OEX Starter Motor 12V 10 Tooth CW Delco Style DXS504

The OEX DXS504 is a new 12V starter motor in Delco style, built with a clockwise rotation and a 10 tooth pinion. It is listed as a 2.2kW unit with a 2 hole starter mount, 105mm mount centres, and an 82.5mm flange diameter.

This starter motor has a 240mm overall length, a 28mm pinion diameter, and a 26mm pinion at rest. The mount hole diameter is M10x1.5, and the unit weighs 3.82kg. Those measurements matter when checking physical interchange, especially where access or mounting depth is tight.

The stated application guidance notes that it will replace original 10 tooth or 11 tooth units. It is marked as suitable for Delco units, so matching the part number DXS504 and the original starter configuration remains the safest way to confirm fitment before ordering.

Key Features

• 12V starter motor
• Clockwise rotation
• 10 tooth pinion
• Delco style application
• 2 hole starter mount
• New unit

Specifications

• Brand: OEX
• Part No.: DXS504
• Product type: Starter Motor
• Voltage: 12V
• Power rating: 2.2kW
• Rotation: CW
• Number of teeth: 10
• Starter mount type: 2 hole

Fitment guidance

• Suits Delco units
• Will replace original 10 tooth or 11 tooth starter units
• Fitment data includes applications across Mercedes-Benz, Jeep, Daewoo and SsangYong vehicles
• Listed fitment groups include Mercedes-Benz C-Class, CLS, E-Class, M-Class, S-Class, Sprinter, Valente, Vario, Viano, Vito and Vito / Mixto
• Listed fitment groups also include SsangYong Actyon, Actyon Sports, Kyron, Musso, Musso Sports, Rexton and Stavic
• Sample applications shown include Jeep Grand Cherokee, Daewoo Korando, Daewoo Musso, Mercedes-Benz 123, 124 and 190

Application and Buying Notes

Before ordering, compare the part number DXS504, the Delco style listing, and the original starter tooth count. This unit is specified as a 12V, 10 tooth, clockwise starter motor, and the note says it can replace original 10 tooth or 11 tooth units, which is the most important interchange checkpoint.

Mounting details should also be checked carefully. The starter uses a 2 hole mount with 105mm mount centres, an 82.5mm flange diameter, and M10x1.5 mount holes. If the vehicle has limited clearance, the 240mm overall length and 3.82kg weight are useful physical references.

Electrical and drive specifications matter as much as vehicle naming. This unit is rated at 2.2kW and has a 28mm pinion diameter with 26mm pinion at rest. Those values help confirm that the replacement starter matches the original configuration rather than relying on appearance alone.

Fitment references are broad and include several Mercedes-Benz, Jeep, Daewoo and SsangYong applications, but the safest purchase check is still the existing starter number and the exact mounting and rotation details on the vehicle. If the original unit differs in tooth count, mount pattern, or rotation, it should be verified before fitting.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXS504 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 105mm, Number of Teeth 10, Pinion at Rest 26mm, Power Rating 2.2kW, Suits Unit Make Delco, Note Will replace original 10 tooth or 11 Tooth Units, Starter Mount Type 2 Hole.

Additional published details for cross-checking include Weight 3.82kg, Product Group 1 ROTATING ELECTRICAL, Part No. DXS504, Brand OEX, Description OEX Starter Motor 12V 10Th CW Delco Style, Flange Diameter 82.5mm, Mount Hole Diameter M10x1.5, Overall Length 240mm, Pinion Diameter 28mm, Rotation CW.

OEX Starter Motor 12V 10Th CW Delco Style. Part number DXS504 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number DXS504, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include 5-T 2006, 5-T 2007, 5-T 2008, 5-T 2009, 6-T 2006, 6-T 2007. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Please confirm fitment using the part number DXS504, the Delco style application, the 12V clockwise rotation, the 10 tooth pinion, and the 2 hole mounting dimensions before purchasing.

FAQ

Is this starter motor new or reconditioned?

It is listed as new. For this listing, part number DXS504 is the main reference point. Listed voltage is 12. Published fitment references include 5-T 2006, 5-T 2007, 5-T 2008. These details should still be checked against the original unit before ordering.

What voltage is the OEX DXS504 starter motor?

It is a 12V starter motor. For this listing, part number DXS504 is the main reference point. Listed voltage is 12. Published fitment references include 5-T 2006, 5-T 2007, 5-T 2008. These details should still be checked against the original unit before ordering.

How many teeth does the pinion have?

The starter is listed with a 10 tooth pinion. For this listing, part number DXS504 is the main reference point. Listed voltage is 12. Published fitment references include 5-T 2006, 5-T 2007, 5-T 2008. These details should still be checked against the original unit before ordering.

What rotation does this starter motor have?

It is listed as clockwise rotation, shown as CW. For this listing, part number DXS504 is the main reference point. Listed voltage is 12. Published fitment references include 5-T 2006, 5-T 2007, 5-T 2008. These details should still be checked against the original unit before ordering.

What vehicles is it associated with?

The fitment data references Mercedes-Benz, Jeep, Daewoo and SsangYong applications, including models such as Grand Cherokee, Korando, Musso, Actyon and several Mercedes-Benz series. Exact fitment should still be confirmed against the original part and mounting details. For this listing, part number DXS504 is the main reference point. Listed voltage is 12. Published fitment references include 5-T 2006, 5-T 2007, 5-T 2008. These details should still be checked against the original unit before ordering.

What warranty is listed for this starter motor?

The listed warranty is 3 years for passenger use and 1 year for commercial use. For this listing, part number DXS504 is the main reference point. Listed voltage is 12. Published fitment references include 5-T 2006, 5-T 2007, 5-T 2008. These details should still be checked against the original unit before ordering.
