OEX Air Conditioning Compressor 24V Ear Mount Sanden SO7150 Style CXI1531

The OEX Air Conditioning Compressor CXI1531 is a 24V ear mount unit built in Sanden SO7150 style, with a 146mm clutch diameter and vertical O-ring fitting type. It is listed as a single unit and carries part number CXI1531 for identification at the counter or when cross-checking against an existing compressor.

This compressor suits Sanden applications and is specified with a B pulley section, 33.85mm gauge line, and an oil capacity of 135ml using PAG46 oil. The original equipment number provided is 7887, which is useful when comparing against a removed unit or checking service records.

Fitment information supplied for this compressor includes Isuzu N Series NPR 5.2L and NQR450 5.2L from 09/2005 onward, plus earlier N Series NPR200 4.3L and NQR450 4.8L from 01/1994 to 12/2004, and N Series NPR200/300/400 4.8L and 5.2L from 08/2000 to 12/2007. Universal applications are also listed, so confirming the exact mount, pulley, and connector details remains important before ordering.

Key Features

• 24V air conditioning compressor
• Ear mount style
• Sanden SO7150 style
• Part number CXI1531
• Original equipment number 7887
• 146mm clutch diameter

Specifications

• Voltage: 24V
• Compressor mounting: Ear mount
• Series: SO7150
• Brand: OEX
• Unit of measure: Each
• Clutch diameter: 146mm
• Gauge line: 33.85mm
• Oil capacity: 135ml

Fitment guidance

• Isuzu N Series NPR 5.2L and NQR450 5.2L from 09/2005 onward
• Isuzu N Series NPR200 4.3L and NQR450 4.8L from 01/1994 to 12/2004
• Isuzu N Series NPR200/300/400 4.8L and 5.2L from 08/2000 to 12/2007
• Universal applications are listed, but exact suitability still needs to be checked against the compressor mounting and pulley details

Application and Buying Notes

Before ordering, compare the part number CXI1531 and original equipment number 7887 with the compressor already fitted to the vehicle. That is the safest way to confirm you are matching the correct Sanden SO7150 style unit, especially where the vehicle may have had previous repairs or a non-standard replacement.

The mount and connection details matter on this compressor. It is an ear mount, 24V unit with vertical O-ring fittings, a 146mm clutch diameter, and a B pulley section, so the replacement should be checked against the existing bracket layout, pulley alignment, and hose connection style rather than relying on vehicle branding alone.

Oil specification also needs attention on compressor replacement. This unit is noted for PAG46 oil with a 135ml oil capacity, and the listing states no dust cover. If the system has been open, contaminated, or previously repaired, the correct servicing procedure should be followed by the installer before the compressor is put into service.

The fitment range includes several Isuzu N Series applications across different engine sizes and build periods, plus universal applications. Because those ranges cover more than one model and configuration, confirm the exact chassis, engine, mounting arrangement, and system specification before purchase to avoid ordering by vehicle name only.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number CXI1531 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type AIR CONDITIONING COMPRESSOR, Unit of Measure EACH, Warranty Two Years, Compressor Mounting Ear Mount, Original Equipment Number 7887, Series SO7150, Voltage 24, Gauge Line 33.85mm, Dust Cover Y/N No.

Additional published details for cross-checking include Product Group 2 AC COMPONENTS, Part No. CXI1531, Brand OEX, Description OEX Air Conditioning Compressor 24V Ear Mount Sanden SO7150 Style, Clutch Diameter 146mm, Fitting Type Vertical O Ring, Pulley Section B, Suits Unit Make Sanden, Note O Rings to suit ORX008 & ORX010 . Oil type PAG46., Oil Capacity 135ml.

OEX Air Conditioning Compressor 24V Ear Mount Sanden SO7150 Style. Part number CXI1531 should be checked first. Listed voltage is 24. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Pulley configuration is B. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number CXI1531, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a air conditioning compressor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 24 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include ISUZU ELF, ISUZU ELF 1970, ISUZU ELF 1971, ISUZU ELF 1972, KOMATSU GD825A-2, KOMATSU GD825A-2 1996. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm compatibility using part number CXI1531, OE number 7887, 24V ear mount layout, vertical O-ring fittings, and the listed Isuzu application details before fitting.

FAQ

What is the part number for this compressor?

The part number is CXI1531.

What voltage is the compressor?

It is a 24V air conditioning compressor.

What vehicles are listed as suitable?

Listed applications include Isuzu N Series NPR 5.2L and NQR450 5.2L from 09/2005 onward, Isuzu N Series NPR200 4.3L and NQR450 4.8L from 01/1994 to 12/2004, and N Series NPR200/300/400 4.8L and 5.2L from 08/2000 to 12/2007.

What type of mounting does it use?

It uses an ear mount compressor mounting style.

What oil does it use?

The listed oil type is PAG46, with an oil capacity of 135ml.

Does it come with a warranty?

Yes. The listed warranty is two years.
