OEX Starter Motor 12V 9 Tooth CW Bosch Style BXS0154

This OEX starter motor is a new 12V unit with clockwise rotation, a 9 tooth pinion, and a 1.1kW power rating. It is listed as Bosch style and suited to Bosch applications, with part number BXS0154 for identification when matching the correct replacement.

Key dimensions are supplied for checking the physical fit before purchase: mount centres A 105mm, B 92mm and C 74mm, with a 3 hole starter mount, 66mm flange diameter, 32mm nose cone length and 208mm overall length. The pinion diameter is 26mm and the pinion at rest is 0mm.

OEX lists this starter motor as a new rotating electrical component with a unit weight of 3.0kg. The product is backed by a 3 year passenger and 1 year commercial warranty, which is useful to note when comparing application and duty cycle expectations for different vehicles.

Key Features

• 12V starter motor
• Clockwise rotation
• 9 tooth pinion
• Bosch style unit
• New starter motor
• 3 hole starter mount

Specifications

• Brand: OEX
• Product type: Starter motor
• Part No.: BXS0154
• Voltage: 12V
• Rotation: CW
• Number of teeth: 9
• Power rating: 1.1kW
• New / remanufactured: New

Vehicle fitment notes

• Fitment is listed against Renault applications.
• Supported makes and models include Renault Clio, Renault Fuego, Renault Grand Scénic, Renault Laguna, Renault Megane and Renault Scénic.
• The fitment preview includes Renault Clio model years from 2000 through 2010.
• Always confirm the exact vehicle application against the part number BXS0154 and the starter dimensions before ordering.

Application and Buying Notes

When checking whether this starter motor is the correct one, start with the part number BXS0154 and then compare the physical measurements. The 3 hole mounting pattern, 105mm/92mm/74mm mount centres, 66mm flange diameter and 208mm overall length are the most useful checkpoints when matching an existing unit.

The electrical and drive details also matter. This is a 12V clockwise starter with a 9 tooth pinion, 26mm pinion diameter and 1.1kW power rating. If the vehicle’s original starter differs in rotation, tooth count or power output, it should not be assumed to interchange.

Because this listing identifies Bosch style and suits Bosch applications, it is important to confirm the existing starter make and the vehicle application together. Fitment is shown for Renault Clio, Fuego, Grand Scénic, Laguna, Megane and Scénic, but the safest approach is still to compare the old unit’s measurements and mounting arrangement before purchase.

The product is new and carries a 3 year passenger / 1 year commercial warranty. That warranty is a helpful reference point, but it does not replace checking whether the vehicle uses a dry clutch starter application and whether the mount hole size M10x1.5 / 12 matches the vehicle’s original setup.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number BXS0154 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 105mm, Mount Centres C 74mm, Nose Cone Length 32mm, Overall Length 208mm, Pinion Diameter 26mm, Rotation CW, Voltage 12.

Additional published details for cross-checking include Starter Mount Type 3 Hole, Weight 3.0kg, Product Group 1 ROTATING ELECTRICAL, Part No. BXS0154, Brand OEX, Description OEX Starter Motor 12V 9Th CW Bosch Style, Flange Diameter 66mm, Mount Centres B 92mm, Mount Hole Diameter M10x1.5 / 12, Number of Teeth 9.

OEX Starter Motor 12V 9Th CW Bosch Style. Part number BXS0154 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number BXS0154, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include RENAULT CLIO, RENAULT CLIO 2000, RENAULT CLIO 2001, RENAULT CLIO 2002. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm compatibility using part number BXS0154, the 12V clockwise Bosch style specification, and the supplied mounting and dimensional details before ordering. Vehicle fitment should be verified against the existing starter and application data, especially on Renault models.

FAQ

What type of starter motor is this?

It is a new OEX starter motor, 12V, clockwise rotation, Bosch style, with a 9 tooth pinion and 1.1kW power rating. For this listing, part number BXS0154 is the main reference point. Listed voltage is 12. Published fitment references include RENAULT CLIO, RENAULT CLIO 2000, RENAULT CLIO 2001. These details should still be checked against the original unit before ordering.

What is the part number?

The part number is BXS0154. For this listing, part number BXS0154 is the main reference point. Listed voltage is 12. Published fitment references include RENAULT CLIO, RENAULT CLIO 2000, RENAULT CLIO 2001. These details should still be checked against the original unit before ordering.

Which vehicles are listed for fitment?

The fitment data lists Renault applications, including Clio, Fuego, Grand Scénic, Laguna, Megane and Scénic. A Renault Clio fitment preview also shows model years from 2000 through 2010. For this listing, part number BXS0154 is the main reference point. Listed voltage is 12. Published fitment references include RENAULT CLIO, RENAULT CLIO 2000, RENAULT CLIO 2001. These details should still be checked against the original unit before ordering.

What mounting details should I check?

Check the 3 hole starter mount, mount centres A 105mm, B 92mm and C 74mm, plus the 66mm flange diameter and 208mm overall length. For this listing, part number BXS0154 is the main reference point. Listed voltage is 12. Published fitment references include RENAULT CLIO, RENAULT CLIO 2000, RENAULT CLIO 2001. These details should still be checked against the original unit before ordering.

Is this unit new or remanufactured?

It is listed as new. For this listing, part number BXS0154 is the main reference point. Listed voltage is 12. Published fitment references include RENAULT CLIO, RENAULT CLIO 2000, RENAULT CLIO 2001. These details should still be checked against the original unit before ordering.

What warranty is supplied?

The warranty is 3 years for passenger use and 1 year for commercial use. For this listing, part number BXS0154 is the main reference point. Listed voltage is 12. Published fitment references include RENAULT CLIO, RENAULT CLIO 2000, RENAULT CLIO 2001. These details should still be checked against the original unit before ordering.
