OEX Starter Motor 12V 9 Tooth CW Mitsuba Style MXS364U

The OEX starter motor MXS364U is a 12V unit with 9 teeth and clockwise rotation, built in a Mitsuba style. It is listed as a new starter motor with a 2 hole starter mount type, 115mm mount centres A, and a 75mm flange diameter.

This unit is rated at 1.6kW and has an overall length of 224mm. The pinion measures 30mm in diameter and 33mm at rest, with mount hole diameters of 13 / 10.5mm and a dry clutch arrangement.

It suits unit make Mitsuba and is supplied as each. The start wire terminal is stated to suit both round and square harness connectors, which may help when checking the electrical connection layout before purchase.

The product carries a 3 year passenger and 1 year commercial warranty. OEX states its products are sourced from ISO certified factories and from market leading original equipment manufacturers and aftermarket suppliers.

Key Features

• 12V starter motor
• 9 tooth pinion
• Clockwise rotation
• Mitsuba style unit
• New, not remanufactured
• 2 hole starter mount

Specifications

• Part number: MXS364U
• Brand: OEX
• Type: Starter motor
• Voltage: 12V
• Power rating: 1.6kW
• Number of teeth: 9
• Rotation: CW
• Suits unit make: Mitsuba

Fitment guidance

• Honda Accord
• Honda Accord Euro
• Honda Civic
• Honda CR-V
• Honda Integra
• Honda Odyssey

Application and Buying Notes

The most important checks on this starter are the part number MXS364U, the 12V electrical system, the 9 tooth pinion, and clockwise rotation. The starter mount type is 2 hole, with 115mm mount centres A and a 75mm flange diameter, so the mounting pattern needs to match the vehicle application before ordering.

Check the pinion dimensions as well as the overall body length. This unit is listed with a 30mm pinion diameter, 33mm pinion at rest, and 224mm overall length. Those measurements matter where clearance around the bellhousing or surrounding components is tight.

The note supplied with the part is worth reading carefully. It says low voltage to the starter can cause the solenoid contacts to chatter and burn, so battery condition and cables should be checked before fitting a new starter motor. That is especially relevant if the old unit failed after slow cranking or repeated starting issues.

Because this is a Mitsuba style unit, the key compatibility checkpoint is whether the original starter matches the Mitsuba pattern and the listed dimensions. The safest approach is to compare the part number, mounting points, rotation, tooth count and connector style before fitment is attempted.

The starter is new and carries a 3 year passenger and 1 year commercial warranty. For commercial use, it is still important to match the vehicle correctly and make sure the charging and starting system is in good condition, as warranty coverage does not replace the need for proper diagnosis before installation.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MXS364U helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 115mm, Number of Teeth 9, Pinion at Rest 33mm, Power Rating 1.6kW, Suits Unit Make Mitsuba, Note Start wire terminal suitable for both round and square harness connector. Voltage drop to the starter (Low voltage) can cause the solenoid contacts to chatter and burn. Please make sure to check the battery condition and cables before the new starter motor fitment., New / Reman. New.

Additional published details for cross-checking include Wet / Dry Clutch Dry, Product Group 2 STARTER MOTORS, Part No. MXS364U, Brand OEX, Description OEX Starter Motor 12V 9Th CW Mitsuba Style - See Note, Flange Diameter 75mm, Mount Hole Diameter 13 / 10.5, Overall Length 224mm, Pinion Diameter 30mm.

OEX Starter Motor 12V 9Th CW Mitsuba Style - See Note. Part number MXS364U should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number MXS364U, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include HONDA ACCORD, HONDA ACCORD 2006, HONDA ACCORD 2007, HONDA ACCORD 2008. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

The listed warranty is 3yr Passenger 1yr Commercial. Warranty terms should be considered alongside correct application and part identification, as warranty does not replace fitment confirmation.

Compatibility note: Confirm fitment by matching part number MXS364U, Mitsuba style, 12V, 9 tooth CW specification, 2 hole mount, and the listed dimensions against the original unit and vehicle application before ordering.

FAQ

What part number is this starter motor?

The part number is MXS364U.

What voltage and rotation does it have?

It is a 12V starter motor with clockwise rotation.

How many teeth does the pinion have?

The pinion has 9 teeth.

What is the power rating?

The listed power rating is 1.6kW.

What vehicles are listed in the fitment guidance?

The fitment guidance includes Honda Accord, Honda Accord Euro, Honda Civic, Honda CR-V, Honda Integra and Honda Odyssey. Final fitment should still be confirmed against the vehicle and original starter.

What should be checked before fitting if the old starter failed?

Battery condition and cables should be checked first. The supplied note states that low voltage can cause the solenoid contacts to chatter and burn.
