Mahle Starter Motor 12V 11 Tooth CW MS235

MAHLE starter motor MS235 is a new 12V unit with 11 teeth, clockwise rotation, and a 3.2kW power rating. It is listed as a 3 hole starter mount type with a 89mm flange diameter, so the mounting pattern and housing dimensions are key checkpoints when comparing it to the original part.

This starter uses a reduction gear design and is described as OE-quality for fit, appearance, and durability. The listed mounting measurements are 127mm mount centres A, 90mm mount centres B, and 90mm mount centres C, along with an 11mm mount hole diameter and a 41mm pinion diameter.

The part number is MS235 and the OEM number listed is V8366 733 53. Voltage is 12, the unit is new, and the warranty is one year. That makes the part number, tooth count, rotation direction, and mount dimensions the main details to confirm before ordering.

If you are matching a failed starter, the pinion at rest is 48mm and the connecting angle is 45.0 degrees. Those details, together with the 11-tooth gear and clockwise rotation, help narrow down the correct replacement for the intended application.

Key Features

• 12V starter motor
• 11 tooth pinion
• Clockwise rotation
• 3.2kW power rating
• Reduction gear design
• 3 hole starter mount

Specifications

• Brand: MAHLE
• Part No.: MS235
• OEM Number: V8366 733 53
• Voltage: 12V
• Number of Teeth: 11
• Rotation: CW
• Power Rating: 3.2kW
• Starter Mount Type: 3 Hole

Fitment guidance

• Fitment data is listed for CASE IH, FENDT, JOHN DEERE, MASSEY FERGUSON, VALTRA, and ZETOR applications.
• Examples shown include CASE IH CS, FENDT VARIO, JOHN DEERE 2000, MASSEY FERGUSON MF 3600, VALTRA 6300# and 6350, and ZETOR 3011.
• Because fitment is application-specific, confirm the original starter details against MS235, V8366 733 53, the 11-tooth CW specification, and the 3 hole mount layout before ordering.

Application and Buying Notes

When comparing this starter to the original unit, check the part number MS235 first, then match the OEM number V8366 733 53 where available. The key physical checks are 12V operation, 11 teeth, clockwise rotation, 3 hole mounting, and the 89mm flange diameter.

Mounting dimensions matter on this model. The listed mount centres are 127mm for A and 90mm for both B and C, with an 11mm mount hole diameter. If any of those measurements differ from the old starter, the unit may not line up correctly even if the motor type looks similar.

The reduction gear design and 3.2kW power rating are useful reference points when assessing whether the replacement matches the original application. The pinion diameter is 41mm and the pinion at rest is 48mm, which are practical checks if you are comparing against an existing starter on the bench.

This is a new starter motor and the warranty is one year. That gives you a clear replacement option, but it still needs to be matched carefully to the tractor or machine application because the fitment data covers multiple makes and model families rather than one universal setup.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MS235 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty One Year, Mount Centres A 127mm, Mount Centres C 90mm, Number of Teeth 11, Pinion Diameter 41mm, Rotation CW, Voltage 12, Item Type Starter Motor.

Additional published details for cross-checking include Starter Mount Type 3 Hole, OEM Number V8366 733 53, Bore O 1 10.9, Tooth Pitch 14.39, Connecting Angle [Degree] 45.0, Packaging length 38.2, Packaging height 14.50, Product Group 2 STARTER MOTORS, Part No. MS235.

Mahle Starter Motor 12V 11Th CW. Part number MS235 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number MS235, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include CASE IH CS, CASE IH CS 2001, CASE IH CS 2002, CASE IH CS 2003, FENDT VARIO, FENDT VARIO 2010. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm fitment using the part number MS235, OEM number V8366 733 53, 12V specification, 11-tooth clockwise rotation, and the 3 hole mount dimensions before purchase. Do not rely on make name alone, as starter applications can vary between model series and production years.

FAQ

What is the part number for this starter motor?

The listed part number is MS235.

What is the voltage and rotation direction?

It is a 12V starter motor with clockwise rotation (CW).

How many teeth does the pinion have?

The starter has 11 teeth.

Is this a new or remanufactured unit?

It is listed as new.

What mounting details are provided?

The starter is a 3 hole mount type with mount centres A 127mm, B 90mm, and C 90mm, plus an 11mm mount hole diameter and 89mm flange diameter.

Which applications are shown in the fitment data?

Fitment data includes CASE IH, FENDT, JOHN DEERE, MASSEY FERGUSON, VALTRA, and ZETOR applications, with examples such as CASE IH CS, FENDT VARIO, JOHN DEERE 2000, MASSEY FERGUSON MF 3600, VALTRA 6300# and 6350, and ZETOR 3011.
