Valeo Alternator 12V 180A 439751

This Valeo alternator is a new 12V unit with a 180A charge current and part number 439751. It is listed as a Valeo unit with internal regulator, twin leg alternator mount and four-point mounting, so the physical mounting arrangement and electrical specification both need to line up with the vehicle application before purchase.

Key dimensions include 61mm inside mounting legs, 8mm pivot hole diameter, 8mm adjusting hole diameter and a 49mm pulley outside diameter. The pulley is 6 groove, and the unit is marked R 90 position / degree with no connector for revolution counter.

Valeo is identified here as a leading OE manufacturer and supplier for many euro vehicles. That makes the unit relevant where an OE-style replacement is needed, but it still needs to be matched on part number, mounting style, pulley configuration and output rating rather than on brand name alone.

Key Features

• New alternator, not remanufactured
• 12V system
• 180A charge current
• Internal regulator
• 6 groove pulley
• Twin leg mount

Specifications

• Brand: Valeo
• Part No.: 439751
• Type: Alternator
• Voltage: 12V
• Power rating: 180A
• Charge current: 180A
• New / Reman.: New
• Warranty: One Year

Known application groups

• SKODA Superb
• Volkswagen CC
• Volkswagen Crafter 30-50
• Volkswagen Multivan
• Volkswagen Passat
• Volkswagen Transporter
• Volkswagen Transporter / Caravelle

Application and Buying Notes

Before ordering, compare the part number 439751 with the alternator already fitted to the vehicle, then check the mounting style and pulley details. This unit is a twin leg alternator with four-point mounting, 61mm inside mounting legs, 8mm pivot hole diameter, 8mm adjusting hole diameter and a 49mm pulley outside diameter, so those details need to align with the existing unit.

The electrical setup also matters. This alternator is a 12V unit with 180A output and an internal regulator. If the vehicle uses a different voltage, a different charge current, or a different regulator arrangement, the correct replacement may be different even where the vehicle family looks similar.

The pulley is listed as 6 groove and the connector note states no connector for revolution counter. That means belt type, pulley groove count and connector arrangement should be checked during comparison with the original part. Small differences in these areas can stop the alternator from fitting or functioning as intended.

The application groups provided include Skoda Superb and several Volkswagen models, but the fit still depends on the exact vehicle setup and the alternator fitted from factory. Use the vehicle details together with the part number, mounting measurements and pulley specification before you commit to the order.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number 439751 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type ALTERNATOR, Unit of Measure EACH, Warranty One Year, Inside Mounting Legs 61mm, Pivot Hole Diameter 8, Pulley Outside Diameter 49mm, Regulator Type Internal, Voltage 12, New / Reman. New, Position / Degree R 90.

Additional published details for cross-checking include Connector / Clamp No Connector for Revolution Counter, Product Group 2 ALTERNATORS, Part No. 439751, Brand VALEO, Description Valeo Alternator 12V 180A, Adjusting Hole Diameter 8, Pin Code IR139, Power Rating (Amp) 180, Pulley Section 6 Groove.

Valeo Alternator 12V 180A. Part number 439751 should be checked first. Listed voltage is 12. Listed output rating is 180. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Mount style is Twin Leg. Regulator type is Internal. Pulley configuration is 6 Groove. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number 439751, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a alternator in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 and output 180 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Please confirm compatibility using part number 439751, the 12V/180A specification, twin leg four-point mounting, 6 groove pulley and the listed measurements before purchasing. The application groups shown are guide only and should be checked against the vehicle’s existing alternator and build details.

FAQ

What is the part number for this alternator?

The part number listed is 439751. For this listing, part number 439751 is the main reference point. Listed voltage is 12. Listed output rating is 180. Published fitment references include SKODA SUPERB, SKODA SUPERB 2008, SKODA SUPERB 2009. These details should still be checked against the original unit before ordering.

Is this a new or remanufactured alternator?

This unit is listed as new. For this listing, part number 439751 is the main reference point. Listed voltage is 12. Listed output rating is 180. Published fitment references include SKODA SUPERB, SKODA SUPERB 2008, SKODA SUPERB 2009. These details should still be checked against the original unit before ordering.

What voltage and output does it have?

It is a 12V alternator with a 180A charge current and 180A power rating. For this listing, part number 439751 is the main reference point. Listed voltage is 12. Listed output rating is 180. Published fitment references include SKODA SUPERB, SKODA SUPERB 2008, SKODA SUPERB 2009. These details should still be checked against the original unit before ordering.

Does it have an internal regulator?

Yes. The regulator type is listed as internal. For this listing, part number 439751 is the main reference point. Listed voltage is 12. Listed output rating is 180. Published fitment references include SKODA SUPERB, SKODA SUPERB 2008, SKODA SUPERB 2009. These details should still be checked against the original unit before ordering.

What pulley and mounting details are listed?

The pulley is listed as 6 groove with a 49mm outside diameter. Mounting details include twin leg alternator mount, four-point mounting, 61mm inside mounting legs, 8mm pivot hole diameter and 8mm adjusting hole diameter. For this listing, part number 439751 is the main reference point. Listed voltage is 12. Listed output rating is 180. Published fitment references include SKODA SUPERB, SKODA SUPERB 2008, SKODA SUPERB 2009. These details should still be checked against the original unit before ordering.

Which vehicles are shown in the application groups?

The application groups shown include Skoda Superb and Volkswagen CC, Crafter 30-50, Multivan, Passat, Transporter and Transporter / Caravelle. Fitment should still be confirmed against the exact vehicle and the existing alternator. For this listing, part number 439751 is the main reference point. Listed voltage is 12. Listed output rating is 180. Published fitment references include SKODA SUPERB, SKODA SUPERB 2008, SKODA SUPERB 2009. These details should still be checked against the original unit before ordering.
