Prestolite Alternator 24V 150A 8SC3160V

The Prestolite 24V 150A alternator, part number 8SC3160V, is a new unit with an internal regulator and insulated return. It is listed as a twin leg mount alternator with 101mm inside mounting legs, 212mm mount centre to centre, and a 22mm shaft diameter.

This alternator is rated at 150 amps and is supplied as each unit. The listed note identifies it as suitable for large frame loadhandler applications with ignition excite (R) and warning light connections, and it is described as an above ground unit.

A specific application is supplied for Komatsu PC3000 with SSA12V159 engine. The fitment information also references a wider range of heavy equipment applications, so matching the part number, mounting dimensions, voltage, and electrical arrangement remains the safest way to confirm suitability before purchase.

Key Features

• 24V alternator with 150A output
• Prestolite part number 8SC3160V
• New unit with internal regulator
• Insulated return configuration
• Twin leg alternator mount
• Above ground application

Specifications

• Voltage: 24V
• Power rating: 150 amp
• Mount type: Twin leg
• Inside mounting legs: 101mm
• Mount centre to centre: 212mm
• Shaft diameter: 22mm
• Adjusting hole diameter: 1/2 UNC
• Pivot hole diameter: 13mm

Fitment and application notes

• Komatsu PC3000 with SSA12V159 engine
• Fitment references also include Komatsu 830E, Komatsu 930E, Komatsu PC3000-6, Komatsu PC5500 and Komatsu PC5500-6
• Other referenced application groups include Bucyrus SKSS, Bucyrus SKSW, Caterpillar MD6250, Caterpillar MD6420, Euclid R130, Euclid R150, Hitachi EX1900-5, Terex O&K RH200 and Volvo D12C

Application and Buying Notes

When checking this alternator, start with the core identifiers: Prestolite, part number 8SC3160V, 24V, and 150A. The mounting layout is also important, with twin leg mounting, 101mm inside mounting legs, and 212mm centre to centre, so the physical fit needs to line up with the existing unit or the machine’s alternator bracket arrangement.

The electrical setup should be matched carefully. This unit is listed with an internal regulator, insulated return, ignition excite (R), and warning light connection notes. Those details matter because they affect how the alternator is wired and how it interfaces with the machine’s charging circuit.

The shaft and hole dimensions are also worth confirming before ordering. The shaft diameter is 22mm, the adjusting hole is 1/2 UNC, and the pivot hole is 13mm. If your existing alternator differs in these areas, the unit may not be a direct swap even if the machine family appears similar.

For the clearest match, compare the part number first, then confirm the application details and measurements against the machine. The supplied note specifically mentions Komatsu PC3000 with SSA12V159 engine, and the broader application references should be treated as a guide rather than a substitute for checking the exact machine build and alternator arrangement.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number 8SC3160V helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type ALTERNATOR, Unit of Measure EACH, Warranty One Year, Inside Mounting Legs 101mm, Power Rating (Amp) 150, Shaft Diameter 22mm, Voltage 24, Alternator Mount Twin Leg, New / Reman. New, Shaft Dimension 22.

Additional published details for cross-checking include Product Group 2 ALTERNATORS, Part No. 8SC3160V, Brand PRESTOLITE, Description Prestolite Alternator 24V 150A, Adjusting Hole Diameter 1/2 UNC, Pivot Hole Diameter 13, Regulator Type Internal, Suits Unit Make Prestolite, Note Insulated return. Large frame loadhandler (Ign) Ignition excite (R) Warning light.

Prestolite Alternator 24V 150A. Part number 8SC3160V should be checked first. Listed voltage is 24. Listed output rating is 150. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Mount style is Twin Leg. Regulator type is Internal. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number 8SC3160V, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a alternator in workshop, fleet, trade, agricultural, or construction service, the listed voltage 24 and output 150 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Please confirm fitment by matching part number 8SC3160V, 24V rating, 150A output, mounting dimensions, shaft size, and electrical configuration against your existing alternator and machine application before ordering.

FAQ

What is the part number for this alternator?

The part number listed is 8SC3160V. For this listing, part number 8SC3160V is the main reference point. Listed voltage is 24. Listed output rating is 150. Published fitment references include BUCYRUS SKSS, BUCYRUS SKSS 2011, BUCYRUS SKSW. These details should still be checked against the original unit before ordering.

What voltage and output does it have?

It is a 24V alternator with a 150 amp power rating. For this listing, part number 8SC3160V is the main reference point. Listed voltage is 24. Listed output rating is 150. Published fitment references include BUCYRUS SKSS, BUCYRUS SKSS 2011, BUCYRUS SKSW. These details should still be checked against the original unit before ordering.

Is this a new or remanufactured unit?

It is listed as a new alternator. For this listing, part number 8SC3160V is the main reference point. Listed voltage is 24. Listed output rating is 150. Published fitment references include BUCYRUS SKSS, BUCYRUS SKSS 2011, BUCYRUS SKSW. These details should still be checked against the original unit before ordering.

What mounting style does it use?

It uses a twin leg mount and has 101mm inside mounting legs with 212mm mount centre to centre. For this listing, part number 8SC3160V is the main reference point. Listed voltage is 24. Listed output rating is 150. Published fitment references include BUCYRUS SKSS, BUCYRUS SKSS 2011, BUCYRUS SKSW. These details should still be checked against the original unit before ordering.

Does it have an internal regulator?

Yes. The regulator type is listed as internal. For this listing, part number 8SC3160V is the main reference point. Listed voltage is 24. Listed output rating is 150. Published fitment references include BUCYRUS SKSS, BUCYRUS SKSS 2011, BUCYRUS SKSW. These details should still be checked against the original unit before ordering.

What application is specifically noted?

The listed specific application is Komatsu PC3000 with SSA12V159 engine. For this listing, part number 8SC3160V is the main reference point. Listed voltage is 24. Listed output rating is 150. Published fitment references include BUCYRUS SKSS, BUCYRUS SKSS 2011, BUCYRUS SKSW. These details should still be checked against the original unit before ordering.
