OEX Starter Motor 12V 8TH CW Mitsubishi Style MXS2069

This OEX starter motor is a 12V unit with 8 teeth, clockwise rotation, and a 1.2kW power rating. It is listed under part number MXS2069 and is described as Mitsubishi style, with a 2 hole starter mount type and a dry wet/dry clutch classification of dry.

Key dimensions to check against the vehicle are a 108mm mount centre, 78mm flange diameter, 43mm nose cone length, 180mm overall length, and 24mm pinion diameter. The mount hole diameter is listed as 8.5 / 9, and the pinion at rest is 10mm.

The unit is new, supplied each, and carries OEX warranty cover of 3yr Passenger and 1yr Commercial. OEX states its products are sourced from market leading original equipment manufacturers and aftermarket suppliers, with production from ISO certified factories.

Key Features

• 12V starter motor
• 8 tooth pinion
• Clockwise rotation
• 1.2kW power rating
• 2 hole starter mount
• New unit

Specifications

• Brand: OEX
• Product type: Starter motor
• Part No.: MXS2069
• Voltage: 12V
• Power rating: 1.2kW
• Rotation: CW
• Number of teeth: 8
• Starter mount type: 2 hole

Confirmed fitment guidance

• Listed for Mitsubishi applications
• Fitment preview includes Mitsubishi Mirage
• Fitment preview includes Mitsubishi Mirage 2012
• Fitment preview includes Mitsubishi Mirage 2013
• Fitment preview includes Mitsubishi Mirage 2014
• Fitment preview includes Mitsubishi Mirage 2015
• Fitment preview includes Mitsubishi Mirage 2016
• Fitment preview includes Mitsubishi Mirage 2017

Application and Buying Notes

Before ordering, match the part number MXS2069 and confirm the starter is the same 12V, 8 tooth, clockwise unit with the same 2 hole mounting pattern. The physical dimensions are important here: 108mm mount centres, 78mm flange diameter, 43mm nose cone length, and 180mm overall length.

The mounting holes are listed at 8.5 / 9mm, which is worth checking carefully if the old starter shows wear, corrosion, or an altered mounting surface. The pinion diameter is 24mm and the pinion at rest is 10mm, so compare those measurements with the removed unit where possible.

This starter is described as Mitsubishi style and suited to Mitsubishi applications, with fitment preview data showing Mitsubishi Mirage across model years from 2012 through 2021. That said, Mirage applications can vary, so the safest approach is to verify the vehicle details, compare the old unit, and rely on the part number and dimensions rather than model name alone.

The unit is new and rated at 1.2kW, so it should be considered as a direct replacement only when the electrical specification, rotation, teeth count, and mounting layout all line up. If your existing starter has a different voltage, tooth count, or mount arrangement, do not assume it will interchange without checking first.

Warranty cover is listed as 3yr Passenger and 1yr Commercial. That makes it especially important to confirm the intended use of the vehicle before purchase, because the warranty period differs depending on whether the vehicle is used for passenger or commercial purposes.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MXS2069 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 108mm, Nose Cone Length 43mm, Overall Length 180mm, Pinion Diameter 24mm, Rotation CW, Voltage 12, Starter Mount Type 2 Hole.

Additional published details for cross-checking include Product Group 2 STARTER MOTORS, Part No. MXS2069, Brand OEX, Description OEX Starter Motor 12V 8Th CW Mitsubishi Style, Flange Diameter 78mm, Mount Hole Diameter 8.5 / 9, Number of Teeth 8, Pinion at Rest 10mm, Power Rating 1.2kW.

OEX Starter Motor 12V 8Th CW Mitsubishi Style. Part number MXS2069 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number MXS2069, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Confirm fitment by checking part number MXS2069, the 12V 8 tooth clockwise specification, and the full mounting and dimension details against the removed starter and vehicle application before ordering.

FAQ

What is the part number for this starter motor?

The part number listed is MXS2069. For this listing, part number MXS2069 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI MIRAGE, MITSUBISHI MIRAGE 2012, MITSUBISHI MIRAGE 2013. These details should still be checked against the original unit before ordering.

Is this starter motor 12V?

Yes. The voltage is listed as 12V. For this listing, part number MXS2069 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI MIRAGE, MITSUBISHI MIRAGE 2012, MITSUBISHI MIRAGE 2013. These details should still be checked against the original unit before ordering.

How many teeth does the pinion have?

It is listed with 8 teeth. For this listing, part number MXS2069 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI MIRAGE, MITSUBISHI MIRAGE 2012, MITSUBISHI MIRAGE 2013. These details should still be checked against the original unit before ordering.

What rotation does this starter motor use?

The rotation is listed as clockwise, or CW. For this listing, part number MXS2069 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI MIRAGE, MITSUBISHI MIRAGE 2012, MITSUBISHI MIRAGE 2013. These details should still be checked against the original unit before ordering.

What vehicle applications are shown?

The fitment preview shows Mitsubishi applications, including Mitsubishi Mirage from 2012 through 2021. For this listing, part number MXS2069 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI MIRAGE, MITSUBISHI MIRAGE 2012, MITSUBISHI MIRAGE 2013. These details should still be checked against the original unit before ordering.

What warranty is listed?

Warranty is listed as 3yr Passenger and 1yr Commercial. For this listing, part number MXS2069 is the main reference point. Listed voltage is 12. Published fitment references include MITSUBISHI MIRAGE, MITSUBISHI MIRAGE 2012, MITSUBISHI MIRAGE 2013. These details should still be checked against the original unit before ordering.
