OEX Starter Motor 12V 9 Tooth CW Mitsuba Style MXS801

The OEX Starter Motor MXS801 is a 12V, clockwise rotation starter motor built in a Mitsuba style format. It has 9 teeth, a 1.6kW power rating, and a 2 hole starter mount type, which makes the physical checks just as important as the electrical ones when matching it to a vehicle.

Key dimensions to confirm before ordering are the 126mm mount centres A, 71mm flange diameter, 210mm overall length, and M10x1.25 / 11 mount hole diameter. The pinion diameter is 29mm and the pinion at rest measurement is 51mm, so the starter’s nose and engagement layout should be checked carefully against the original unit.

This is a new starter motor, sold each, and the listed part number is MXS801. It is identified as suitable for Mitsuba applications, and the fitment listing provided includes Honda Legend applications across multiple model years, so matching the exact part number and application remains the safest way to buy with confidence.

Key Features

• 12V starter motor
• 9 tooth pinion
• Clockwise rotation
• 1.6kW power rating
• 2 hole starter mount
• New unit, sold each

Specifications

• Brand: OEX
• Product type: Starter Motor
• Part No.: MXS801
• Voltage: 12V
• Rotation: CW
• Number of teeth: 9
• Power rating: 1.6kW
• Starter mount type: 2 hole

Fitment guidance

• Honda Legend applications are listed in the provided fitment data
• Fitment preview includes Honda Legend model years from 1991 through 2001
• Honda Prelude appears in the fitment make data, but no year-by-year application details are provided here
• Use the part number MXS801 and the measured dimensions to confirm the exact match before ordering

Application and Buying Notes

When replacing a starter motor, the best match is not based on voltage alone. This unit is 12V with 9 teeth, clockwise rotation, and a 1.6kW rating, so the original starter should be checked for the same electrical and engagement details as well as the same physical layout.

The mounting arrangement matters on this part. The 2 hole starter mount, 126mm mount centres A, 71mm flange diameter, and M10x1.25 / 11 mount hole diameter all need to align with the vehicle’s existing setup. If any of these measurements differ, the starter may not physically interchange even if the vehicle make appears in the fitment listing.

The pinion measurements are also worth confirming. With a 29mm pinion diameter and 51mm pinion at rest, the nose profile and gear engagement should be compared against the removed unit. This is especially important when dealing with Mitsuba style starters, where the external shape and mounting pattern are a key part of the match.

If you are cross-checking against an old starter, use the part number MXS801 first, then compare the model details, rotation, tooth count, and mounting dimensions. The unit is new, weighs 5.12kg, and is supplied with a 3yr Passenger / 1yr Commercial warranty, but warranty cover does not replace fitment verification.

For listed Honda Legend applications, confirm the exact vehicle year and engine application against the original part before fitting. The provided data also references Honda Prelude in the fitment make data, but no specific application breakdown is included here, so extra care is needed before ordering.

A starter motor can look close and still be wrong in the details that matter. Checking the mount type, flange diameter, overall length, tooth count, and rotation direction against the original component is the most reliable way to avoid installation issues and unnecessary returns.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MXS801 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 126mm, Number of Teeth 9, Pinion at Rest 51mm, Power Rating 1.6kW, Suits Unit Make Mitsuba, Item Type Starter Motor, Starter Mount Type 2 Hole.

Additional published details for cross-checking include Weight 5.12kg, Product Group 1 ROTATING ELECTRICAL, Part No. MXS801, Brand OEX, Description OEX Starter Motor 12V 9Th CW Mitsuba Style, Flange Diameter 71mm, Mount Hole Diameter M10x1.25 / 11, Overall Length 210mm, Pinion Diameter 29mm, Rotation CW.

OEX Starter Motor 12V 9Th CW Mitsuba Style. Part number MXS801 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number MXS801, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Please confirm fitment using part number MXS801, the 12V CW 9 tooth specification, and the listed mounting dimensions before ordering. Vehicle references should be matched against the original starter and application details, especially where only partial fitment data is available.

FAQ

What is the part number for this starter motor?

The listed part number is MXS801.

Is this starter motor new or remanufactured?

It is listed as new.

What voltage and rotation does it have?

It is a 12V starter motor with clockwise rotation.

How many teeth does the pinion have?

The starter motor has 9 teeth.

What mounting details should be checked before buying?

Check the 2 hole starter mount, 126mm mount centres A, 71mm flange diameter, and M10x1.25 / 11 mount hole diameter against the original unit.

Which vehicles are mentioned in the fitment data?

Honda Legend applications are listed, with model years shown from 1991 through 2001. Honda Prelude also appears in the fitment make data, but no specific year-by-year applications are provided here.
