OEX Starter Motor 24V 11TH CW Bosch Style BXS9025

The OEX Starter Motor 24V 11Th CW Bosch Style, part number BXS9025, is a new starter motor with an 11-tooth pinion, clockwise rotation and a 6.6kW power rating. It is listed as a Bosch style unit and suits Bosch applications, with a 24V electrical setup for heavier vehicle and equipment use.

Key physical details for checking a match include a 3-hole starter mount, 89mm flange diameter, 127mm mount centres A, 90mm mount centres B and 90mm mount centres C. The unit measures 406.5mm overall length, has an 11mm mount hole diameter, a 41mm pinion diameter and 48mm pinion at rest.

This starter motor is identified as new, with dry clutch specification and a weight of 19kg. It is an OEX product sourced from ISO certified factories and backed by a 3yr passenger / 1yr commercial warranty, which gives buyers a practical benchmark when comparing against the original unit or an existing replacement.

The listed note is KB Series, and the product is grouped under rotating electrical and starter motors. Those details matter when you are matching a replacement for a commercial machine, truck, or other 24V Bosch style application where tooth count, rotation and mounting pattern must line up exactly.

Key Features

• 24V starter motor
• 11-tooth pinion
• Clockwise rotation
• 6.6kW power rating
• Bosch style / suits Bosch unit make
• New unit

Specifications

• Brand: OEX
• Part No.: BXS9025
• Type: Starter Motor
• Unit of measure: Each
• Voltage: 24V
• Number of teeth: 11
• Rotation: CW
• Power rating: 6.6kW

Supported fitment applications

• VOLVO
• VOLVO CONSTRUCTION
• VOLVO CONSTRUCTION EC340
• VOLVO CONSTRUCTION G740B
• VOLVO CONSTRUCTION G746B
• VOLVO CONSTRUCTION G780B
• VOLVO CONSTRUCTION L110E
• VOLVO CONSTRUCTION L120C

Application and Buying Notes

Before ordering, compare the part number BXS9025, the 24V rating, 11-tooth pinion and clockwise rotation against the unit being replaced. These are the first checks that help separate a correct Bosch style starter from one that may look similar but will not suit the application.

Mounting dimensions also need to be checked carefully. This starter uses a 3-hole mount with 89mm flange diameter, 127mm mount centres A, 90mm mount centres B and 90mm mount centres C, plus 11mm mount hole diameter. If any of those measurements differ from the existing starter, fitment should be rechecked before purchase.

The overall length of 406.5mm, pinion diameter of 41mm and pinion at rest measurement of 48mm are useful when comparing against the removed starter or service information. In rotating electrical parts, those details are just as important as the electrical rating because physical clearances and engagement position must suit the machine.

This unit is listed as new and dry, with a 6.6kW power rating and 19kg weight. Those details help set expectations when comparing to an original starter or a previous replacement, especially on equipment where the starter needs to match both the mounting pattern and the required electrical output.

The fitment list includes Volvo, Volvo Construction, Volvo D12A, Volvo F10, Volvo F12, Volvo FH12, Volvo FL10 and Volvo Marine/Penta applications. Even so, the correct way to confirm suitability is to match the part number and the actual application details from the machine or original starter, rather than relying on model name alone.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number BXS9025 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 127mm, Mount Centres C 90mm, Number of Teeth 11, Pinion at Rest 48mm, Power Rating 6.6kW, Suits Unit Make Bosch, Note KB Series.

Additional published details for cross-checking include New / Reman. New, Wet / Dry Clutch Dry, Product Group 2 STARTER MOTORS, Part No. BXS9025, Brand OEX, Description OEX Starter Motor 24V 11Th CW Bosch Style, Flange Diameter 89mm, Mount Centres B 90mm, Mount Hole Diameter 11.

OEX Starter Motor 24V 11Th CW Bosch Style. Part number BXS9025 should be checked first. Listed voltage is 24. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number BXS9025, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 24 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include VOLVO CONSTRUCTION, VOLVO CONSTRUCTION EC340, VOLVO CONSTRUCTION EC340 1999, VOLVO CONSTRUCTION G740B. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm compatibility by checking part number BXS9025, 24V electrical requirement, 11-tooth clockwise Bosch style configuration, and all mounting dimensions against the original unit and vehicle or equipment application details before ordering.

FAQ

What is the part number for this starter motor?

The part number is BXS9025.

Is this a 12V or 24V starter motor?

It is a 24V starter motor.

How many teeth does the pinion have?

The pinion has 11 teeth.

What is the rotation direction?

The starter motor rotates clockwise (CW).

Is this unit new or remanufactured?

It is listed as new.

Which applications are listed for this starter motor?

The listed applications include Volvo, Volvo Construction, Volvo D12A, Volvo F10, Volvo F12, Volvo FH12, Volvo FL10 and Volvo Marine/Penta, among others in the provided fitment list. Final confirmation should still be made against the part number and the original unit.
