OEX Starter Motor 12V 10 Tooth CW Denso Style DXS575

The OEX DXS575 is a new 12V starter motor with clockwise rotation, a 10 tooth pinion and Denso suitment. It is listed with a 2.2kW power rating, a 2 hole starter mount, and an overall length of 240mm, so it is important to compare the physical dimensions and mounting layout against the unit being replaced.

Key measurements include a 130mm mount centres A dimension, 82mm flange diameter, M12 / 14 mount hole diameter, 38mm pinion diameter and 18mm pinion at rest. These details matter when checking that the replacement matches the existing starter and the engine application.

This starter is described as interchangeable with the 11 tooth version and as replacing a 2.7kW Denso starter. It also has a start wire terminal suitable for both large and small harness connectors, which can help where the existing wiring terminal style needs to be matched carefully during installation.

Key Features

• 12V new starter motor
• Clockwise rotation (CW)
• 10 tooth pinion
• Denso suitment
• 2 hole starter mount
• Start wire terminal suits large and small harness connectors

Specifications

• Part number: DXS575
• Brand: OEX
• Product type: Starter motor
• Power rating: 2.2kW
• Voltage: 12V
• Rotation: CW
• Number of teeth: 10
• Starter mount type: 2 hole

Fitment guidance

• Daihatsu Delta
• Toyota 4 Runner
• Toyota Granvia
• Toyota Hiace
• Toyota Hiace / Commuter
• Toyota Hilux
• Toyota Hilux Surf
• Toyota Land Cruiser

Application and Buying Notes

Before ordering, match the part number DXS575, the 12V system, 10 tooth pinion, and clockwise rotation against the starter being removed. The 2 hole mount, 130mm mount centres, 82mm flange diameter and 240mm overall length are the best physical checkpoints to confirm the replacement is the correct shape and size for the vehicle.

The listed note that this unit is interchangeable with the 11 tooth version and replaces a 2.7kW Denso starter is useful, but it should still be checked against the original starter and application details. Even where the unit family is the same, the terminal arrangement, mount style and pinion count must line up with the existing installation.

The start wire terminal is suitable for both large and small harness connectors, which can help with wiring compatibility, but the rest of the starter still needs to match the vehicle exactly. Use the pinion at rest of 18mm, the 38mm pinion diameter, and the M12 / 14 mount hole diameter as practical reference points when comparing units.

This starter is supplied new and carries a 3 year passenger / 1 year commercial warranty. Warranty coverage is important, but it does not replace fitment checking, so the safest approach is to confirm the vehicle application, the Denso-style configuration and the measured dimensions before fitting.

Before supply, the safest approach is to confirm the original unit details against the listed part number, voltage, output rating, mounting arrangement, and pulley configuration. That checking process is standard practice in the parts trade because visually similar units can still differ in service-critical ways.

For workshop, fleet, and equipment applications, accurate identification of part number DXS575 helps avoid unnecessary freight, additional labour, and vehicle or machine downtime. Where the application is not straightforward, the original unit, OEM reference, or workshop records should be used as the primary confirmation point.

Relevant published details for this unit include Type STARTER MOTOR, Unit of Measure EACH, Warranty 3yr Passenger 1yr Commercial, Mount Centres A 130mm, Number of Teeth 10, Pinion at Rest 18mm, Power Rating 2.2kW, Suits Unit Make Denso, Note Start wire terminal suitable for both large and small harness connector. Interchangeable with 11 Tooth version. Replaces 2.7kW Denso starter., Starter Mount Type 2 Hole.

Additional published details for cross-checking include Weight 5.9kg, Product Group 1 ROTATING ELECTRICAL, Part No. DXS575, Brand OEX, Description OEX Starter Motor 12V 10Th CW Denso Style, Flange Diameter 82mm, Mount Hole Diameter M12 / 14, Overall Length 240mm, Pinion Diameter 38mm, Rotation CW.

OEX Starter Motor 12V 10Th CW Denso Style. Part number DXS575 should be checked first. Listed voltage is 12. These details form the core reference points used by parts interpreters when confirming the correct replacement.

For part number DXS575, the normal identification sequence is part number, electrical rating, mounting arrangement, connector or terminal style, and pulley or drive details. Using those checkpoints helps confirm that the listed unit matches the service requirement rather than only looking similar.

For a starter motor in workshop, fleet, trade, agricultural, or construction service, the listed voltage 12 should be checked carefully. Incorrect selection can affect installation time, return freight, and equipment availability.

Available application references include DAIHATSU DELTA, DAIHATSU DELTA 2003, DAIHATSU DELTA 2004, DAIHATSU DELTA 2005, TOYOTA 4 RUNNER, TOYOTA 4 RUNNER 1993. Even with application listings, final confirmation should still be based on the exact unit being replaced and the service requirements of the vehicle or machine.

Compatibility note: Confirm fitment by checking part number DXS575, 12V specification, 10 tooth CW configuration, Denso suitment and all mounting dimensions against the original starter and vehicle application before purchase or installation.

FAQ

What is the part number for this starter motor?

The part number is DXS575. For this listing, part number DXS575 is the main reference point. Listed voltage is 12. Published fitment references include DAIHATSU DELTA, DAIHATSU DELTA 2003, DAIHATSU DELTA 2004. These details should still be checked against the original unit before ordering.

Is this starter motor 12V or 24V?

It is a 12V starter motor. For this listing, part number DXS575 is the main reference point. Listed voltage is 12. Published fitment references include DAIHATSU DELTA, DAIHATSU DELTA 2003, DAIHATSU DELTA 2004. These details should still be checked against the original unit before ordering.

How many teeth does the pinion have?

The pinion has 10 teeth. For this listing, part number DXS575 is the main reference point. Listed voltage is 12. Published fitment references include DAIHATSU DELTA, DAIHATSU DELTA 2003, DAIHATSU DELTA 2004. These details should still be checked against the original unit before ordering.

What rotation is this starter motor?

It is clockwise rotation, listed as CW. For this listing, part number DXS575 is the main reference point. Listed voltage is 12. Published fitment references include DAIHATSU DELTA, DAIHATSU DELTA 2003, DAIHATSU DELTA 2004. These details should still be checked against the original unit before ordering.

What are the key mounting dimensions?

The main mounting details listed are 2 hole starter mount, 130mm mount centres A, 82mm flange diameter and M12 / 14 mount hole diameter. For this listing, part number DXS575 is the main reference point. Listed voltage is 12. Published fitment references include DAIHATSU DELTA, DAIHATSU DELTA 2003, DAIHATSU DELTA 2004. These details should still be checked against the original unit before ordering.

Which vehicles are listed in the fitment data?

The fitment data lists Daihatsu Delta and Toyota applications including 4 Runner, Granvia, Hiace, Hiace / Commuter, Hilux, Hilux Surf, Land Cruiser, Land Cruiser Prado and Regius Ace. Fitment should still be confirmed against the exact starter and vehicle details before ordering. For this listing, part number DXS575 is the main reference point. Listed voltage is 12. Published fitment references include DAIHATSU DELTA, DAIHATSU DELTA 2003, DAIHATSU DELTA 2004. These details should still be checked against the original unit before ordering.
