HCC Air Conditioning Compressor 12V Direct Mount HS15 CXH034

The HCC Air Conditioning Compressor in HS15 series is a 12V, direct mount unit supplied under part number CXH034. It is listed with original equipment number 97701-4H060 and uses a 7 groove pulley with a 118mm clutch diameter, so those identifiers are the key checks when comparing against the vehicle already in front of you.

This compressor is specified with a 150cc oil capacity and uses FD46XG oil type. It is a Halla unit and is listed as a direct mount fitting type with no dust cover, which makes the mounting style and accessory details important when matching it to the existing compressor setup.

Fitment guidance supplied with the part lists Hyundai iLoad TQ-V I & II 2.5L from 01/2015 onward and Hyundai iMax TQ 2.5L from 01/2008 to 08/2015. Those application details should be checked carefully against the vehicle build date, engine, and the compressor currently fitted before ordering.

Key Features

• HCC air conditioning compressor
• 12V electrical specification
• HS15 series
• Direct mount compressor
• Part number CXH034
• Original equipment number 97701-4H060

Specifications

• Type: Air conditioning compressor
• Brand: Hanon System
• Part No.: CXH034
• Original Equipment Number: 97701-4H060
• Voltage: 12V
• Series: HS15
• Compressor mounting: Direct mount
• Fitting type: Pad right hand

Verified fitment guidance

• Hyundai iLoad TQ-V I & II 2.5L — 01/2015 onward
• Hyundai iMax TQ 2.5L — 01/2008 to 08/2015
• Listed fitment family includes Hyundai iLoad / H-1 and Hyundai iMax / H-1
• Confirm the vehicle build date, engine, and existing compressor layout before ordering

Application and Buying Notes

Before buying, compare the compressor mounting style, pulley layout, and clutch size against the unit already fitted to the vehicle. This compressor is a direct mount HS15 unit with a 7 groove pulley and 118mm clutch diameter, so those physical details matter as much as the model name when confirming a match.

The part number CXH034 and OEM number 97701-4H060 are the most useful identifiers for cross-checking. If the vehicle uses a different compressor arrangement, even within a similar Hyundai application, the mount type or pulley specification may not line up and the part should be checked again before installation.

This is a climate control component supplied as a single unit, and it carries a one year warranty. Like any air conditioning compressor, correct identification is important because the same vehicle family can use different compressor variants depending on engine or accessory drive setup.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number CXH034 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type AIR CONDITIONING COMPRESSOR, Unit of Measure EACH, Warranty One Year, Compressor Mounting Direct Mount, Original Equipment Number 97701-4H060, Series HS15, Voltage 12, Oil Capacity 150cc, Weight 7.34kg, Product Group 1 COOLING.

Additional published details for cross-checking include Part No. CXH034, Brand HANON SYSTEM, Description HCC Air Conditioning Compressor 12V Direct Mount HS15, Clutch Diameter 118mm, Fitting Type Pad Right Hand, Pulley Section 7 Groove, Suits Unit Make Halla, Note Oil type: FD46XG, Dust Cover Y/N No.

HCC Air Conditioning Compressor 12V Direct Mount HS15. Part number CXH034 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

Pulley configuration is 7 Groove. Those physical and electrical details should line up with the original unit before the replacement is approved for fitment.

For part number CXH034, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a air conditioning compressor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include HYUNDAI ILOAD / H-1, HYUNDAI ILOAD / H-1 2008, HYUNDAI ILOAD / H-1 2012, HYUNDAI IMAX / H-1. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Please confirm fitment by matching part number CXH034, OEM 97701-4H060, 12V specification, direct mount style, 7 groove pulley, 118mm clutch diameter, and the listed Hyundai application details before purchase.
