Genuine Starter Motor 24V 9 Tooth CW Delco 28MT Style DXS9111

This Genuine Products starter motor is a 24V, 9 tooth, clockwise unit built in Delco 28MT style, with part number DXS9111. It is a new starter motor sold each, and the key identification points are the 24 volt system, CW rotation, 9 teeth, and 3 hole starter mount type.

It carries a 3.5kW power rating and suits Delco unit applications. Physical dimensions and mount details are listed as 127mm mount centres A, 90mm mount centres B, 90mm mount centres C, 89mm flange diameter, 11mm mount hole diameter, 343mm overall length, 35mm pinion diameter, and 45mm pinion at rest.

For buyers comparing replacements, the important match points are the part number DXS9111, the Delco 28MT style reference, and the 24V clockwise configuration. Weight is listed at 8.82kg, which can help when checking against the removed unit and confirming you are comparing the same style starter.

Key Features

• 24V starter motor
• 9 tooth pinion
• Clockwise rotation (CW)
• Delco 28MT style
• 3 hole starter mount type
• 3.5kW power rating

Specifications

• Part number: DXS9111
• Brand: Genuine Products
• Type: Starter motor
• Voltage: 24V
• Rotation: CW
• Number of teeth: 9
• Power rating: 3.5kW
• Suits unit make: Delco

Fitment guidance

• Fitment is not fully verified for individual vehicle models here.
• Known application groups supplied include Mercedes-Benz Atego, Atego 2, L Series, OF, OH, Touro (O 500), and Vario.
• Known application groups supplied also include Normet Charmec, Normet Utim ec, and Normet Variomec.
• If your machine or vehicle is not in those groups, check the removed starter against the part number DXS9111 and the listed dimensions before ordering.

Application and Buying Notes

The safest way to confirm this starter is by matching the part number DXS9111, the 24V electrical system, and the clockwise rotation. The starter is a Delco 28MT style unit with 9 teeth, so a mismatch in tooth count or rotation can mean the part is not suitable even if the housing looks similar.

Physical checks matter as much as the electrical details. The listed 3 hole mount type, 127mm mount centres A, 90mm mount centres B, 90mm mount centres C, 89mm flange diameter, 11mm mount hole diameter, and 343mm overall length give you useful comparison points against the original starter before installation.

The 3.5kW rating and 35mm pinion diameter are important when comparing like-for-like replacements. If the removed unit is marked differently, or if the application uses a different Delco starter style, do not rely on appearance alone. Measure the existing starter and compare the mount pattern and overall length to reduce the risk of ordering the wrong unit.

This starter is listed as new and has a warranty of 3 years for passenger use and 1 year for commercial use. The difference matters because commercial applications often see more heat, vibration, and duty cycle demand, so correct identification and installation remain essential regardless of warranty coverage.

The product is described as built to withstand the harshest environments, but that should not be read as a substitute for fitment checking. Confirm the voltage, tooth count, rotation, mount centres, and the Delco application style together, particularly if the vehicle or machine is from the Mercedes-Benz or Normet groups noted in the fitment information.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXS9111 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 127mm, Mount Centres C 90mm, Number of Teeth 9, Pinion at Rest 45mm, Power Rating 3.5kW, Suits Unit Make Delco, New / Reman. New.

Additional published details for cross-checking include Wet / Dry Clutch Dry, Product Group 2 STARTER MOTORS, Part No. DXS9111, Brand GENUINE PRODUCTS, Description Genuine Starter Motor 24V 9Th CW Delco 28MT Style, Flange Diameter 89mm, Mount Centres B 90mm, Mount Hole Diameter 11, Overall Length 343mm.

Genuine Starter Motor 24V 9Th CW Delco 28MT Style. Part number DXS9111 should be checked first. Listed voltage is 24. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number DXS9111, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 24 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include MERCEDES-BENZ ATEGO, MERCEDES-BENZ ATEGO 1998, MERCEDES-BENZ ATEGO 1999, MERCEDES-BENZ ATEGO 2, NORMET CHARMEC, NORMET CHARMEC 1980. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

The listed warranty is 3yr Passenger 1yr Commercial. Warranty terms should be considered alongside correct application and part identification, as warranty does not replace fitment confirmation.

Compatibility note: Please confirm fitment using part number DXS9111, the Delco 28MT style reference, the 24V CW configuration, and the listed mount and dimension measurements before purchase or installation.

FAQ

What is the part number for this starter motor?

The part number listed is DXS9111.

What voltage is this starter motor?

It is a 24V starter motor.

Is the rotation clockwise or anti-clockwise?

The rotation is clockwise (CW).

How many teeth does the pinion have?

The pinion has 9 teeth.

What style or unit family does it suit?

It is listed as Delco 28MT style and suits Delco unit make applications.

What warranty is listed?

The listed warranty is 3 years for passenger use and 1 year for commercial use.
