Mahle Alternator 12V 100A MG292

The MAHLE alternator listed here is a 12V, 100A unit with part number MG292. It is a new alternator, supplied as each, with an internal regulator and insulated ground arrangement, and it is described as dust proof with insulated return.

Key mounting details are provided for checking against the vehicle or machine before ordering. The unit has a twin leg alternator mount, inside mounting legs of 82mm, mounting bores distance of 82.0, a mount centre-to-centre measurement of 149mm, and an adjusting hole diameter of M8x1.25.

Pulley and rotation details are also important on an alternator replacement. This MAHLE unit has a double pulley, AA pulley section, 73mm pulley outside diameter, 38.3 distance from pulley to the alternator, and clockwise rotation, so those points should be matched carefully to the original unit.

Key Features

• 12V alternator with 100A charge current
• New unit, not remanufactured
• Internal regulator
• Twin leg alternator mount
• Double pulley fitted
• Dust proof design with insulated ground

Specifications

• Brand: MAHLE
• Part No.: MG292
• Type: Alternator
• Voltage: 12V
• Power rating: 100A
• Alternator charge current: 100A
• Warranty: One year
• Unit of measure: Each

Fitment guidance

• Fitment information supplied includes Caterpillar applications such as 216B, 216B2, 226B, 232B, 232B2, 242B, 901B, CB-334E, CB334D and CB335D.
• Fitment information supplied includes Massey Ferguson MF 3085 and MF 3095 applications.
• Fitment information supplied includes New Holland 6635 and 7635 applications.
• Some listed applications include model-year references, including Caterpillar 216B from 2004 through 2010, Massey Ferguson MF 3085 and MF 3095 from 1990, and New Holland 6635 and 7635 from the early 1990s through the late 1990s.
• Match the part number MG292 and confirm the mounting, pulley, voltage and rotation details against the original alternator before ordering.

Application and Buying Notes

The most reliable way to buy an alternator is to compare the part number MG292 with the original unit, then confirm the physical details. In this case, the key checkpoints are 12V, 100A output, internal regulator, clockwise rotation, and the double pulley with a 73mm outside diameter.

Mounting measurements matter just as much as electrical output. This alternator uses a twin leg mount, 82mm inside mounting legs, 82.0 mounting bores distance, 149mm mount centre-to-centre, and an M8x1.25 adjusting hole. If those dimensions do not match the existing alternator, the unit may not install correctly.

The insulated ground and insulated return details should also be checked against the application. These features can affect how the alternator is connected in the system, so it is best to confirm the original arrangement rather than assuming interchange from appearance alone.

If you are replacing a worn alternator, compare the pulley section, distance from pulley to alternator, and the number of pulleys fitted. The listed AA pulley section, 38.3 distance from pulley to alternator, and double pulley setup are specific details that should be matched to avoid a mismatch during installation.

Fitment references are helpful, but they should be treated as guidance rather than a substitute for inspection of the old part. Machinery and tractor applications can vary, so use the application details together with the physical measurements and MG292 part number to make the final check.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MG292 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type ALTERNATOR, Unit of Measure EACH, Warranty One Year, Inside Mounting Legs 82mm, Pivot Hole Diameter 8, Pulley Outside Diameter 73mm, Regulator Type Internal, Suits Unit Make Mahle, Note Dust Proof. Insulated Ground, Mount Cnt to Cnt 149mm.

Additional published details for cross-checking include Insulated Return Yes, Pulleys with double pulley, Mounting points diameter 86.0, Distance from pulley to the alternator 38.3, Packaging width 18.60, Net Weight 5717, Product Group 1 ROTATING ELECTRICAL, Part No. MG292, Brand MAHLE, Description Mahle Alternator 12V 100A.

Mahle Alternator 12V 100A. Part number MG292 should be checked first. Listed voltage is 12. Listed output rating is 100. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Mount style is Twin Leg. Regulator type is Internal. Pulley configuration is AA. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number MG292, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a alternator in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 and output 100 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Please confirm compatibility using part number MG292, the 12V 100A specification, the twin leg mount dimensions, pulley details, rotation, and your original alternator’s application before ordering.

FAQ

What is the part number for this MAHLE alternator?

The part number listed is MG292.

What voltage and output does this alternator have?

It is a 12V alternator with a 100A charge current and 100A power rating.

Does this alternator have an internal regulator?

Yes. The regulator type is listed as internal.

What pulley setup is fitted to this alternator?

It is listed with a double pulley, a 73mm pulley outside diameter, and an AA pulley section.

What mounting measurements are provided?

The listed mounting details include twin leg mount, 82mm inside mounting legs, 82.0 mounting bores distance, 149mm mount centre-to-centre, and an M8x1.25 adjusting hole.

Which applications are referenced in the fitment data?

The supplied fitment references include Caterpillar 216B, 216B2, 226B, 232B, 232B2, 242B, 901B, CB-334E, CB334D and CB335D, plus Massey Ferguson MF 3085 and MF 3095, and New Holland 6635 and 7635.
