OEX Starter Motor 12V 8TH CW Mitsubishi Style MXS345

The OEX Starter Motor MXS345 is a 12V unit with 8 teeth, clockwise rotation, and a 1.2kW power rating. It is listed as a Mitsubishi style starter motor with a 2-hole mount, 70mm flange diameter, and 97mm mount centres A, so the physical dimensions matter as much as the electrical rating when checking replacement suitability.

This starter motor is new, not remanufactured, and is supplied as each. Other listed dimensions include an overall length of 178mm, a pinion diameter of 28mm, a pinion at rest of 10mm, and a mount hole diameter of M10x1.25 / 11. Those measurements are the practical checkpoints to compare against the original unit before ordering.

OEX states its products are sourced from market leading original equipment manufacturers and aftermarket suppliers, with supply from ISO certified factories. The unit is backed by a 3 year passenger and 1 year commercial warranty, which is an important consideration for buyers wanting a replacement starter with defined coverage and known specifications.

Key Features

• 12V starter motor
• 8-tooth pinion
• Clockwise rotation
• 1.2kW power rating
• 2-hole starter mount
• New unit

Specifications

• Part number: MXS345
• Voltage: 12V
• Power rating: 1.2kW
• Rotation: CW
• Number of teeth: 8
• Starter mount type: 2 hole
• Flange diameter: 70mm
• Mount centres A: 97mm

Vehicle fitment guidance

• Listed fitment includes Mitsubishi applications.
• Fitment data shown includes Mitsubishi 380, with sample model years 2005, 2006, 2007 and 2008.
• Fitment data shown also includes Mitsubishi ASX, with sample model years 2010, 2011, 2012, 2013 and 2014.
• Confirm the original starter’s part number, tooth count, rotation, mount style, and key dimensions before fitting.

Application and Buying Notes

For a starter motor, the critical checks are not just voltage and power output. This OEX unit is 12V with an 8-tooth clockwise configuration, so the original starter should match that basic setup before any other comparison is made. The 2-hole mount, 97mm mount centres A, and 70mm flange diameter are the main physical points to verify against the removed part.

The listed overall length of 178mm, pinion diameter of 28mm, and pinion at rest of 10mm are useful when comparing units side by side. If any of those measurements differ from the vehicle’s original starter, the unit may not interchange cleanly even if the make is Mitsubishi. The mount hole size of M10x1.25 / 11 is another practical check that should be confirmed carefully.

This starter is described as Mitsubishi style, and the fitment data provided points to Mitsubishi 380 and Mitsubishi ASX applications. That still leaves enough room for variation between trims, engines, and production years, so the safest approach is to match the part number MXS345 and compare the physical dimensions on the old unit before purchase. The 3 year passenger and 1 year commercial warranty adds useful context, but warranty coverage does not replace a proper fitment check.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MXS345 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 97mm, Number of Teeth 8, Pinion at Rest 10mm, Power Rating 1.2kW, Suits Unit Make Mitsubishi, New / Reman. New, Wet / Dry Clutch Dry.

Additional published details for cross-checking include Product Group 2 STARTER MOTORS, Part No. MXS345, Brand OEX, Description OEX Starter Motor 12V 8Th CW Mitsubishi Style, Flange Diameter 70mm, Mount Hole Diameter M10x1.25 / 11, Overall Length 178mm, Pinion Diameter 28mm, Rotation CW.

OEX Starter Motor 12V 8Th CW Mitsubishi Style. Part number MXS345 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number MXS345, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include MITSUBISHI 380, MITSUBISHI 380 2005, MITSUBISHI 380 2006, MITSUBISHI 380 2007. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

The listed warranty is 3yr Passenger 1yr Commercial. Warranty terms should be considered alongside correct application and part identification, as warranty does not replace fitment confirmation.

Compatibility note: Confirm compatibility by matching part number MXS345, 12V voltage, 8 teeth, clockwise rotation, 2-hole mount, and the listed dimensions against the vehicle’s original starter motor before ordering.

FAQ

What is the part number for this starter motor?

The part number listed is MXS345. For this listing, part number MXS345 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI 380, MITSUBISHI 380 2005, MITSUBISHI 380 2006. These details should still be checked against the original unit before ordering.

What voltage is this starter motor?

It is a 12V starter motor. For this listing, part number MXS345 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI 380, MITSUBISHI 380 2005, MITSUBISHI 380 2006. These details should still be checked against the original unit before ordering.

How many teeth does the pinion have?

The starter motor has 8 teeth. For this listing, part number MXS345 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI 380, MITSUBISHI 380 2005, MITSUBISHI 380 2006. These details should still be checked against the original unit before ordering.

What rotation does this starter motor use?

The rotation is clockwise, shown as CW. For this listing, part number MXS345 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI 380, MITSUBISHI 380 2005, MITSUBISHI 380 2006. These details should still be checked against the original unit before ordering.

What vehicles are shown in the fitment data?

The provided fitment data includes Mitsubishi 380 and Mitsubishi ASX applications. Specific years shown in the sample data include Mitsubishi 380 2005 to 2008 and Mitsubishi ASX 2010 to 2014. For this listing, part number MXS345 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI 380, MITSUBISHI 380 2005, MITSUBISHI 380 2006. These details should still be checked against the original unit before ordering.

What warranty is listed for this OEX starter motor?

The listed warranty is 3 years for passenger use and 1 year for commercial use. For this listing, part number MXS345 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI 380, MITSUBISHI 380 2005, MITSUBISHI 380 2006. These details should still be checked against the original unit before ordering.
