OEX Starter Motor 12V 10 Tooth CCW United Technologies Style SMX036

The OEX Starter Motor SMX036 is a 12V starter motor in United Technologies style, with 10 teeth, counter-clockwise rotation, and a 0.4kW power rating. It is supplied as a new unit and is listed as a dry clutch application, with a cradle starter mount type.

This unit has a 63mm mount centre measurement, a 44mm flange diameter, an overall length of 198mm, and a 30mm pinion diameter. The pinion at rest measures 38mm, and the unit weight is 2.32kg. Those measurements matter when matching the replacement to the existing starter arrangement.

OEX describes its products as being sourced from market leading original equipment manufacturers and aftermarket suppliers, with manufacturing from ISO certified factories. The starter motor is backed by a 3 year passenger and 1 year commercial warranty.

Key Features

• 12V starter motor
• 10 tooth pinion
• Counter-clockwise rotation
• New unit
• Dry clutch application
• Cradle starter mount type

Specifications

• Brand: OEX
• Part No.: SMX036
• Type: Starter Motor
• Voltage: 12V
• Rotation: CCW
• Number of Teeth: 10
• Power Rating: 0.4kW
• Mount Centres A: 63mm

Fitment information supplied

• Suits unit make: United Technologies
• Fitment references include TORO WHEELHORSE applications
• Listed application references include TORO WHEELHORSE 1988 through 1998

Application and Buying Notes

Before ordering, compare the part number SMX036 with the starter already fitted to the machine. The key physical checks on this unit are the 12V rating, 10 tooth pinion, CCW rotation, 63mm mount centres, 44mm flange diameter, and 198mm overall length. If any of those details differ from your current starter, stop and verify the application before fitting.

The starter is listed for United Technologies style use and references TORO WHEELHORSE applications, including model year references from 1988 to 1998. Even with those references, starter fitment should still be confirmed against the machine’s existing starter dimensions, pinion count, and rotation direction, because small differences in mounting or gear engagement can prevent a correct installation.

The 0.4kW power rating, 30mm pinion diameter, and 38mm pinion-at-rest dimension are useful checks when comparing physical compatibility. The cradle mount style and dry clutch listing are also important, particularly where the existing arrangement uses a specific mount form or flywheel engagement setup.

For commercial use, the warranty is listed as 1 year, while passenger use is listed as 3 years. Keep proof of purchase and confirm the intended application before installation, as warranty terms and correct fitment both depend on using the starter in the right vehicle or machine setup.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number SMX036 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 63mm, Overall Length 198mm, Pinion Diameter 30mm, Rotation CCW, Voltage 12, New / Reman. New, Wet / Dry Clutch Dry.

Additional published details for cross-checking include Product Group 2 STARTER MOTORS, Part No. SMX036, Brand OEX, Description OEX Starter Motor 12V 10Th CCW United Tech Style, Flange Diameter 44mm, Number of Teeth 10, Pinion at Rest 38mm, Power Rating .4kW, Suits Unit Make United Technologies.

OEX Starter Motor 12V 10Th CCW United Tech Style. Part number SMX036 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number SMX036, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include TORO WHEELHORSE, TORO WHEELHORSE 1988, TORO WHEELHORSE 1989, TORO WHEELHORSE 1990. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm fitment by matching part number SMX036, the 12V specification, 10 tooth count, CCW rotation, and the listed mounting dimensions against the starter being replaced and the machine application.

FAQ

What is the part number for this starter motor?

The part number is SMX036. For this listing, part number SMX036 is the main reference point. Listed voltage is 12. Published fitment references include TORO WHEELHORSE, TORO WHEELHORSE 1988, TORO WHEELHORSE 1989. These details should still be checked against the original unit before ordering.

What voltage does this starter motor use?

It is a 12V starter motor. For this listing, part number SMX036 is the main reference point. Listed voltage is 12. Published fitment references include TORO WHEELHORSE, TORO WHEELHORSE 1988, TORO WHEELHORSE 1989. These details should still be checked against the original unit before ordering.

What rotation does this starter motor have?

It is counter-clockwise (CCW). For this listing, part number SMX036 is the main reference point. Listed voltage is 12. Published fitment references include TORO WHEELHORSE, TORO WHEELHORSE 1988, TORO WHEELHORSE 1989. These details should still be checked against the original unit before ordering.

What are the main mounting dimensions?

The listed mount centres are 63mm, the flange diameter is 44mm, and the overall length is 198mm. For this listing, part number SMX036 is the main reference point. Listed voltage is 12. Published fitment references include TORO WHEELHORSE, TORO WHEELHORSE 1988, TORO WHEELHORSE 1989. These details should still be checked against the original unit before ordering.

Which unit make is listed for this starter motor?

The listed unit make is United Technologies. For this listing, part number SMX036 is the main reference point. Listed voltage is 12. Published fitment references include TORO WHEELHORSE, TORO WHEELHORSE 1988, TORO WHEELHORSE 1989. These details should still be checked against the original unit before ordering.

What warranty is provided?

The warranty is listed as 3 years for passenger use and 1 year for commercial use. For this listing, part number SMX036 is the main reference point. Listed voltage is 12. Published fitment references include TORO WHEELHORSE, TORO WHEELHORSE 1988, TORO WHEELHORSE 1989. These details should still be checked against the original unit before ordering.
