OEX Starter Motor 12V 9 Tooth CW Denso Style DXS4003

The OEX Starter Motor DXS4003 is a new 12V starter motor in a Denso style layout, with 9 teeth, clockwise rotation, and a 0.8kW power rating. It is listed with a 2-hole starter mount, 91mm mount centres, a 70mm flange diameter, and an overall length of 209mm, so the physical dimensions can be checked against the original unit before ordering.

This unit is identified with a 29mm pinion diameter, 33mm pinion at rest, and M12x1.25 / 11 mount hole diameter. Those measurements matter when matching the starter to the vehicle’s bellhousing and mounting arrangement, particularly where the original starter has specific clearance or terminal requirements.

Key Features

• 12V new starter motor
• 9-tooth pinion
• Clockwise rotation
• Denso style unit
• 2-hole mount design
• Moulded square start terminal

Specifications

• Part number: DXS4003
• Brand: OEX
• Product type: Starter motor
• Voltage: 12V
• Power rating: 0.8kW
• Rotation: CW
• Number of teeth: 9
• Suits unit make: Denso

Fitment notes

• HONDA: CITY, CITY 2009, CITY 2010, CITY 2011, CITY 2012, plus other listed applications

Application and Buying Notes

Before ordering, compare the part number DXS4003, the 12V electrical rating, and the 9-tooth clockwise layout with the starter currently fitted to the vehicle. The mount centres of 91mm, 2-hole mount type, 70mm flange diameter, and 209mm overall length are the key dimensions to verify against the original unit.

The terminal style needs attention as well. This starter has a moulded square start terminal, and the note states it may require wiring modification for moulded round plug applications. If the vehicle’s existing harness uses a different connector shape, that difference should be confirmed before installation.

The listed fitment data includes Honda City and Honda Jazz applications, but the exact model year and variant still need to be checked carefully against the vehicle and the original starter. Starter motors can look similar across models while differing in pinion, mounting, or connector details, so the best match is the one that agrees with the part number and the physical measurements.

The 0.8kW power rating, 29mm pinion diameter, and 33mm pinion at rest are practical checks for compatibility and clearance. Where access is tight, or where the original unit sits close to brackets or covers, those measurements can make the difference between a correct fit and an avoidable return.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXS4003 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 91mm, Number of Teeth 9, Pinion at Rest 33mm, Power Rating 0.8kW, Suits Unit Make Denso, Note Has Moulded Square Start Terminal.May Required Wiring Modification For Moulded Round Plug Applications., Starter Mount Type 2 Hole.

Additional published details for cross-checking include Weight 2.86kg, Product Group 1 ROTATING ELECTRICAL, Part No. DXS4003, Brand OEX, Description OEX Starter Motor 12V 9Th CW Denso Style, Flange Diameter 70mm, Mount Hole Diameter M12x1.25 / 11, Overall Length 209mm, Pinion Diameter 29mm, Rotation CW.

OEX Starter Motor 12V 9Th CW Denso Style. Part number DXS4003 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number DXS4003, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include HONDA CITY, HONDA CITY 2009, HONDA CITY 2010, HONDA CITY 2011. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm fitment using the part number DXS4003, the Denso style application, and the listed mounting, tooth count, rotation, and terminal details before purchase.

FAQ

What is the part number for this starter motor?

The part number is DXS4003. For this listing, part number DXS4003 is the main reference point. Listed voltage is 12. Published fitment references include HONDA CITY, HONDA CITY 2009, HONDA CITY 2010. These details should still be checked against the original unit before ordering.

What voltage is this starter motor?

It is a 12V starter motor. For this listing, part number DXS4003 is the main reference point. Listed voltage is 12. Published fitment references include HONDA CITY, HONDA CITY 2009, HONDA CITY 2010. These details should still be checked against the original unit before ordering.

Is this a new or remanufactured unit?

It is listed as new. For this listing, part number DXS4003 is the main reference point. Listed voltage is 12. Published fitment references include HONDA CITY, HONDA CITY 2009, HONDA CITY 2010. These details should still be checked against the original unit before ordering.

What rotation does this starter motor have?

The starter motor is clockwise rotation, listed as CW. For this listing, part number DXS4003 is the main reference point. Listed voltage is 12. Published fitment references include HONDA CITY, HONDA CITY 2009, HONDA CITY 2010. These details should still be checked against the original unit before ordering.

What terminal style does it use?

It has a moulded square start terminal, and the note says it may require wiring modification for moulded round plug applications. For this listing, part number DXS4003 is the main reference point. Listed voltage is 12. Published fitment references include HONDA CITY, HONDA CITY 2009, HONDA CITY 2010. These details should still be checked against the original unit before ordering.

Which vehicle applications are shown in the provided fitment data?

The provided fitment data includes Honda City and Honda Jazz applications. The exact vehicle year and variant still need to be matched to the part number and mounting details before purchase. For this listing, part number DXS4003 is the main reference point. Listed voltage is 12. Published fitment references include HONDA CITY, HONDA CITY 2009, HONDA CITY 2010. These details should still be checked against the original unit before ordering.
