OEX Starter Motor 12V 8 Tooth CW Mitsubishi Style MXS240

The OEX Starter Motor MXS240 is a 12V, clockwise rotating starter motor in Mitsubishi style with an 8 tooth pinion. It is a new unit, not remanufactured, and is listed with a 1.4kW power rating for applications that match the supplied mounting and dimensional details.

Key physical details include a 3 hole starter mount type, 111mm mount centres A, 107mm mount centres B, 29mm mount centres C, and a 70mm flange diameter. The overall length is 220mm, the mount hole diameter is M10x1.5, and the unit weighs 3.2kg.

For comparison at ordering stage, the pinion measures 28mm in diameter, the pinion at rest is 27mm, and the starter is specified for a dry clutch setup. The part number is MXS240, which is the safest reference point when checking against the vehicle application.

Key Features

• 12V starter motor
• 8 tooth pinion
• Clockwise rotation
• Mitsubishi style unit
• 3 hole starter mount
• New unit

Specifications

• Part No.: MXS240
• Brand: OEX
• Voltage: 12V
• Power Rating: 1.4kW
• Rotation: CW
• Number of Teeth: 8
• Starter Mount Type: 3 hole
• Flange Diameter: 70mm

Verified application references

• Ford Corsair
• Nissan Pintara
• Toyota Corolla

Application and Buying Notes

This starter should only be matched after checking the part number MXS240, the 12V system requirement, and the clockwise rotation. Those three items are the quickest way to rule out an incorrect replacement before comparing mounting dimensions and pinion details.

The mounting layout is specific: 3 hole mount type, 111mm / 107mm / 29mm mount centres, 70mm flange diameter, and M10x1.5 mount holes. If the existing starter differs in these measurements, the unit may not align correctly even where the vehicle family appears similar.

The 8 tooth pinion and 28mm pinion diameter are also important checks. The unit is described as Mitsubishi style and suitable for a dry clutch application, so it is worth confirming the original starter and clutch arrangement before ordering.

The warranty is listed as 3 years for passenger use and 1 year for commercial use. For workshop or fleet buyers, that distinction matters when assessing how the starter will be used after installation.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MXS240 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 111mm, Mount Centres C 29mm, Number of Teeth 8, Pinion at Rest 27mm, Power Rating 1.4kW, Suits Unit Make Mitsubishi, New / Reman. New.

Additional published details for cross-checking include Wet / Dry Clutch Dry, Product Group 2 STARTER MOTORS, Part No. MXS240, Brand OEX, Description OEX Starter Motor 12V 8Th CW Mitsubishi Style, Flange Diameter 70mm, Mount Centres B 107mm, Mount Hole Diameter M10x1.5, Overall Length 220mm.

OEX Starter Motor 12V 8Th CW Mitsubishi Style. Part number MXS240 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number MXS240, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include FORD CORSAIR, FORD CORSAIR 1989, FORD CORSAIR 1990, FORD CORSAIR 1991, NISSAN PINTARA, NISSAN PINTARA 1989. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm fitment by matching part number MXS240, the 12V clockwise specification, and the mounting and pinion measurements against the vehicle application before purchase.

FAQ

What is the part number for this starter motor?

The part number is MXS240. For this listing, part number MXS240 is the main reference point. Listed voltage is 12. Published fitment references include FORD CORSAIR, FORD CORSAIR 1989, FORD CORSAIR 1990. These details should still be checked against the original unit before ordering.

Is this starter motor new or remanufactured?

It is listed as a new starter motor. For this listing, part number MXS240 is the main reference point. Listed voltage is 12. Published fitment references include FORD CORSAIR, FORD CORSAIR 1989, FORD CORSAIR 1990. These details should still be checked against the original unit before ordering.

What voltage and rotation does it use?

It is a 12V unit with clockwise rotation. For this listing, part number MXS240 is the main reference point. Listed voltage is 12. Published fitment references include FORD CORSAIR, FORD CORSAIR 1989, FORD CORSAIR 1990. These details should still be checked against the original unit before ordering.

How many teeth does the pinion have?

The pinion has 8 teeth. For this listing, part number MXS240 is the main reference point. Listed voltage is 12. Published fitment references include FORD CORSAIR, FORD CORSAIR 1989, FORD CORSAIR 1990. These details should still be checked against the original unit before ordering.

What warranty is listed for this product?

The warranty is listed as 3 years for passenger use and 1 year for commercial use. For this listing, part number MXS240 is the main reference point. Listed voltage is 12. Published fitment references include FORD CORSAIR, FORD CORSAIR 1989, FORD CORSAIR 1990. These details should still be checked against the original unit before ordering.

Which vehicle makes are referenced in the fitment data?

The fitment data references Ford, Nissan, and Toyota, including Ford Corsair, Nissan Pintara, and Toyota Corolla applications. For this listing, part number MXS240 is the main reference point. Listed voltage is 12. Published fitment references include FORD CORSAIR, FORD CORSAIR 1989, FORD CORSAIR 1990. These details should still be checked against the original unit before ordering.
