OEX Starter Motor 12V 9TH CW Denso Style DXS4045

The OEX Starter Motor DXS4045 is a 12V, clockwise rotation starter motor with 9 teeth and a 1.0kW power rating. It is listed as a new unit, with a Denso-style fitment profile, 2-hole starter mount, and a flange diameter of 74mm.

Key dimensions to check include an overall length of 202mm, nose cone length of 42mm, mount centre to centre of 132mm, pinion diameter of 30mm, and pinion at rest of 8mm. The mount hole diameter is M10x1.25 / 11, and the unit weighs 2.85kg.

This starter is supplied under the OEX brand, which is sourced from original equipment manufacturers and aftermarket suppliers, with product made in ISO certified factories. Warranty coverage is listed as 3 years for passenger use and 1 year for commercial use.

Key Features

• 12V starter motor
• Clockwise rotation
• 9-tooth pinion
• 1.0kW power rating
• Denso-style unit
• New starter motor

Specifications

• Part No.: DXS4045
• Brand: OEX
• Type: Starter Motor
• Unit of Measure: Each
• Voltage: 12
• Rotation: CW
• Number of Teeth: 9
• Power Rating: 1.0kW

Verified fitment applications

• Holden Nova
• Toyota Corolla
• Toyota Sprinter

Application and Buying Notes

Before ordering, compare the part number DXS4045, the 12V system requirement, and the clockwise rotation with the unit currently fitted to the vehicle. Starter motors are sensitive to tooth count, mounting pattern, nose cone shape, and pinion location, so the 9-tooth design and 2-hole mounting arrangement need to match the existing application closely.

The listed dimensions are the best place to check if you are unsure. Measure the mount centre to centre at 132mm, flange diameter at 74mm, overall length at 202mm, and nose cone length at 42mm against the original starter. The M10x1.25 / 11 mount hole diameter and 30mm pinion diameter are also useful confirmation points when comparing units side by side.

This starter is described as Denso style and suits Denso applications, so matching the make profile matters as much as the electrical rating. The 1.0kW power rating, 9 teeth, and 8mm pinion at rest all need to align with the replacement unit to avoid installation problems or incorrect engagement. If the original starter is no longer present, the vehicle application and the physical measurements should be checked before purchase.

Warranty coverage is listed separately for passenger and commercial use, at 3 years and 1 year respectively. That makes it important to confirm how the vehicle is used, particularly if it is being fitted to a commercial application. As with any starter motor, correct identification up front is the safest way to avoid downtime, returns, and unnecessary removal work.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXS4045 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Hole Diameter M10x1.25 / 11, Number of Teeth 9, Pinion at Rest 8mm, Power Rating 1.0kW, Suits Unit Make Denso, Mount Cnt to Cnt 132mm, Starter Mount Type 2 Hole.

Additional published details for cross-checking include Weight 2.85kg, Product Group 1 ROTATING ELECTRICAL, Part No. DXS4045, Brand OEX, Description OEX Starter Motor 12V 9Th CW Denso Style, Flange Diameter 74mm, Nose Cone Length 42mm, Overall Length 202mm, Pinion Diameter 30mm, Rotation CW.

OEX Starter Motor 12V 9Th CW Denso Style. Part number DXS4045 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number DXS4045, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include HOLDEN NOVA, HOLDEN NOVA 1989, HOLDEN NOVA 1990, HOLDEN NOVA 1991, TOYOTA COROLLA, TOYOTA COROLLA 1981. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm fitment by checking part number DXS4045, the Denso-style application, and the exact mounting and dimensional details before ordering. Vehicle listing references are helpful, but the starter should still be matched against the existing unit and application specifications.

FAQ

What is the part number for this starter motor?

The part number listed is DXS4045. For this listing, part number DXS4045 is the main reference point. Listed voltage is 12. Published fitment references include HOLDEN NOVA, HOLDEN NOVA 1989, HOLDEN NOVA 1990. These details should still be checked against the original unit before ordering.

What voltage is this starter motor?

It is a 12V starter motor. For this listing, part number DXS4045 is the main reference point. Listed voltage is 12. Published fitment references include HOLDEN NOVA, HOLDEN NOVA 1989, HOLDEN NOVA 1990. These details should still be checked against the original unit before ordering.

Does this starter rotate clockwise or anti-clockwise?

This unit is listed as clockwise rotation, or CW. For this listing, part number DXS4045 is the main reference point. Listed voltage is 12. Published fitment references include HOLDEN NOVA, HOLDEN NOVA 1989, HOLDEN NOVA 1990. These details should still be checked against the original unit before ordering.

How many teeth does the pinion have?

The pinion has 9 teeth. For this listing, part number DXS4045 is the main reference point. Listed voltage is 12. Published fitment references include HOLDEN NOVA, HOLDEN NOVA 1989, HOLDEN NOVA 1990. These details should still be checked against the original unit before ordering.

What are the main mounting details?

It has a 2-hole starter mount, mount hole diameter of M10x1.25 / 11, and mount centre to centre of 132mm. For this listing, part number DXS4045 is the main reference point. Listed voltage is 12. Published fitment references include HOLDEN NOVA, HOLDEN NOVA 1989, HOLDEN NOVA 1990. These details should still be checked against the original unit before ordering.

What warranty is listed for this OEX starter motor?

The warranty is listed as 3 years for passenger use and 1 year for commercial use. For this listing, part number DXS4045 is the main reference point. Listed voltage is 12. Published fitment references include HOLDEN NOVA, HOLDEN NOVA 1989, HOLDEN NOVA 1990. These details should still be checked against the original unit before ordering.
