Valeo Starter Motor 12V 9 Tooth CW 1KW Part No. 432636

Valeo Starter Motor 12V 9 Tooth CW, part no. 432636, is a new starter motor supplied as an each unit. It is a 1kW starter with clockwise rotation and a 9 tooth pinion, suited to applications that require a 12V Valeo unit with this mounting and drive arrangement.

Key physical details matter with starters, and this unit gives you several useful checks before purchase: 85mm mount centres B, 120mm mount centres A, 85mm mount centres C, M10x1.5 mount hole diameter, a 3 hole starter mount type, and an overall length of 210mm. The nose cone length is 26mm, the pinion diameter is 25mm, and the pinion at rest is -6mm.

Valeo notes that 9 tooth and 13 tooth units are interchangeable, which is helpful when comparing an existing starter against replacement options. The unit is listed as dry clutch type, with no clamp, and weighs 3.11kg. Warranty is one year.

Key Features

• Valeo new starter motor
• 12V, 1kW output
• Clockwise rotation
• 9 tooth pinion
• 9 tooth and 13 tooth units are interchangeable
• 3 hole starter mount type

Specifications

• Part No.: 432636
• Brand: Valeo
• Product type: Starter motor
• Voltage: 12V
• Power rating: 1kW
• Rotation: CW
• Number of teeth: 9
• Mount centres A: 120mm

Fitment guidance

• Listed fitment includes Citroen BX, Citroen Xantia, Citroen XM and Citroen Xsara.
• Listed fitment includes Peugeot 205, Peugeot 306, Peugeot 405, Peugeot 406, Peugeot 508 and Peugeot 605.
• Fitment records also show model-year applications for Citroen BX across 1982 to 1992 and Peugeot 205 across 1987 to 1997.

Application and Buying Notes

Before ordering, match the part number 432636 and check the physical dimensions against your existing starter. The 3 hole mount pattern, 120mm and 85mm mount centres, M10x1.5 mount hole diameter, and 210mm overall length are the most useful comparison points when confirming the unit is the same shape and fixing arrangement.

The tooth count and rotation are equally important on a starter motor. This Valeo unit is 9 tooth, clockwise rotation, 12V, and 1kW. Valeo also notes that 9 tooth and 13 tooth units are interchangeable, but that should still be checked against the application and the starter already fitted to the vehicle.

If you are replacing a starter on a Citroen or Peugeot application, compare the existing unit carefully rather than relying on the vehicle badge alone. Starter motors can vary by mounting style, nose length, pinion position, and tooth count, so the safest check is to verify the part number, voltage, rotation, mount centres, and pinion details together.

The one year warranty applies to the supplied new unit. As with any rotating electrical part, correct identification before fitting is important, because once installed it is harder to confirm interchange details without removing the starter again.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number 432636 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty One Year, Mount Centres B 85mm, Mount Hole Diameter M10x1.5, Number of Teeth 9, Pinion at Rest -6mm, Power Rating 1kW, Suits Unit Make Valeo, Note 9 tooth and 13 tooth units are interchangeable.

Additional published details for cross-checking include Starter Mount Type 3 Hole, Position / Degree L 55, Number of Thread Bores 3, Product Group 2 STARTER MOTORS, Part No. 432636, Brand VALEO, Description Valeo Starter Motor 12V 9Th CW, Mount Centres A 120mm, Mount Centres C 85mm.

Valeo Starter Motor 12V 9Th CW. Part number 432636 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number 432636, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include CITROEN BX, CITROEN BX 1982, CITROEN BX 1983, CITROEN BX 1984, PEUGEOT 205, PEUGEOT 205 1987. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm compatibility by checking part number 432636, the 12V supply, 1kW rating, CW rotation, 9 tooth pinion, and the listed mount dimensions against the starter already fitted to the vehicle. Do not rely on vehicle model alone, as starter fitment can vary within the same range.

FAQ

What is the part number for this Valeo starter motor?

The part number is 432636. For this listing, part number 432636 is the main reference point. Listed voltage is 12. Published fitment references include CITROEN BX, CITROEN BX 1982, CITROEN BX 1983. These details should still be checked against the original unit before ordering.

Is this a new or remanufactured starter motor?

It is listed as new. For this listing, part number 432636 is the main reference point. Listed voltage is 12. Published fitment references include CITROEN BX, CITROEN BX 1982, CITROEN BX 1983. These details should still be checked against the original unit before ordering.

What voltage and power rating does this starter have?

It is a 12V starter motor with a 1kW power rating. For this listing, part number 432636 is the main reference point. Listed voltage is 12. Published fitment references include CITROEN BX, CITROEN BX 1982, CITROEN BX 1983. These details should still be checked against the original unit before ordering.

What rotation and tooth count does this unit use?

This starter has clockwise rotation and a 9 tooth pinion. For this listing, part number 432636 is the main reference point. Listed voltage is 12. Published fitment references include CITROEN BX, CITROEN BX 1982, CITROEN BX 1983. These details should still be checked against the original unit before ordering.

Are 9 tooth and 13 tooth units interchangeable?

Valeo notes that 9 tooth and 13 tooth units are interchangeable. For this listing, part number 432636 is the main reference point. Listed voltage is 12. Published fitment references include CITROEN BX, CITROEN BX 1982, CITROEN BX 1983. These details should still be checked against the original unit before ordering.

What are the main mounting measurements to check?

Check the 3 hole mount type, mount centres A 120mm, mount centres B 85mm, mount centres C 85mm, and M10x1.5 mount hole diameter. For this listing, part number 432636 is the main reference point. Listed voltage is 12. Published fitment references include CITROEN BX, CITROEN BX 1982, CITROEN BX 1983. These details should still be checked against the original unit before ordering.
