Sanden Air Conditioning Compressor 24V Direct Mount SD7H15 CXS6023

This Sanden air conditioning compressor is a 24V direct mount unit in the SD7H15 series, identified by part number CXS6023 and original equipment number 6023. It is listed as a vertical pad fitting type with an 8 groove pulley section, a 119mm clutch diameter, and a gauge line of 56.55mm.

The compressor is specified with SP 10 oil, a 240ml oil capacity, and a weight of 5.4kg. It is supplied without a dust cover and carries a one year warranty. These details matter when checking replacement requirements, especially on vehicles that need a direct mount compressor with the same voltage and mounting style.

Fitment information supplied with this unit links it to Scania applications using the DSC11 11.0L and 11.7L engine families across several model ranges and build periods. The listed application data includes P94/P112M, P124, P420, R112/113M, and T112/113M/T124 variants, so matching the compressor by part number and application details remains essential before purchase.

Key Features

• 24V Sanden air conditioning compressor
• SD7H15 series
• Direct mount compressor
• Vertical pad fitting type
• 8 groove pulley section
• 119mm clutch diameter

Specifications

• Brand: Sanden
• Product type: Air conditioning compressor
• Part No.: CXS6023
• Original Equipment Number: 6023
• Voltage: 24V
• Compressor mounting: Direct mount
• Series: SD7H15
• Gauge line: 56.55mm

Verified application details

• Scania P94/P112M DSC11 11.0L, P124 11.0L, P420 11.7L: 01/1987 to 12/2004
• Scania R112/113M DSC11 11.0L: 01/1987 to 01/1998
• Scania T112/113M/T124 DSC11 11.0L: 01/1987 to 01/2002

Application and Buying Notes

When replacing an air conditioning compressor, the safest check is the part number and the mounting arrangement. This unit is listed as CXS6023, OE number 6023, 24V, direct mount, with a vertical pad fitting type and 8 groove pulley, so those details need to line up with the vehicle and the existing compressor before ordering.

The listed application range is focused on Scania models fitted with DSC11 11.0L and 11.7L engines, including P94/P112M, P124, P420, R112/113M, and T112/113M/T124 variants across the stated build periods. If the vehicle is outside those dates or uses a different engine or compressor layout, confirm the match carefully rather than relying on model name alone.

Oil specification is another practical point on compressor replacement. This unit is specified for SP 10 oil with a 240ml oil capacity, and the unit is supplied without a dust cover. Those details can matter during installation and when comparing it with the removed component, particularly where the existing system has already been serviced or altered.

The 119mm clutch diameter, 56.55mm gauge line, and 5.4kg weight are useful checks when confirming that the replacement matches the physical compressor arrangement. If the old compressor is available, compare the mounting face, pulley section, and electrical system voltage against the listed figures before fitting.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number CXS6023 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type AIR CONDITIONING COMPRESSOR, Unit of Measure EACH, Warranty One Year, Compressor Mounting Direct Mount, Original Equipment Number 6023, Series SD7H15, Voltage 24, Gauge Line 56.55mm, Dust Cover Y/N No, Weight 5.4kg.

Additional published details for cross-checking include Product Group 1 COOLING, Part No. CXS6023, Brand SANDEN, Description Sanden Air Conditioning Compressor 24V Direct Mount SD7H15, Clutch Diameter 119mm, Fitting Type Vertical Pad, Pulley Section 8 Groove, Suits Unit Make Sanden, Note Oil Type SP 10, Oil Capacity 240ml.

Sanden Air Conditioning Compressor 24V Direct Mount SD7H15. Part number CXS6023 should be checked first. Listed voltage is 24. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Pulley configuration is 8 Groove. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number CXS6023, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a air conditioning compressor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 24 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include S - SERIES 2017, SCANIA 2 - SERIES, SCANIA 2 - SERIES 1980, SCANIA 2 - SERIES 1981, SCANIA 2 - SERIES 1982, T - SERIES 2004. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Please confirm compatibility by checking part number CXS6023, original equipment number 6023, 24V direct mount configuration, vertical pad fitting, and the stated Scania application details before purchase.

FAQ

What is the part number for this compressor?

The listed part number is CXS6023, and the original equipment number is 6023.

What voltage does this compressor use?

It is specified as a 24V air conditioning compressor.

What type of mounting does it have?

This unit is a direct mount compressor with a vertical pad fitting type.

Which pulley setup is listed?

The compressor is listed with an 8 groove pulley section and a 119mm clutch diameter.

What oil specification is required?

The listed oil type is SP 10, with an oil capacity of 240ml.

What vehicles are listed for fitment?

The listed applications are Scania P94/P112M DSC11 11.0L, P124 11.0L, P420 11.7L from 01/1987 to 12/2004, Scania R112/113M DSC11 11.0L from 01/1987 to 01/1998, and Scania T112/113M/T124 DSC11 11.0L from 01/1987 to 01/2002.
