Prestolite Alternator 24V 150A New – Part No. 8SC3200V

This Prestolite alternator is a new 24V unit with a 150A power rating, part number 8SC3200V. It is listed as an above ground alternator with an internal regulator and insulated return, and it is supplied as each.

The unit is identified for Prestolite applications and uses a twin leg alternator mount with 101mm inside mounting legs, 212mm mount centre-to-centre, a 13mm pivot hole diameter, and a 1/2 UNC adjusting hole diameter. The shaft diameter is 22mm and the alternator weighs 12.94kg.

The notes state this is a batteryless alternator for large frame loadhandler applications, with IGN excite and R = phase. It is designed for vehicle refrigeration units that require constant maximum output to keep evaporator and condenser motors running, and it is not intended for battery type applications.

Key Features

• New alternator
• 24V system
• 150A output
• Internal regulator
• Insulated return
• Above ground design

Specifications

• Brand: Prestolite
• Product type: Alternator
• Voltage: 24V
• Power rating: 150A
• Part number: 8SC3200V
• New / remanufactured: New
• Warranty: One year
• Alternator mount: Twin leg

Application and Buying Notes

Check the part number carefully before ordering. This alternator is identified as 8SC3200V and is a 24V, 150A Prestolite unit with a twin leg mount, so the mounting style, shaft size, and hole sizes need to match the vehicle or equipment arrangement you are working with.

The notes specify batteryless use only, and that it is intended for large frame loadhandler and vehicle refrigeration applications that need constant maximum output. It should not be used with batteries, so confirm the electrical setup before fitting. The internal regulator and insulated return are important details when comparing it with the original unit.

If you are replacing an existing alternator, compare the 101mm inside mounting legs, 212mm centre-to-centre mounting dimension, 13mm pivot hole, 1/2 UNC adjusting hole, and 22mm shaft diameter. These measurements are often the quickest way to confirm whether the unit will physically suit the application.

The one-year warranty applies to the unit as supplied, but warranty coverage does not replace the need to confirm correct application first. For batteryless refrigeration or loadhandler use, also check the associated components such as capacitors and resistors, as their performance can change over time with temperature and environmental conditions.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number 8SC3200V helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type ALTERNATOR, Unit of Measure EACH, Warranty One Year, Inside Mounting Legs 101mm, Power Rating (Amp) 150, Shaft Diameter 22mm, Voltage 24, Alternator Mount Twin Leg, New / Reman. New, Weight 12.94kg.

Additional published details for cross-checking include Product Group 1 ROTATING ELECTRICAL, Part No. 8SC3200V, Brand PRESTOLITE, Description Prestolite Alternator 24V 150A - REFER NOTES, Adjusting Hole Diameter 1/2 UNC, Pivot Hole Diameter 13, Regulator Type Internal, Suits Unit Make Prestolite, Note Batteryless. Large frame loadhandler. IGN Excite. R = Phase Batteryless alternators are designed to be used on vehicle refrigeration units that require constant maximum output to keep their evaporator and condenser motor running. They are not designed for any battery type application and should not be used with batteries. Note: For any electric circuit, the performance of the components such as capacitors and resistors that are connected to this alternator are naturally affected, over time, by temperature & environmental changes. You should consult your supplier of these components as to the recommend replacement periods for your particular situation, along with the safe process of removal and disposal, Mount Cnt to Cnt 212mm.

Prestolite Alternator 24V 150A - REFER NOTES. Part number 8SC3200V should be checked first. Listed voltage is 24. Listed output rating is 150. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Mount style is Twin Leg. Regulator type is Internal. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number 8SC3200V, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a alternator in workshop, fleet, trade, agricultural, or construction service, the listed voltage 24 and output 150 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Where no verified application list is available, the part number, mounting details, connector style, and published specifications should be used as the primary selection criteria.

In the absence of a verified fitment list, the safest approach is to compare the removed unit directly with the listed product details. That includes checking the housing style, pulley layout, regulator arrangement, and any visible identification numbers before supply is approved.

The listed warranty is One Year. Warranty terms should be considered alongside correct application and part identification, as warranty does not replace fitment confirmation.

Compatibility note: Please confirm fitment by matching the part number 8SC3200V, the 24V 150A specification, the twin leg mounting dimensions, and the batteryless application details before purchase.

FAQ

What is the part number for this alternator?

The part number listed is 8SC3200V.

Is this alternator new or remanufactured?

It is listed as new.

What voltage and amperage does it have?

It is a 24V alternator with a 150A power rating.

Does it have an internal regulator?

Yes. The regulator type is listed as internal.

Can this alternator be used with batteries?

No. The notes state it is a batteryless alternator and is not designed for any battery type application.

What mounting details should be checked before ordering?

Check the twin leg mount, 101mm inside mounting legs, 212mm mount centre-to-centre, 13mm pivot hole diameter, and 1/2 UNC adjusting hole diameter.
