.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXA423 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type ALTERNATOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Inside Mounting Legs 67mm, Pivot Hole Diameter 8, Pulley Outside Diameter 76mm, Regulator Type Internal, Voltage 12, Mount Cnt to Cnt 156mm, Shaft Dimension 15.

Additional published details for cross-checking include Product Group 2 ALTERNATORS, Part No. DXA423, Brand OEX, Description OEX Alternator 12V 50A Denso Style, Adjusting Hole Diameter M8x1.25, Pin Code IR17, Power Rating (Amp) 50, Pulley Section B, Suits Unit Make Denso.

OEX Alternator 12V 50A Denso Style. Part number DXA423 should be checked first. Listed voltage is 12. Listed output rating is 50. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Mount style is Twin Leg. Regulator type is Internal. Pulley configuration is B. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number DXA423, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a alternator in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 and output 50 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Please confirm compatibility by matching part number DXA423, the Denso style application, and the measured mounting and pulley details against the existing alternator and machine setup before purchase.

FAQ

Is this alternator new or remanufactured?

It is listed as new, not remanufactured. For this listing, part number DXA423 is the main reference point. Listed voltage is 12. Listed output rating is 50. Published fitment references include TOYOTA INDUSTRIAL 02-7FD35, TOYOTA INDUSTRIAL 02-7FD35 2005, TOYOTA INDUSTRIAL 3FG25. These details should still be checked against the original unit before ordering.

What is the voltage and output rating?

This alternator is 12V with a 50A power rating. For this listing, part number DXA423 is the main reference point. Listed voltage is 12. Listed output rating is 50. Published fitment references include TOYOTA INDUSTRIAL 02-7FD35, TOYOTA INDUSTRIAL 02-7FD35 2005, TOYOTA INDUSTRIAL 3FG25. These details should still be checked against the original unit before ordering.

What part number should I match?

The listed part number is DXA423. For this listing, part number DXA423 is the main reference point. Listed voltage is 12. Listed output rating is 50. Published fitment references include TOYOTA INDUSTRIAL 02-7FD35, TOYOTA INDUSTRIAL 02-7FD35 2005, TOYOTA INDUSTRIAL 3FG25. These details should still be checked against the original unit before ordering.

What regulator type does it use?

It uses an internal regulator. For this listing, part number DXA423 is the main reference point. Listed voltage is 12. Listed output rating is 50. Published fitment references include TOYOTA INDUSTRIAL 02-7FD35, TOYOTA INDUSTRIAL 02-7FD35 2005, TOYOTA INDUSTRIAL 3FG25. These details should still be checked against the original unit before ordering.

What mounting details should I check?

Check the twin leg mount, 67mm inside mounting legs, 156mm mount centre to centre, 8mm pivot hole diameter, and M8x1.25 adjusting hole diameter. For this listing, part number DXA423 is the main reference point. Listed voltage is 12. Listed output rating is 50. Published fitment references include TOYOTA INDUSTRIAL 02-7FD35, TOYOTA INDUSTRIAL 02-7FD35 2005, TOYOTA INDUSTRIAL 3FG25. These details should still be checked against the original unit before ordering.

Which applications are listed for this alternator?

The supplied fitment includes Toyota Industrial 02-7FD35, 3FG25, 4SDK10, 5SDK10, 5SDK11, 5SDK9, FG25, and Toyota Industrial Forklift listings. For this listing, part number DXA423 is the main reference point. Listed voltage is 12. Listed output rating is 50. Published fitment references include TOYOTA INDUSTRIAL 02-7FD35, TOYOTA INDUSTRIAL 02-7FD35 2005, TOYOTA INDUSTRIAL 3FG25. These details should still be checked against the original unit before ordering.
