OEX Starter Motor 12V 9T CW Valeo VXS951

The OEX Starter Motor VXS951 is a new 12V starter motor with clockwise rotation, 9 teeth, and a 3kW power rating. It suits Valeo applications and is noted as suitable for a Hyundai D4BB engine forklift, so matching the part number and application details is important before purchase.

Key dimensions on this unit include 145mm mount centres A, 115mm mount centres B, 95mm mount centres C, a 100mm flange diameter, and a 240mm overall length. The starter uses a 3 hole mount, has a 13mm mount hole diameter, and weighs 5.72kg.

The pinion specifications are also clear: 35mm pinion diameter and 30mm pinion at rest. As with any starter motor, those measurements matter because the physical fit, pinion engagement, and mounting pattern must line up with the existing unit or the application it is being matched to.

Key Features

• 12V starter motor
• 9 tooth pinion
• Clockwise rotation
• 3kW power rating
• New unit
• Suits Valeo applications

Specifications

• Part No.: VXS951
• Brand: OEX
• Product type: Starter motor
• Voltage: 12V
• Rotation: CW
• Number of teeth: 9
• Power rating: 3kW
• New / Reman.: New

Application and Buying Notes

Before ordering, compare the part number VXS951 and the listed application for a Hyundai D4BB engine forklift with your existing starter. The unit is specified as a Valeo suit, so that make and the mounting layout need to align with the replacement starter already fitted.

The mounting measurements are often the quickest way to confirm whether a starter will physically suit. This unit is listed with 145mm, 115mm, and 95mm mount centres, a 100mm flange diameter, a 3 hole starter mount, and 13mm mount hole diameter, so those figures should be checked against the removed part or workshop records.

The electrical and drive details also need to match. This starter is 12V, clockwise rotation, with 9 teeth and a 3kW rating. If your application uses a different voltage, rotation, tooth count, or pinion size, it should not be assumed to fit or operate correctly.

For the best result, confirm the overall length of 240mm, the pinion diameter of 35mm, and the pinion at rest measurement of 30mm before fitting. Those dimensions help avoid mismatch at the mounting face and the ring gear engagement point, especially where the existing starter has been replaced previously.

The unit is new and carries a 3yr Passenger 1yr Commercial warranty, but warranty cover does not replace fitment checking. The safest approach is to verify the starter against the removed unit, the vehicle or machine application, and any service information you already have on hand.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number VXS951 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 145mm, Mount Centres C 95mm, Number of Teeth 9, Pinion at Rest 30mm, Power Rating 3kW, Suits Unit Make Valeo, Note Suits Hyundai D4BB engine forklift.

Additional published details for cross-checking include Starter Mount Type 3 Hole, Weight 5.72kg, Product Group 1 ROTATING ELECTRICAL, Part No. VXS951, Brand OEX, Description OEX Starter Motor 12V 9Th CW Valeo, Flange Diameter 100mm, Mount Centres B 115mm, Mount Hole Diameter 13, Overall Length 240mm.

OEX Starter Motor 12V 9Th CW Valeo. Part number VXS951 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number VXS951, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Where no verified application list is available, the part number, mounting details, connector style, and published specifications should be used as the primary selection criteria.

Compatibility note: Confirm compatibility using the part number VXS951, the 12V clockwise 9 tooth specification, the Valeo suit, and the listed mounting dimensions before ordering.

FAQ

What is the part number for this starter motor?

The part number is VXS951. For this listing, part number VXS951 is the main reference point. Listed voltage is 12. These details should still be checked against the original unit before ordering.

What voltage does this starter motor use?

It is a 12V starter motor. For this listing, part number VXS951 is the main reference point. Listed voltage is 12. These details should still be checked against the original unit before ordering.

Is this starter motor new or remanufactured?

It is listed as new. For this listing, part number VXS951 is the main reference point. Listed voltage is 12. These details should still be checked against the original unit before ordering.

What rotation does this starter motor have?

It is clockwise rotation, shown as CW. For this listing, part number VXS951 is the main reference point. Listed voltage is 12. These details should still be checked against the original unit before ordering.

What application is noted for this starter motor?

It is noted as suiting a Hyundai D4BB engine forklift and Valeo applications. For this listing, part number VXS951 is the main reference point. Listed voltage is 12. These details should still be checked against the original unit before ordering.

What warranty is listed for this starter motor?

The listed warranty is 3yr Passenger 1yr Commercial. For this listing, part number VXS951 is the main reference point. Listed voltage is 12. These details should still be checked against the original unit before ordering.
