OEX Starter Motor 12V 9 Tooth CW Bosch Style BXS0182

The OEX Starter Motor BXS0182 is a new 12V rotating electrical unit with a 1.1kW power rating, 9 teeth, and clockwise rotation. It is listed as Bosch style and suits a Bosch unit make, so checking the existing starter against the part number, tooth count, rotation, and mounting measurements is the safest way to confirm it is the correct match.

Key physical details include a 2 hole starter mount, 105mm mount centres A, 68mm flange diameter, 8.5mm mount hole diameter, 52mm nose cone length, and 220mm overall length. The pinion diameter is 25mm and the pinion at rest measurement is 18.5mm, which are important checks when comparing against the removed starter motor.

This unit is supplied by OEX and is backed by a 3 year passenger / 1 year commercial warranty. It weighs 2.94kg and is sold as each, making it suitable for direct replacement work where the correct Bosch style fitment and the original mounting layout must be matched carefully.

Key Features

• 12V starter motor
• 9 tooth pinion
• Clockwise rotation
• Bosch style unit
• New starter motor
• 2 hole mount type

Specifications

• Part No.: BXS0182
• Brand: OEX
• Product type: Starter Motor
• Voltage: 12V
• Rotation: CW
• Number of teeth: 9
• Power rating: 1.1kW
• Starter mount type: 2 hole

Known application groups

• Daewoo: 1.5I, Cielo, Espero, Kalos, Lanos, Nubira
• Holden: Astra, Barina, Combo, Tigra, Viva
• Kubota: U35-3
• Opel: Corsa

Application and Buying Notes

Before ordering, compare the part number BXS0182 with the starter removed from the vehicle and confirm the Bosch style, 12V rating, 9 tooth pinion, and clockwise rotation. These are the main identifiers that help separate one starter motor from another, especially where similar-looking units can differ in rotation, tooth count, or mounting.

The mounting measurements matter just as much as the electrical rating. Check the 2 hole mount type, 105mm mount centres A, 68mm flange diameter, and 8.5mm mount hole diameter against the original starter. If any of those dimensions differ, the unit may not sit correctly on the bell housing or may not line up with the ring gear as intended.

The listed physical size also needs to be treated as a matching point, not an assumption. Verify the 52mm nose cone length, 220mm overall length, 25mm pinion diameter, and 18.5mm pinion at rest measurement before purchasing. Those dimensions are useful when comparing the replacement to the existing starter in hand, particularly on vehicles where different starter variants may have been used.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number BXS0182 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 105mm, Nose Cone Length 52mm, Overall Length 220mm, Pinion Diameter 25mm, Rotation CW, Voltage 12, Starter Mount Type 2 Hole.

Additional published details for cross-checking include Weight 2.94kg, Product Group 1 ROTATING ELECTRICAL, Part No. BXS0182, Brand OEX, Description OEX Starter Motor 12V 9Th CW Bosch Style, Flange Diameter 68mm, Mount Hole Diameter 8.5, Number of Teeth 9, Pinion at Rest 18.5mm, Power Rating 1.1kW.

OEX Starter Motor 12V 9Th CW Bosch Style. Part number BXS0182 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number BXS0182, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include DAEWOO 1.5I, DAEWOO 1.5I 1994, DAEWOO 1.5I 1995, DAEWOO CIELO, HOLDEN ASTRA, HOLDEN ASTRA 1987. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

The listed warranty is 3yr Passenger 1yr Commercial. Warranty terms should be considered alongside correct application and part identification, as warranty does not replace fitment confirmation.

Compatibility note: Confirm fitment by matching part number BXS0182, Bosch style application, 12V rating, 9 tooth CW configuration, and the mounting dimensions before purchase. Vehicle and machine compatibility should always be verified against the removed starter and the listed application details.

FAQ

Is this starter motor new or reconditioned?

It is listed as new, not remanufactured. For this listing, part number BXS0182 is the main reference point. Listed voltage is 12. Published fitment references include DAEWOO 1.5I, DAEWOO 1.5I 1994, DAEWOO 1.5I 1995. These details should still be checked against the original unit before ordering.

What is the part number for this starter motor?

The part number is BXS0182. For this listing, part number BXS0182 is the main reference point. Listed voltage is 12. Published fitment references include DAEWOO 1.5I, DAEWOO 1.5I 1994, DAEWOO 1.5I 1995. These details should still be checked against the original unit before ordering.

What voltage does this starter motor use?

It is a 12V starter motor. For this listing, part number BXS0182 is the main reference point. Listed voltage is 12. Published fitment references include DAEWOO 1.5I, DAEWOO 1.5I 1994, DAEWOO 1.5I 1995. These details should still be checked against the original unit before ordering.

What rotation does it have?

The rotation is clockwise, shown as CW. For this listing, part number BXS0182 is the main reference point. Listed voltage is 12. Published fitment references include DAEWOO 1.5I, DAEWOO 1.5I 1994, DAEWOO 1.5I 1995. These details should still be checked against the original unit before ordering.

Which unit make does it suit?

It suits Bosch unit make and is described as Bosch style. For this listing, part number BXS0182 is the main reference point. Listed voltage is 12. Published fitment references include DAEWOO 1.5I, DAEWOO 1.5I 1994, DAEWOO 1.5I 1995. These details should still be checked against the original unit before ordering.

What warranty is listed?

The listed warranty is 3 year passenger and 1 year commercial. For this listing, part number BXS0182 is the main reference point. Listed voltage is 12. Published fitment references include DAEWOO 1.5I, DAEWOO 1.5I 1994, DAEWOO 1.5I 1995. These details should still be checked against the original unit before ordering.
