Genuine Products Starter Motor 12V 9 Tooth CW Mitsubishi SH1B18400

This Genuine Products starter motor is a 12V, clockwise-rotation unit with 9 teeth and part number SH1B18400. It is listed as a new starter motor for Mitsubishi applications and carries a 12 month warranty.

Key dimensional checks include a 221mm overall length, 73mm flange diameter, 134mm mount centres A, 98mm mount centres B, and 63mm mount centres C. The starter uses a 3 hole mount type with M12x1.5 / 13 mount hole diameter and a 30mm pinion diameter.

The unit is described as original equipment for a guaranteed perfect fit, but the important point is still to match the physical and application details on your vehicle before ordering. Starter motors need the correct voltage, rotation, tooth count, and mounting pattern to be a suitable replacement.

Key Features

• 12V starter motor
• 9 tooth pinion
• Clockwise rotation
• New unit
• 3 hole mount type
• Mitsubishi application

Specifications

• Part number: SH1B18400
• Brand: Genuine Products
• Type: Starter motor
• Voltage: 12V
• Power rating: 1.8kW
• Rotation: CW
• Number of teeth: 9
• Pinion at rest: 2mm

Fitment Information

• Mitsubishi applications only are listed in the product data.
• No verified vehicle model list is supplied beyond Mitsubishi, so exact fitment must be confirmed by part number and physical dimensions before purchase.

Application and Buying Notes

Before ordering, compare the part number SH1B18400 and the mounting details against the starter currently fitted to the vehicle. The important match points here are 12V operation, clockwise rotation, 9 teeth, 3 hole mount type, and the measured mounting centres of 134mm, 98mm, and 63mm.

The 1.8kW power rating, 73mm flange diameter, 221mm overall length, and M12x1.5 / 13 mount hole diameter are useful checks when identifying a replacement starter. If any one of these details differs from the existing unit, do not assume interchangeability.

This starter is described for Mitsubishi use, but there is not enough verified fitment detail here to match it to a specific vehicle model with confidence. The safest approach is to confirm the original starter’s part number, tooth count, rotation direction, and physical layout before buying.

A 12 month warranty is supplied, which gives a useful reference point for the product, but warranty coverage does not replace fitment checking. Starter motors can look similar while differing in mount centres, pinion depth, or rotation, so the vehicle application needs to be checked carefully.

Because this is a new starter motor rather than a remanufactured unit, the condition should be new as listed. Even so, installation should only proceed once the electrical and mechanical match is confirmed, especially where the original unit has signs of wear or non-standard replacement history.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number SH1B18400 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 12 Months, Mount Centres A 134mm, Mount Centres C 63mm, Number of Teeth 9, Pinion at Rest 2mm, Power Rating 1.8kW, Suits Unit Make Mitsubishi, Item Type Starter Motor.

Additional published details for cross-checking include Starter Mount Type 3 Hole, Product Group 2 STARTER MOTORS, Part No. SH1B18400, Brand GENUINE PRODUCTS, Description Genuine Starter Motor 12V 9Th CW Mitsubishi, Flange Diameter 73mm, Mount Centres B 98mm, Mount Hole Diameter M12x1.5 / 13, Overall Length 221mm.

Genuine Starter Motor 12V 9Th CW Mitsubishi. Part number SH1B18400 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number SH1B18400, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Compatibility note: Confirm compatibility using part number SH1B18400 together with the 12V, CW, 9 tooth, 3 hole mount specifications and the recorded mounting dimensions before purchase.

FAQ

What is the part number for this starter motor?

The part number is SH1B18400. For this listing, part number SH1B18400 is the main reference point. Listed voltage is 12. Published fitment references include MAZDA CX-5, MAZDA CX-5 2017, MAZDA CX-5 2018. These details should still be checked against the original unit before ordering.

What voltage is this starter motor?

It is a 12V starter motor. For this listing, part number SH1B18400 is the main reference point. Listed voltage is 12. Published fitment references include MAZDA CX-5, MAZDA CX-5 2017, MAZDA CX-5 2018. These details should still be checked against the original unit before ordering.

What rotation does it use?

The rotation is clockwise (CW). For this listing, part number SH1B18400 is the main reference point. Listed voltage is 12. Published fitment references include MAZDA CX-5, MAZDA CX-5 2017, MAZDA CX-5 2018. These details should still be checked against the original unit before ordering.

How many teeth does the pinion have?

It has 9 teeth. For this listing, part number SH1B18400 is the main reference point. Listed voltage is 12. Published fitment references include MAZDA CX-5, MAZDA CX-5 2017, MAZDA CX-5 2018. These details should still be checked against the original unit before ordering.

What vehicle brand is listed for this starter motor?

The listed vehicle make is Mitsubishi. For this listing, part number SH1B18400 is the main reference point. Listed voltage is 12. Published fitment references include MAZDA CX-5, MAZDA CX-5 2017, MAZDA CX-5 2018. These details should still be checked against the original unit before ordering.

Is this a new or remanufactured unit?

It is listed as new. For this listing, part number SH1B18400 is the main reference point. Listed voltage is 12. Published fitment references include MAZDA CX-5, MAZDA CX-5 2017, MAZDA CX-5 2018. These details should still be checked against the original unit before ordering.
