OEX Starter Motor 12V 9TH CW Bosch Style BXS0113

The OEX starter motor BXS0113 is a 12V, 9 tooth, clockwise rotating unit built in a Bosch style configuration. It is listed as a new starter motor, supplied each, with a 1.2kW power rating, which makes the key identification details easy to check before ordering.

Physical dimensions are important with starters, and this unit carries an 82mm flange diameter, 105mm mount centres, M10x1.5 mount hole threads, and an overall length of 217mm. The pinion diameter is 25mm and the pinion at rest is 26mm, so matching those details to the vehicle application is a sensible first step.

OEX positions this part as a quality replacement for the Australian automotive aftermarket. The brand notes a 3 year or 75,000 kilometre warranty on new units, and this starter is identified as a dry clutch type with a two hole starter mount.

Key Features

• 12V starter motor
• 9 tooth pinion
• Clockwise rotation
• Bosch style unit
• New replacement part
• 2 hole starter mount

Specifications

• Part No.: BXS0113
• Brand: OEX
• Product type: Starter motor
• Voltage: 12V
• Power rating: 1.2kW
• Rotation: CW
• Number of teeth: 9
• Starter mount type: 2 hole

Confirmed application guidance

• Fitment data includes BMW 5 and BMW 7 applications.
• Fitment data includes Mercedes-Benz 123 and Mercedes-Benz 124 applications.
• Fitment data includes Mercedes-Benz 180, 190, C-Class, CLC-Class, CLK, E-Class, MB, SLK, Sprinter 3-T, Vito, and Vito / Mixto applications.
• Fitment data includes SsangYong Korando and SsangYong Musso applications.
• Fitment entries span multiple model years in the supplied data, including BMW 5 from 1992 through 2003, Mercedes-Benz 123 from 1980 through 1985, Mercedes-Benz 124 from 1985 through 1988, SsangYong Korando from 1998 and 2012 through 2016, and SsangYong Musso from 1996 through 1998.

Application and Buying Notes

Before buying, match the part number BXS0113 and compare the starter layout to the vehicle’s original unit. The important physical checks here are 12V system voltage, 9 tooth pinion count, clockwise rotation, 82mm flange diameter, 105mm mount centres, and the M10x1.5 mount holes.

Because this is described as a Bosch style starter motor, it is best used where the original starter matches that style and mounting pattern. The 2 hole mount, 217mm overall length, 25mm pinion diameter, and 26mm pinion at rest all matter when confirming the unit against the vehicle already in place.

Warranty support differs between new and remanufactured units in the OEX range, but this listing is for a new starter motor. The stated warranty for new units is 3 years or 75,000 kilometres, while commercial use and any other vehicle-specific factors still need to be checked against the application before purchase.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number BXS0113 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 105mm, Number of Teeth 9, Pinion at Rest 26mm, Power Rating 1.2kW, Suits Unit Make Bosch, New / Reman. New, Wet / Dry Clutch Dry.

Additional published details for cross-checking include Product Group 2 STARTER MOTORS, Part No. BXS0113, Brand OEX, Description OEX Starter Motor 12V 9Th CW Bosch Style, Flange Diameter 82mm, Mount Hole Diameter M10x1.5, Overall Length 217mm, Pinion Diameter 25mm, Rotation CW.

OEX Starter Motor 12V 9Th CW Bosch Style. Part number BXS0113 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number BXS0113, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include BMW 5, BMW 5 1992, BMW 5 1993, BMW 5 1994, MERCEDES-BENZ 123, MERCEDES-BENZ 123 1980. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

The listed warranty is 3yr Passenger 1yr Commercial. Warranty terms should be considered alongside correct application and part identification, as warranty does not replace fitment confirmation.

Compatibility note: Confirm fitment using the part number BXS0113, the Bosch style application, and the physical measurements listed here. Do not rely on model name alone; compare voltage, tooth count, rotation, mount type, and dimensions against the original starter on the vehicle.

FAQ

What type of part is BXS0113?

BXS0113 is an OEX starter motor. It is listed as a 12V, 9 tooth, clockwise rotating Bosch style unit supplied new each. For this listing, part number BXS0113 is the main reference point. Listed voltage is 12. Published fitment references include BMW 5, BMW 5 1992, BMW 5 1993. These details should still be checked against the original unit before ordering.

Is this starter motor new or remanufactured?

This listing is for a new starter motor, not a remanufactured unit. For this listing, part number BXS0113 is the main reference point. Listed voltage is 12. Published fitment references include BMW 5, BMW 5 1992, BMW 5 1993. These details should still be checked against the original unit before ordering.

What are the main mounting measurements?

The listed mounting details are 82mm flange diameter, 105mm mount centres, M10x1.5 mount hole diameter, and a two hole starter mount. For this listing, part number BXS0113 is the main reference point. Listed voltage is 12. Published fitment references include BMW 5, BMW 5 1992, BMW 5 1993. These details should still be checked against the original unit before ordering.

What electrical rating is listed?

The starter motor is listed at 12V with a 1.2kW power rating. For this listing, part number BXS0113 is the main reference point. Listed voltage is 12. Published fitment references include BMW 5, BMW 5 1992, BMW 5 1993. These details should still be checked against the original unit before ordering.

Which vehicle makes appear in the fitment data?

The supplied fitment data includes BMW, Mercedes-Benz, and SsangYong applications. For this listing, part number BXS0113 is the main reference point. Listed voltage is 12. Published fitment references include BMW 5, BMW 5 1992, BMW 5 1993. These details should still be checked against the original unit before ordering.

What should I check before ordering?

Check the part number BXS0113, then compare voltage, tooth count, clockwise rotation, Bosch style, mount type, and dimensions against the original starter fitted to the vehicle. For this listing, part number BXS0113 is the main reference point. Listed voltage is 12. Published fitment references include BMW 5, BMW 5 1992, BMW 5 1993. These details should still be checked against the original unit before ordering.
