OEX Air Conditioning Compressor 24V Direct Mount Denso 10PA15C Style CXD0044

The OEX Air Conditioning Compressor is a 24V direct mount unit in Denso 10PA15C style, supplied as part number CXD0044. It is listed with pad fitting type, a 9 groove pulley section, and a 139mm clutch diameter, so it is intended for applications that match those mounting and drive details.

This compressor is identified as suitable for Denso units and carries original equipment number A5412300111. The listed oil capacity is 160ml and the unit weight is 7kg, which are useful details when comparing against the compressor already fitted to the vehicle or equipment.

Fitment matters with compressors because mounting style, pulley configuration, voltage, and refrigerant system layout all need to line up correctly. This unit is described as a direct mount 24V compressor, and the provided application notes should be checked carefully before ordering.

Key Features

• 24V air conditioning compressor
• Direct mount compressor design
• Denso 10PA15C style
• Pad fitting type
• 9 groove pulley section
• 139mm clutch diameter

Specifications

• Type: Air conditioning compressor
• Brand: OEX
• Part No.: CXD0044
• Voltage: 24
• Compressor mounting: Direct mount
• Series: 10PA15C
• Suits unit make: Denso
• Fitting type: Pad

Verified fitment notes

• Bell B40D OM541 11.9L from 01/2011 onwards
• Hitachi B40D OM541 11.9L from 01/2011 onwards

Application and Buying Notes

Before ordering, compare the compressor already on the vehicle with the key identifiers here: 24V voltage, direct mount style, Denso 10PA15C series, pad fitting type, and 9 groove pulley section. If any of those points differ, the compressor may not suit the application even if the general vehicle family looks similar.

The listed original equipment number is A5412300111 and the part number is CXD0044. Those references are the safest starting point when confirming a replacement compressor, especially for equipment where the air conditioning system has been fitted with a specific Denso-style unit.

The fitment notes supplied for this compressor point to Bell B40D OM541 11.9L from 01/2011 onwards and Hitachi B40D OM541 11.9L from 01/2011 onwards. Use those applications only where they match the vehicle details exactly, and check the compressor mount, pulley drive, and electrical system before fitting.

Oil capacity is listed as 160ml, and the unit weighs 7kg. Those details are useful for handling and installation checks, but they do not replace a direct comparison with the removed part, the existing bracket arrangement, and the system specification on the vehicle.

Because this is a direct mount compressor, the physical mounting arrangement is especially important. Confirm the mounting face, pad style, clutch diameter of 139mm, and pulley groove count before purchase so the replacement aligns with the existing belt and bracket setup.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number CXD0044 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type AIR CONDITIONING COMPRESSOR, Unit of Measure EACH, Warranty Two Years, Compressor Mounting Direct Mount, Original Equipment Number A5412300111, Series 10PA15C, Voltage 24, Oil Capacity 160ml, Weight 7kg, Product Group 1 COOLING.

Additional published details for cross-checking include Part No. CXD0044, Brand OEX, Description OEX Air Conditioning Compressor 24V Direct Mount Denso 10PA15C Style, Clutch Diameter 139mm, Fitting Type Pad, Pulley Section 9 Groove, Suits Unit Make Denso, Note 10PA15C, Dust Cover Y/N No.

OEX Air Conditioning Compressor 24V Direct Mount Denso 10PA15C Style. Part number CXD0044 should be checked first. Listed voltage is 24. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Pulley configuration is 9 Groove. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number CXD0044, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

Compatibility note: Confirm fitment by matching the part number CXD0044, original equipment number A5412300111, 24V electrical requirement, direct mount design, Denso 10PA15C style, and the listed application details before ordering.

FAQ

What type of compressor is this?

It is an OEX air conditioning compressor, listed as a 24V direct mount unit in Denso 10PA15C style. For this listing, part number CXD0044 is the main reference point. Listed voltage is 24. Published fitment references include BELL B40D, BELL B40D 2011, JOHN DEERE 350D. These details should still be checked against the original unit before ordering.

What is the part number?

The listed part number is CXD0044. For this listing, part number CXD0044 is the main reference point. Listed voltage is 24. Published fitment references include BELL B40D, BELL B40D 2011, JOHN DEERE 350D. These details should still be checked against the original unit before ordering.

What original equipment number is provided?

The original equipment number provided is A5412300111. For this listing, part number CXD0044 is the main reference point. Listed voltage is 24. Published fitment references include BELL B40D, BELL B40D 2011, JOHN DEERE 350D. These details should still be checked against the original unit before ordering.

What vehicle applications are listed?

The supplied application notes list Bell B40D OM541 11.9L from 01/2011 onwards and Hitachi B40D OM541 11.9L from 01/2011 onwards. For this listing, part number CXD0044 is the main reference point. Listed voltage is 24. Published fitment references include BELL B40D, BELL B40D 2011, JOHN DEERE 350D. These details should still be checked against the original unit before ordering.

What are the key physical specifications?

Key listed specifications include 24V voltage, direct mount compressor mounting, pad fitting type, 9 groove pulley section, 139mm clutch diameter, 160ml oil capacity, and 7kg weight. For this listing, part number CXD0044 is the main reference point. Listed voltage is 24. Published fitment references include BELL B40D, BELL B40D 2011, JOHN DEERE 350D. These details should still be checked against the original unit before ordering.

Does this compressor include a dust cover?

No. The listed dust cover status is No. For this listing, part number CXD0044 is the main reference point. Listed voltage is 24. Published fitment references include BELL B40D, BELL B40D 2011, JOHN DEERE 350D. These details should still be checked against the original unit before ordering.
