OEX Starter Motor 12V 9 Tooth CCW Bosch Style BXS0111

The OEX Starter Motor BXS0111 is a 12V, 1.1kW unit with 9 teeth and CCW rotation, built as a Bosch style replacement starter motor for rotating electrical applications. It is listed as a new unit and uses a 3 hole starter mount type, with an overall length of 224mm and a flange diameter of 76mm.

Key mounting dimensions include 122mm mount centres A, 112mm mount centres B, and 32mm mount centres C, with an 11mm mount hole diameter. The pinion diameter is 25mm and the pinion at rest measurement is 33mm, so these dimensions should be checked carefully against the vehicle’s original starter before ordering.

This starter motor is identified for Bosch unit applications and is supplied under the OEX brand, part number BXS0111. OEX new units are supported by a 3 year or 75,000 kilometre warranty, while remanufactured units carry different coverage; this listing is for a new starter motor.

Key Features

• 12V starter motor
• 1.1kW power rating
• 9 tooth pinion
• CCW rotation
• Bosch style replacement
• 3 hole starter mount

Specifications

• Brand: OEX
• Product type: Starter motor
• Part No.: BXS0111
• Voltage: 12V
• Power rating: 1.1kW
• Number of teeth: 9
• Rotation: CCW
• Suits unit make: Bosch

Known application guidance

• Audi A3
• Seat Cordoba
• Seat Toledo
• Volkswagen Bora
• Volkswagen Golf
• Volkswagen Passat
• Volkswagen Vento

Application and Buying Notes

Before buying, confirm the starter matches the vehicle’s original layout for a Bosch unit application, including 12V system voltage, 9 tooth pinion count, and CCW rotation. The BXS0111 unit also has a 3 hole mount pattern, 76mm flange diameter, and 224mm overall length, so those measurements need to line up with the existing starter and mounting points.

The mount centres are a useful cross-check when comparing parts: 122mm at A, 112mm at B, and 32mm at C, with 11mm mount holes. If any of those measurements differ from the original part, it is best to verify further before fitting, as starter motors can look similar while using different mounting and nose dimensions.

The pinion details are also important. This starter has a 25mm pinion diameter and the pinion sits 33mm at rest. Combined with the 1.1kW rating and dry clutch type, these details help distinguish it from other Bosch style starters that may share the same general appearance but not the same fitment.

If you are replacing an older starter, compare the old unit’s part number, mounting pattern, rotation, and tooth count rather than relying on appearance alone. OEX lists this as a new starter motor with a 3 year or 75,000 kilometre warranty on new units, so it is still important to confirm the exact application before purchase.

For vehicles linked to Audi A3, Seat Cordoba, Seat Toledo, Volkswagen Bora, Volkswagen Golf, Volkswagen Passat, and Volkswagen Vento applications, fitment should still be checked against the specific engine and starter arrangement on the vehicle. The compatibility of a starter motor is determined by the complete combination of part number, mounting dimensions, rotation, and electrical specification.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number BXS0111 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 122mm, Mount Centres C 32mm, Number of Teeth 9, Pinion at Rest 33mm, Power Rating 1.1kW, Suits Unit Make Bosch, Item Type Starter Motor.

Additional published details for cross-checking include Starter Mount Type 3 Hole, Weight 3.82kg, Product Group 1 ROTATING ELECTRICAL, Part No. BXS0111, Brand OEX, Description OEX Starter Motor 12V 9Th CCW Bosch Style, Flange Diameter 76mm, Mount Centres B 112mm, Mount Hole Diameter 11, Overall Length 224mm.

OEX Starter Motor 12V 9Th CCW Bosch Style. Part number BXS0111 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number BXS0111, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Confirm fitment using part number BXS0111, the 12V Bosch style application, 9 tooth CCW specification, and the measured mounting dimensions before ordering.

FAQ

What is the part number for this starter motor?

The part number is BXS0111. For this listing, part number BXS0111 is the main reference point. Listed voltage is 12. Published fitment references include AUDI A3, AUDI A3 1997, AUDI A3 1998. These details should still be checked against the original unit before ordering.

What voltage is the OEX BXS0111 starter motor?

It is a 12V starter motor. For this listing, part number BXS0111 is the main reference point. Listed voltage is 12. Published fitment references include AUDI A3, AUDI A3 1997, AUDI A3 1998. These details should still be checked against the original unit before ordering.

How many teeth does this starter have?

It has 9 teeth. For this listing, part number BXS0111 is the main reference point. Listed voltage is 12. Published fitment references include AUDI A3, AUDI A3 1997, AUDI A3 1998. These details should still be checked against the original unit before ordering.

What rotation does this starter motor use?

It is CCW rotation. For this listing, part number BXS0111 is the main reference point. Listed voltage is 12. Published fitment references include AUDI A3, AUDI A3 1997, AUDI A3 1998. These details should still be checked against the original unit before ordering.

Is this a new or remanufactured unit?

This listing is for a new starter motor. For this listing, part number BXS0111 is the main reference point. Listed voltage is 12. Published fitment references include AUDI A3, AUDI A3 1997, AUDI A3 1998. These details should still be checked against the original unit before ordering.

What warranty is listed for OEX new starter motors?

OEX new units are supported by a 3 year or 75,000 kilometre warranty. For this listing, part number BXS0111 is the main reference point. Listed voltage is 12. Published fitment references include AUDI A3, AUDI A3 1997, AUDI A3 1998. These details should still be checked against the original unit before ordering.
