OEX Starter Motor 12V 9T CW Denso Style DXS519

The OEX DXS519 starter motor is a 12V unit with 9 teeth, clockwise rotation, and a Denso-style application. It is a new starter motor, not remanufactured, and it carries a power rating of 1.2kW. Key physical points for checking before purchase include the 2-hole starter mount, 104mm mount centres, and 74mm flange diameter.

This starter motor suits a dry clutch arrangement and has a pinion at rest measurement of 20mm. Other useful dimensions are an overall length of 180mm, a 29mm pinion diameter, and M10x1.25 mount hole diameter. Weight is listed at 3.44kg, which can help when comparing to the removed unit.

OEX states its products are sourced from market leading Original Equipment Manufacturers and aftermarket suppliers, with supply from ISO certified factories. The unit is backed by a comprehensive nationwide warranty, with warranty cover listed as 3yr Passenger and 1yr Commercial. That makes the part number DXS519 an important reference when matching the starter to the vehicle application.

Key Features

• 12V starter motor
• 9-tooth pinion
• Clockwise rotation
• 1.2kW power rating
• New unit
• Denso-style application

Specifications

• Brand: OEX
• Product type: Starter motor
• Part No.: DXS519
• Voltage: 12V
• Number of teeth: 9
• Rotation: CW
• Power rating: 1.2kW
• Starter mount type: 2 hole

Fitment guidance

• Common fitment groups listed include HINO and TOYOTA applications.
• HINO entries include DUTRO and RANGER variants.
• TOYOTA entries include DYNA 200, GRANVIA, HIACE, HIACE / COMMUTER, HIACE SBV, HILUX, HILUX SURF, LAND CRUISER PRADO, and REGIUS ACE.
• Because vehicle-specific engine and model details are not fully identified here, match carefully by part number and starter measurements before ordering.

Application and Buying Notes

This starter motor is identified as DXS519 and described as a 12V, 9-tooth, clockwise unit in Denso style. The most useful checks are the 2-hole mount, 104mm mount centres, 74mm flange diameter, and M10x1.25 mount hole size. If your removed starter does not match those points, it should be treated as a different application.

The 1.2kW power rating and 20mm pinion at rest are also worth checking against the old part. Starter motors can look similar while differing in tooth count, rotation, pinion size, or mount pattern, so the best result comes from comparing the physical unit and part number together rather than relying on appearance alone.

This part is listed as new and suited to a dry clutch application. If the vehicle has already been modified, or if the existing starter has no visible identification, confirm the installation points carefully before purchase. A 3.44kg unit with 180mm overall length can be compared directly with the removed component to help avoid mismatches.

The fitment information provided points to HINO and TOYOTA applications, but the exact vehicle, engine, and build details still matter. Use the part number DXS519, tooth count, rotation direction, and mount dimensions as the main compatibility checkpoints. That is the safest way to confirm the starter before fitting.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXS519 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 104mm, Number of Teeth 9, Pinion at Rest 20mm, Power Rating 1.2kW, Suits Unit Make Denso, New / Reman. New, Wet / Dry Clutch Dry.

Additional published details for cross-checking include Product Group 2 STARTER MOTORS, Part No. DXS519, Brand OEX, Description OEX Starter Motor 12V 9Th CW Denso Style, Flange Diameter 74mm, Mount Hole Diameter M10x1.25, Overall Length 180mm, Pinion Diameter 29mm, Rotation CW.

OEX Starter Motor 12V 9Th CW Denso Style. Part number DXS519 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number DXS519, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include HINO DUTRO, HINO DUTRO 2000, HINO DUTRO 2003, HINO RANGER, TOYOTA DYNA 200, TOYOTA DYNA 200 1995. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Please confirm compatibility using part number DXS519, 12V specification, 9-tooth clockwise configuration, and the listed mount and dimension details before ordering. Vehicle fitment should be checked against the removed unit and application details.

FAQ

What type of part is DXS519?

DXS519 is an OEX starter motor. It is listed as a 12V, 9-tooth, clockwise unit in Denso style. For this listing, part number DXS519 is the main reference point. Listed voltage is 12. Published fitment references include HINO DUTRO, HINO DUTRO 2000, HINO DUTRO 2003. These details should still be checked against the original unit before ordering.

Is this starter motor new or remanufactured?

It is listed as new, not remanufactured. For this listing, part number DXS519 is the main reference point. Listed voltage is 12. Published fitment references include HINO DUTRO, HINO DUTRO 2000, HINO DUTRO 2003. These details should still be checked against the original unit before ordering.

What is the power rating?

The power rating is 1.2kW. For this listing, part number DXS519 is the main reference point. Listed voltage is 12. Published fitment references include HINO DUTRO, HINO DUTRO 2000, HINO DUTRO 2003. These details should still be checked against the original unit before ordering.

What mounting details are provided?

The unit has a 2-hole starter mount, 104mm mount centres, a 74mm flange diameter, and M10x1.25 mount hole diameter. For this listing, part number DXS519 is the main reference point. Listed voltage is 12. Published fitment references include HINO DUTRO, HINO DUTRO 2000, HINO DUTRO 2003. These details should still be checked against the original unit before ordering.

Which clutch type is it suited to?

It is listed for a dry clutch application. For this listing, part number DXS519 is the main reference point. Listed voltage is 12. Published fitment references include HINO DUTRO, HINO DUTRO 2000, HINO DUTRO 2003. These details should still be checked against the original unit before ordering.

What warranty is listed?

The warranty is listed as 3yr Passenger and 1yr Commercial. For this listing, part number DXS519 is the main reference point. Listed voltage is 12. Published fitment references include HINO DUTRO, HINO DUTRO 2000, HINO DUTRO 2003. These details should still be checked against the original unit before ordering.
