OEX Starter Motor 24V 11 Tooth CW Denso Style DXS623

The OEX Starter Motor DXS623 is a new 24V starter motor with 11 teeth, clockwise rotation and a 4.5kW power rating. It is listed as a Denso style unit and suits Denso applications, so matching the part number and mounting details is the safest way to confirm the correct replacement.

This starter uses a 3 hole mount type with 132mm mount centres A, 115mm mount centres B and 115mm mount centres C. The flange diameter is 105mm and the mount hole diameter is 13mm, which are useful checks when comparing against the removed unit before ordering.

The pinion measures 40mm in diameter and sits 35mm at rest, and the unit is supplied new rather than remanufactured. OEX states the product is sourced from market leading original equipment manufacturers and aftermarket suppliers, made in ISO certified factories, and backed by a comprehensive nationwide warranty.

Key Features

• New 24V starter motor
• 11 tooth pinion
• Clockwise rotation
• Denso style, suits Denso unit make
• 3 hole mount type
• 4.5kW power rating

Specifications

• Brand: OEX
• Part number: DXS623
• Product type: Starter motor
• Voltage: 24V
• Rotation: CW
• Number of teeth: 11
• Power rating: 4.5kW
• Mount type: 3 hole

Verified fitment notes

• KOMATSU FD60-2
• KOMATSU FD60-2 1980
• NISSAN UD NET6A
• NISSAN UD NET6A 1988
• SUMITOMO FORKLIFT
• SUMITOMO FORKLIFT 1980
• UD NISSAN DIESEL C SERIES
• UD NISSAN DIESEL C SERIES 1980

Application and Buying Notes

This starter is identified by part number DXS623, and that identifier should be your first check when replacing a starter on a Denso application. The key matching points are 24V, 11 teeth, clockwise rotation and a 3 hole mount with 132mm, 115mm and 115mm mount centres.

Because starter fitment can vary even within similar machines, compare the flange diameter of 105mm, the 13mm mount hole diameter and the 40mm pinion diameter against the removed unit. These measurements are practical confirmation points when the original starter is available for side-by-side checking.

The listed applications include Komatsu FD60-2, Nissan UD NET6A, Sumitomo Forklift and UD Nissan Diesel C Series models across a range of years. That said, the safest purchasing method is still to confirm the part number, starter make, voltage and mounting pattern before fitting.

The unit is new and rated at 4.5kW, so it is intended as a direct replacement where the application matches the listed specifications. If your existing unit differs in tooth count, rotation direction, mounting style or voltage, stop and verify before ordering.

Warranty coverage is listed as 3 years for passenger use and 1 year for commercial use. For buyers in commercial or industrial equipment, it is worth confirming the operating context so the warranty class is understood before installation.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXS623 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 132mm, Mount Centres C 115mm, Number of Teeth 11, Pinion Diameter 40mm, Rotation CW, Voltage 24, New / Reman. New.

Additional published details for cross-checking include Wet / Dry Clutch Dry, Product Group 1 ROTATING ELECTRICAL, Part No. DXS623, Brand OEX, Description OEX Starter Motor 24V 11Th CW Denso Style, Flange Diameter 105mm, Mount Centres B 115mm, Mount Hole Diameter 13, Pinion at Rest 35mm, Power Rating 4.5kW.

OEX Starter Motor 24V 11Th CW Denso Style. Part number DXS623 should be checked first. Listed voltage is 24. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number DXS623, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 24 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Confirm fitment by checking DXS623, 24V, 11 tooth CW rotation, 3 hole mounting and the listed mount centres, flange diameter and pinion dimensions against the existing starter and the vehicle or machine application.

FAQ

What is the part number for this starter motor?

The part number is DXS623. For this listing, part number DXS623 is the main reference point. Listed voltage is 24. Published fitment references include KOMATSU FD60-2, KOMATSU FD60-2 1980, NISSAN UD NET6A. These details should still be checked against the original unit before ordering.

Is this starter motor new or remanufactured?

It is listed as new. For this listing, part number DXS623 is the main reference point. Listed voltage is 24. Published fitment references include KOMATSU FD60-2, KOMATSU FD60-2 1980, NISSAN UD NET6A. These details should still be checked against the original unit before ordering.

What voltage is this starter motor?

It is a 24V starter motor. For this listing, part number DXS623 is the main reference point. Listed voltage is 24. Published fitment references include KOMATSU FD60-2, KOMATSU FD60-2 1980, NISSAN UD NET6A. These details should still be checked against the original unit before ordering.

What rotation does this starter motor use?

It is clockwise rotation, noted as CW. For this listing, part number DXS623 is the main reference point. Listed voltage is 24. Published fitment references include KOMATSU FD60-2, KOMATSU FD60-2 1980, NISSAN UD NET6A. These details should still be checked against the original unit before ordering.

What are the mount centre measurements?

The mount centres are 132mm for A, 115mm for B and 115mm for C. For this listing, part number DXS623 is the main reference point. Listed voltage is 24. Published fitment references include KOMATSU FD60-2, KOMATSU FD60-2 1980, NISSAN UD NET6A. These details should still be checked against the original unit before ordering.

Which applications are listed for this starter motor?

Listed applications include Komatsu FD60-2, Nissan UD NET6A, Sumitomo Forklift and UD Nissan Diesel C Series models across the specified years. For this listing, part number DXS623 is the main reference point. Listed voltage is 24. Published fitment references include KOMATSU FD60-2, KOMATSU FD60-2 1980, NISSAN UD NET6A. These details should still be checked against the original unit before ordering.
