OEX Starter Motor 12V 12 Tooth CW Mitsubishi Style MXS2080

The OEX MXS2080 starter motor is a new 12V unit with 12 teeth, clockwise rotation, and a 1.7kW power rating. It is listed as a Mitsubishi style starter motor and uses a 2-hole starter mount with 94.5mm mount centres A.

Key dimensions include a 78mm flange diameter, 225mm overall length, 38mm pinion diameter, and 56mm pinion at rest. The mount hole diameter is M10x1.25 / 12, and the unit weighs 3.72kg.

This starter motor is supplied by OEX, with the brand sourced from market leading original equipment manufacturers and aftermarket suppliers. OEX products are sourced from ISO certified factories and are backed by a comprehensive nationwide warranty.

Key Features

• 12V starter motor
• 12 tooth pinion
• Clockwise rotation
• 1.7kW power rating
• New unit
• 2-hole starter mount

Specifications

• Part No.: MXS2080
• Brand: OEX
• Product type: Starter motor
• Voltage: 12V
• Power rating: 1.7kW
• Rotation: CW
• Number of teeth: 12
• Starter mount type: 2 hole

Fitment guidance

• Fitment is not fully verified here, so confirm the part number MXS2080 against the original starter motor before ordering.
• Check that the replacement matches 12V operation, clockwise rotation, 12 teeth, and the 2-hole mount layout with 94.5mm mount centres A.
• Measure the flange diameter, overall length, pinion diameter, and pinion offset if the original unit is available for comparison.
• Use the Mitsubishi style designation as a guide only and match the physical dimensions and mounting pattern to your vehicle application.
• If your vehicle uses a different starter mount, tooth count, or rotation direction, this unit should not be assumed to fit.

Application and Buying Notes

The safest way to buy this starter motor is to match the part number MXS2080 and then compare the physical details against the removed unit. The important checks here are 12V, clockwise rotation, 12 teeth, 1.7kW output, and the 2-hole mount with 94.5mm mount centres A.

The dimensions matter because starter motors can look similar while differing in mounting or engagement depth. For this unit, the flange diameter is 78mm, the overall length is 225mm, the pinion diameter is 38mm, and the pinion at rest is 56mm. Those measurements should be checked carefully if you are replacing an existing starter.

This starter is listed as suitable for Mitsubishi applications, but the available fitment information supplied does not verify a specific vehicle model range. That means the exact vehicle match still needs to be confirmed using the original part number, mounting arrangement, tooth count, rotation, and the dry clutch application.

The product is new, weighs 3.72kg, and is covered by a 3yr passenger / 1yr commercial warranty. Warranty terms are useful, but they do not replace fitment checking, especially where starter motor dimensions and mounting style need to match exactly.

If the original starter has any identifying label, keep that information handy when comparing units. The most reliable checks are the old part number, mounting pattern, voltage, rotation, and the pinion and flange measurements listed above.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MXS2080 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 94.5mm, Number of Teeth 12, Pinion at Rest 56mm, Power Rating 1.7kW, Suits Unit Make Mitsubishi, New / Reman. New, Wet / Dry Clutch Dry.

Additional published details for cross-checking include Product Group 2 STARTER MOTORS, Part No. MXS2080, Brand OEX, Description OEX Starter Motor 12V 12Th CW Mitsubishi Style, Flange Diameter 78mm, Mount Hole Diameter M10x1.25 / 12, Overall Length 225mm, Pinion Diameter 38mm, Rotation CW.

OEX Starter Motor 12V 12Th CW Mitsubishi Style. Part number MXS2080 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number MXS2080, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Please confirm compatibility using the part number MXS2080 and the full application details before purchase. Starter motor fitment can vary by mounting pattern, tooth count, rotation, and dimensions, so the original unit should be matched carefully.

FAQ

What is the part number for this starter motor?

The part number is MXS2080. For this listing, part number MXS2080 is the main reference point. Listed voltage is 12. Published fitment references include NISSAN ELGRAND, NISSAN ELGRAND 2000, NISSAN ELGRAND 2001. These details should still be checked against the original unit before ordering.

Is this starter motor new or remanufactured?

It is listed as new. For this listing, part number MXS2080 is the main reference point. Listed voltage is 12. Published fitment references include NISSAN ELGRAND, NISSAN ELGRAND 2000, NISSAN ELGRAND 2001. These details should still be checked against the original unit before ordering.

What voltage does this starter motor use?

It is a 12V starter motor. For this listing, part number MXS2080 is the main reference point. Listed voltage is 12. Published fitment references include NISSAN ELGRAND, NISSAN ELGRAND 2000, NISSAN ELGRAND 2001. These details should still be checked against the original unit before ordering.

What are the key rotation and tooth details?

It has clockwise rotation and 12 teeth. For this listing, part number MXS2080 is the main reference point. Listed voltage is 12. Published fitment references include NISSAN ELGRAND, NISSAN ELGRAND 2000, NISSAN ELGRAND 2001. These details should still be checked against the original unit before ordering.

What mounting style does it use?

It uses a 2-hole starter mount with 94.5mm mount centres A. For this listing, part number MXS2080 is the main reference point. Listed voltage is 12. Published fitment references include NISSAN ELGRAND, NISSAN ELGRAND 2000, NISSAN ELGRAND 2001. These details should still be checked against the original unit before ordering.

Does the listing confirm exact vehicle fitment?

No exact vehicle model fitment is verified here. The supplied information identifies Mitsubishi style and fitment guidance should be confirmed against the original part number and measurements. For this listing, part number MXS2080 is the main reference point. Listed voltage is 12. Published fitment references include NISSAN ELGRAND, NISSAN ELGRAND 2000, NISSAN ELGRAND 2001. These details should still be checked against the original unit before ordering.
