OEX Starter Motor 12V 9T CW Mitsubishi Style MXS307

The OEX MXS307 is a new 12V starter motor with 9 teeth, clockwise rotation and a 1.4kW power rating. It is listed as Mitsubishi style and suited to Mitsubishi units, so matching the part number and application details is the safest way to confirm the correct replacement before ordering.

Key dimensions include a 119mm mount centres measurement, 72mm nose cone length, 240mm overall length, 73mm flange diameter and 11mm mount hole diameter. The unit weighs 3.46kg and uses a 2 hole starter mount type, which are useful checks when comparing against the removed starter motor.

As a rotating electrical component, the MXS307 is supplied new rather than remanufactured and is backed by a 3 year passenger / 1 year commercial warranty. For buyers working on a Mitsubishi application, the 12V electrical specification, CW rotation and 9 tooth pinion are the main identifiers to verify against the vehicle’s original starter.

OEX states its products are sourced from market leading original equipment manufacturers and aftermarket suppliers, produced in ISO certified factories, and supported by a nationwide warranty. Those details matter when you want a replacement starter motor that can be matched by specification rather than guesswork.

Key Features

• 12V starter motor
• 9 tooth pinion
• Clockwise rotation
• 1.4kW power rating
• New unit
• 2 hole starter mount type

Specifications

• Part No.: MXS307
• Brand: OEX
• Type: Starter motor
• Voltage: 12V
• Rotation: CW
• Number of teeth: 9
• Power rating: 1.4kW
• Starter mount type: 2 hole

Fitment guidance

• Suites unit make: Mitsubishi

Application and Buying Notes

Before buying, check the part number MXS307 against the starter removed from the vehicle and compare the physical dimensions: 119mm mount centres, 72mm nose cone length, 240mm overall length and 73mm flange diameter. Those measurements, along with the 2 hole mount pattern and 11mm mount hole diameter, are practical checks when two starters look similar but are not identical.

The electrical and drive details also need to line up. This unit is 12V, clockwise rotation, 9 tooth, and rated at 1.4kW, so it should only be considered where those exact specifications match the original application. The pinion diameter is 25mm and pinion at rest is 39mm, which can help with identification when comparing the old part to the replacement.

The fitment information provided only confirms Mitsubishi as the unit make, so there is not enough verified detail here to name specific vehicle models. If the vehicle has been modified, if the existing starter has been changed previously, or if the original part label is missing, confirm the application carefully before purchase.

For commercial use, the warranty listed is 1 year; for passenger use, it is 3 years. That difference is worth noting if the vehicle sees regular work duty, because warranty coverage depends on how the unit is used rather than just the part number alone.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number MXS307 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 119mm, Nose Cone Length 72mm, Overall Length 240mm, Pinion Diameter 25mm, Rotation CW, Voltage 12, Starter Mount Type 2 Hole.

Additional published details for cross-checking include Weight 3.46kg, Product Group 1 ROTATING ELECTRICAL, Part No. MXS307, Brand OEX, Description OEX Starter Motor 12V 9Th CW Mitsubishi Style, Flange Diameter 73mm, Mount Hole Diameter 11, Number of Teeth 9, Pinion at Rest 39mm, Power Rating 1.4kW.

OEX Starter Motor 12V 9Th CW Mitsubishi Style. Part number MXS307 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number MXS307, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include LAND ROVER 110/127, LAND ROVER 110/127 1983, LAND ROVER 110/127 1984, LAND ROVER 110/127 1985, ROVER 2000-3500, ROVER 2000-3500 1968. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm compatibility by matching part number MXS307, 12V CW rotation, 9 tooth pinion, 2 hole mount, and the listed dimensions against the existing starter motor and vehicle application details before ordering.

FAQ

What is the part number for this starter motor?

The part number is MXS307. For this listing, part number MXS307 is the main reference point. Listed voltage is 12. Published fitment references include LAND ROVER 110/127, LAND ROVER 110/127 1983, LAND ROVER 110/127 1984. These details should still be checked against the original unit before ordering.

Is this a new or remanufactured starter motor?

It is listed as new. For this listing, part number MXS307 is the main reference point. Listed voltage is 12. Published fitment references include LAND ROVER 110/127, LAND ROVER 110/127 1983, LAND ROVER 110/127 1984. These details should still be checked against the original unit before ordering.

What voltage does this starter motor use?

It is a 12V starter motor. For this listing, part number MXS307 is the main reference point. Listed voltage is 12. Published fitment references include LAND ROVER 110/127, LAND ROVER 110/127 1983, LAND ROVER 110/127 1984. These details should still be checked against the original unit before ordering.

What rotation does the starter motor have?

The rotation is clockwise, listed as CW. For this listing, part number MXS307 is the main reference point. Listed voltage is 12. Published fitment references include LAND ROVER 110/127, LAND ROVER 110/127 1983, LAND ROVER 110/127 1984. These details should still be checked against the original unit before ordering.

How many teeth does the pinion have?

It has 9 teeth. For this listing, part number MXS307 is the main reference point. Listed voltage is 12. Published fitment references include LAND ROVER 110/127, LAND ROVER 110/127 1983, LAND ROVER 110/127 1984. These details should still be checked against the original unit before ordering.

What warranty is listed for this part?

The warranty is 3 years for passenger use and 1 year for commercial use. For this listing, part number MXS307 is the main reference point. Listed voltage is 12. Published fitment references include LAND ROVER 110/127, LAND ROVER 110/127 1983, LAND ROVER 110/127 1984. These details should still be checked against the original unit before ordering.
